Digital Watchdog Star-Light Plus DWC-VA553WTIR User Manual page 12

Installation - Instructions
Using the mounting template or your camera,
1
mark and drill the necessary holes to mount the
bracket to a wall or ceiling.
Pull a necessary wires through and make the
2
proper connections. See pages 14-15.
Use the three mounting screws to install the
3
camera on the wall or ceiling. See page 16 for
tilting and pan adjustment options.
Adjust the camera's tilt and rotation as needed.
4
See page 16 for more information.
When the installation is completed, place the
5
camera's dome over the camera's body by
clicking the dome into place.
12
Template sheet
