Charlton & Jenrick INFINITY 880 BF Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
INCLUDES
User, Maintenance, Service, and Installation
Instructions
880 BF
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.
For use in Great Britain and Ireland.
Literature NO 6456 (ISS 04)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INFINITY 880 BF and is the answer not in the manual?

Questions and answers

Related Manuals for Charlton & Jenrick INFINITY 880 BF

Summary of Contents for Charlton & Jenrick INFINITY 880 BF

  • Page 1 Owner’s Manual INCLUDES User, Maintenance, Service, and Installation Instructions 880 BF Keep this booklet for service log and future reference IMPORTANT This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online.

  • Page 2: Table Of Contents

    Contents EXTENDED FIVE YEAR PARTS WARRANTY ....2 Benchmark Scheme ............. 3 SECTION ONE Important Information (user EXTENDED FIVE YEAR PARTS instructions) ..............5 WARRANTY SECTION TWO Introduction (user instructions) ..6 SECTION THREE Operation (user instructions) ... 7 In order to validate your extended 5 years parts SECTION FOUR Cleaning &...

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance. Benchmark is managed and promoted by the Heating and Hotwater Industry Council.
  • Page 4 For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. MODEL: INFINITY 880 BF Serial No. This information can be found on the label attached to the packaging and on the data badge, which is located on the base of the appliance behind the control cover.

  • Page 5: Section One Important Information (User Instructions)

     As the INFINITY 880 BF is a room sealed appliance (i.e. air for the combustion process is taken from outside the room) no purpose built ventilation is required.

  • Page 6: Section Two Introduction (User Instructions)

     Although the INFINITY 880 BF is fitted with a glass front which acts as a dress guard it is strongly recommended that a fireguard should be used for the protection of children, the elderly or infirm. Fireguards should conform to B.

  • Page 7: Section Three Operation (User Instructions)

    SECTION THREE Operation (user instructions) To light the appliance using the remote hand set: A. Point the remote control hand set in the direction of the appliance and press the button. Continue to hold the button for approximately 2 seconds and release. When released a bleep should be and heard the appliance will automatically go through the ignition sequence and the pilot should ignite.
  • Page 8 To Replace Battery In Hand Set (3 aaa type batteries) Remove the cover from the rear of the handset and fit replacement battery. Clock Regulation As soon as the batteries are fitted the timer digits will blink. Using the arrow key increase or decrease the hour, minutes and week`s value.
  • Page 9 Child Lock (Handset) To activate `Child Lock` : Press and hold the Mode Key O button for 5 seconds, this will lock and disable the handset and a “padlock” symbol will appear on the bottom of the screen. This can be done while the fire is “off” or “on”. To deactivate this function press and hold the Mode Key O for 5 seconds and the “padlock”...

  • Page 10: Section Four Cleaning & Laying The Fuel Bed (User Instructions)

    SECTION FOUR Cleaning & Laying the fuel bed (user instructions) Warning:-Before you clean any part of the appliance ensure that the appliance is switched off and cold. CLEANING: BLACK PAINTED SURFACES  These surfaces should be dusted regularly and any marks removed with a soft cloth. ...
  • Page 11 CLEANING AND REPLACING fuel bed shapes Important: - Refer to the ‘Health & Safety Notice located on page 3 of this booklet before cleaning or replacing any refractory material. Use only the shapes provided NO OTHER SHAPES SHOULD BE ADDED to the appliance The Fuel bed set consists of: ...
  • Page 12  Place the Decorative Bark shapes as shown.  Place 3 off log shapes as shown.  Place 2 off log shapes as shown.  Place the last two large shapes LH and RH as shown. LT6456 (ISS 04)

  • Page 13: Section Five Appliance Data (Installation Instructions)

    SECTION FIVE Appliance Data (installation instructions) Fire Box dimensions: Height 1030mm Width 785mm Forward Projection: 42mm Weight: 35kg Flue Length……………………………………………………..……………...100mm (minimum) to 600mm (maximum) No bends or joined flue pipes should be used in the flue system. Pressure Test Point Location: Gas inlet elbow Gas Connection: 8.0mm O/D, tube.

  • Page 14: Section Six Regulations And Warnings (Installation Instructions)

    SECTION SIX Regulations and Warnings (installation instructions)  This appliance must only be installed in Great Britain or Ireland.  The appliance is available in natural gas only.  This appliance must be installed on a suitable outside wall.  No special ventilation bricks or vents are required into the room containing the appliance.

  • Page 15: Section Seven Siting The Appliance (Installation Instructions)

    SECTION SEVEN Siting the Appliance (installation instructions) GENERAL REQUIREMENTS  The flue and air duct length must be between 100mm to 600mm.  The fire is supplied with a standard pipe length of 600mm Flue length.  The flue and air duct must not have any bends. ...

  • Page 16: Section Seven Siting The Appliance Continued (Installation Instructions)

    SECTION SEVEN Siting the Appliance Continued (installation instructions) Please note with early cavity wall design prior to 1970. The minimum depth requirement may well be difficult to obtain. This could result in the need for the fire box to be spaced further from the internal surface of the plaster and to achieve this larger rebated surround maybe necessary.
  • Page 17 Measurement taken from floor Level to the flue pilot height and lintel minimum clearance Using 150mm core drill cut the holes following the pilot holes. Drill from the outside through to the cavity to give a good finish on the outside. ...
  • Page 18 CONNECTING THE GAS SUPPLY (installation instructions) TURN OFF ANY GAS APPLIANCES THAT ARE FED BY THE METER AND ISOLATE THE GAS SUPPLY BY TURNING OFF AT THE METER.  The Gas Connection can be made by removing the gas inlet cover located on the left hand side of the fire box sump assembly.

  • Page 19: Section Ten Assemble The Appliance (Installation Instructions)

    SECTION TEN Assemble the appliance (installation instructions)  Taking special care remove the ceramic liner set from within the packaging. The rear liner is in two pieces. Place the bottom rear liner upon the top edge to the air tray. Angle the upper rear line into the firebox assembly and place on top of the rear bottom line.

  • Page 20: Section Eleven Instruct And Advise The Customer (Installation Instructions)

     Holder within the bracket at the bottom of the fireplace assembly.  Fit the Inlet cover at the bottom of the appliance between the glass panel and fireplace frame assembly.  Finally Slide the LH and RH infill strip within the fireplace frame and the glass panel.

  • Page 21: Section Twelve Maintenance Instructions (Maintenance Instructions)

    SECTION TWELVE Maintenance Instructions (maintenance instructions) General  Servicing should be carried out annually by a competent person such as a GAS SAFE-registered person in accordance with the relevant regulations, to ensure the safe and correct operation of the appliance. Warning: - Before commencing any service or replacement of parts, turn off the gas supply to the fire.
  • Page 22 Turn on the gas supply, check for gas soundness, operation and re-commission appliance. When ordering parts quote 'INFINITY 880 BF' and the serial number of the fire, which can be found on the data badge on bottom left hand side of fire. (Refer to cleaning instructions for trim removal.)

  • Page 23: Section Twelve Wiring Diagram (Maintenance Instructions)

    SECTION TWELVE Wiring Diagram (maintenance instructions) Attach to the valve www.charltonandjenrick.co.uk LT6456 (ISS 04)
  • Page 24 LT6456 (ISS 04)
  • Page 25 Register your appliance online today to active your warranty www.charltonandjenrick.co.uk LT6456 (ISS 04)

  • Page 26: Balanced Flue Gas Fire Commissioning Checklist

    BALANCED FLUE GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference. Failure to install and commission according to the manufacturer’s instructions and complete this Benchmark Commissioning Checklist will invalidate the warranty.

  • Page 27: Service Record

    SERVICE RECORD It is essential that your gas fire is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
  • Page 28 Product A-0432 Serial No ID Label Prefix Data Badge Burner Tray / Box Assembly Air Test Completed Warning Label (1409) Grommet (1406) Glass Sub-Assembly Silicone Sealing Strip (4818) x 2 880 BF Log Set (6334) Fireplace Frame (6257) Battery Holder (5775) Inlet Cover (6249) Top Fixing Cover (6344) “AAA”...
