Combustion Specifications

Jøtul F 602 V2
1
Heat Output Range:
2
Heating Capacity:
2
Maximum Burn Time:
3
EPA Efficiency:
4
CO Emissions:
5
Pariculate Emissions:
Fuel: Up to 16" Logs (330 mm)
1
Heat Output Range results are determined during specific
emissions tests established by the EPA.
2
Heating Capacity and Maximum Burn Time will vary depending on
design of home, climate, wood type and operation
3
EPA Tested Efficiency:
High Heat Value and Low Heat Value efficiencies are determined
per the CSA B415.1-10 test method. The difference between the
HHV and LHV is in how the energy in the exhaust gas water vapor
is accounted.
LHV efficiency assumes all the water vapor in combustion gases
was condensed and the heat from such was recovered and
transferred to the dwelling. HHV calculations do not assume all
water vapor is condensed, therefore the HHV value is less than the
LHV value
4
Carbon Monoxide Emissions rate results from Test Method CSA
B415.1-10.
5
.
Particulate Emissions rate was obtained using EPA Test Method
ALT-125 (Cordwood Fuel)., ASTM E2515-11 and ASTM E3053-17.
Check Building Codes
When installing, operating and maintaining your
Jøtul F 602 V2 woodstove, follow the guidelines presented
in these instructions, and make them available to anyone
using or servicing the stove.
Your city, town, county or province may require a building
permit to install a solid fuel burning appliance.
In the U.S., the National Fire Protection Association's Code,
NFPA 211, Standards for Chimneys, Fireplaces, Vents and
Solid Fuel Burning Appliances, or similar regulations, may
apply to the installation of a solid fuel burning appliance
in your area.
In Canada, the guideline is established by the CSA
Standard, CAN/CSA-B365-M93, Installation Code for Solid-
Fuel-Burning Appliances and Equipment.
Always consult your local building inspector or authority
having jurisdiction to determine what regulations apply
in your area.
15,200 to 49,576 BTU/hr.
Up to 800 sq. ft.
Up to 5 hours
HHV: 70% LHV: 75.14%
1.18 g/min.
2.11 g/hr

1.0 Safety Notices

• BURN SOLID, NATURAL WOOD FUEL ONLY. DO NOT BURN ANY
OTHER FUEL.
• DO NOT USE CHEMICALS OR FLUIDS TO START A FIRE. DO NOT
BURN GARBAGE OR FLAMABLE FUELS.
• DO NOT USE A GRATE OR ELEVATE THE FIRE. BUILD THE FIRE
DIRECTLY ON THE HEARTH.
• IF THIS ROOM HEATER IS NOT PROPERLY INSTALLED, A HOUSE
FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE
INSTRUCTIONS IN THIS MANUAL. FAILURE TO FOLLOW THESE
INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY
INJURY, OR LOSS OF LIFE.
• CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT
RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS
IN YOUR AREA.
• ANY EXISTING CHIMNEY SYSTEM MUST BE INSPECTED BEFORE
INSTALLATION OF THIS APPLIANCE.
• DO NOT CONNECT THIS STOVE TO ANY AIR DISTRIBUTION DUCT
OR SYSTEM.
• EXTREMELY HOT WHILE IN OPERATION! KEEP CHILDREN,
CLOTHING, AND FURNITURE AWAY. CONTACT WILL CAUSE SKIN
BURNS. USE A CHILD GUARD SCREEN TO PREVENT ACCIDENTAL
CONTACT BY SMALL CHILDREN.
• INSTALL SMOKE DETECTORS IN THE LIVING AREA AND
BEDROOMS OF YOUR HOME. TEST THEM REGULARLY AND
INSTALL FRESH BATTERIES TWICE ANNUALLY.
WHEN INSTALLED IN THE SAME ROOM AS THE STOVE, A SMOKE
OR CARBON MONOXIDE DETECTOR SHOULD BE LOCATED AS
FAR FROM THE STOVE AS POSSIBLE TO PREVENT THE ALARM
SOUNDING WHEN ADDING FUEL.
• DO NOT OPERATE THIS APPLIANCE WITH CRACKED OR BROKEN
GLASS. REPLACE GLASS ONLY WITH JØTUL PART NUMBER 128101.
• Avoid creating a low pressure condition in the room where the
stove is operating. Be aware that operation of an exhaust fan or
clothes dryer can create a low pressure area and consequently
promote flow reversal through the stove and chimney system. In
some cases, the optional Fresh Air Adaptor #156408 can be used
to alleviate this condition. The chimney and building, however,
always work together as a system - provision of outside air,
directly or indirectly to an atmospherically vented appliance
will not guarantee proper chimney performance. Consult your
local Jøtul authorized dealer regarding specific installation/
performance issues.
• Jøtul strongly recommends that this stove be installed by a
professional solid fuel technician, or that you consult one if
you do the work yourself. Also, consult your insurance company
regarding any other specific requirements.
F 602 V2 3/20
