Jøtul F 602 CB
Non-catalytic Wood Heater
Installation and Operating Instructions
for the United States and Canada
„ The Jøtul F 602 CB non-catalytic stove is
listed to burn solid wood only. Do not
burn any other fuels.
„ Read this entire manual before you
install and use this appliance.
„ Save these instructions for future
reference and make them available to
anyone using or servicing the fireplace
insert.
„ This wood heater requires periodic
inspection and repair for proper
operation. See this manual for specific
maintenance information. It is against
federal regulations to operate this
wood heater in a manner inconsistent
with the operating instructions in this
owner's manual.

Advertisement

Table of Contents
loading

Related Manuals for Jøtul F 602 CB

Summary of Contents for Jøtul F 602 CB

  • Page 1 Non-catalytic Wood Heater Installation and Operating Instructions for the United States and Canada „ The Jøtul F 602 CB non-catalytic stove is listed to burn solid wood only. Do not burn any other fuels. „ Read this entire manual before you install and use this appliance.

  • Page 2: Table Of Contents

    Table of Contents Standards Combustion Specifications, Building Codes, ..............3 The Jøtul F 602 CB solid fuel heater has been tested and listed to : 1.0 Safety Notices ..............3 U.S. Standards: ANSI/UL 737 and ANSI/UL 1482. Canadian Standards: 2.0 Initial Assembly CAN/ULC-S627-M00 and CAN/ULC-S628-M93 2.1 Inspect Contents ..............

  • Page 3: Combustion Specifications

    F 602 CB 139677_R04 April 2017 1.0 Safety Notices Combustion Specifications Jøtul F 602 CB • BURN SOLID, NATURAL WOOD FUEL ONLY. DO NOT BURN ANY OTHER FUEL. Heat Output Range: 12,000 to 47,700 BTU/hr. • DO NOT USE CHEMICALS OR FLUIDS TO START A FIRE. DO NOT Max.

  • Page 4: Initial Assembly

    F 602 CB 139677_R04 April 2017 2.0 Initial Assembly be accessible for cleaning. Where passage through a wall or partition of combustible construction is desired, the installation must conform with NFPA 211 or CAN/CSA-B365, and is also addressed in this manual.

  • Page 5: Chimney Requirements

    A chimney, whether masonry or prefabricated metal, must be the required height above the roof or other obstruction for safety and There are two types of chimneys suitable for the Jøtul F 602 CB: for proper draft function. The chimney must beat least 3’ higher 1.

  • Page 6: Floor Protection

    C-factor (thermal conductance). When installed with a listed double wall pipe and with wall protection, the Jøtul F 602 CB can be placed in an alcove that See 8.0 Appendix A on page 17 for the procedure to has a minimum height of 96”...

  • Page 7: Operation 5.1 Combustion Efficiency

    Worse, that moisture will condense as creosote in the relatively The Jøtul F 602 CB has an EPA tested High Heating Value (HHV) efficiency rate of 70.06. There are, however, aspects...

  • Page 8: Break-In Procedure

    The Jøtul F 602 CB is constructed of cast iron and stove furnace cement. Cast iron, while very durable, expands and contracts as it is heated and cooled.

  • Page 9: Open Door Fire-Viewing

    F 602 CB 139677_R04 April 2017 5.9 Ash Removal Note: lf the charcoal bed present at reloading time is relatively deep (2”-3”) and your wood is well seasoned, it Always use stove gloves when handling hot ashes. Ash is possible to add the fresh fuel load, close the door and...

  • Page 10: Maintenance

    The Jøtul F 602 CB is designed to burn cleanly and efficiently • Press the gasket firmly in place. when used according to the guidelines in this manual. In •...

  • Page 11: Illustrations 7.1 Clearance Chart

    F 602 CB 139677_R04 April 2017 7.0 Jøtul F 602 CB Clearances Table Stove clearances Unprotected surfaces Protected surfaces (NFPA 211) Top vent/vertical Side Rear Corner Side Rear Corner Single wall pipe 21” 13.5” 13” 13” 11” 9” W/out rear heatshield...

  • Page 12: Figures

    F 602 CB 139677_R04 April 2017 Fig. 2. Fig. 1. 12 5/8” 320mm Chimney Connector points toward stove. Flue Gas Toward Stove Direction 12 1/2” 317mm Fig. 3. 21 1/4” 18 7/8” 19 5/16” 21 1/4” Fig. 4. At least 2 ft.
  • Page 13 F 602 CB 139677_R04 April 2017 Fig. 5 Hearth Protection 2” Fig. 7 Listed Cap (5 cm) Storm Manufacturer’s specified clearance Collar to combustible construction Flashing 43 1/2” 45 1/2” (111 cm) (116 cm) Listed Chimney Attic Insulation A: 8” (20 cm) Shield B: 16”...
  • Page 14 F 602 CB 139677_R04 April 2017 Alcove - double wall pipe and Fig. 11 Rear Heat Shield to reduce clearance Fig. 14 Single wall pipe, top exit only wall protection A: 41” - (104 cm) A: 21” - (53,5 cm) B: 8”...
  • Page 15 F 602 CB 139677_R04 April 2017 Parallel installation in a corner with Controls Fig. 17 Fig. 20 wall shield Combustible wall Wall Shield • Must be 1” off the The wall wall and 1” off the shield must floor. extend a •...
  • Page 16 F 602 CB 139677_R04 April 2017 Fig.21...

  • Page 17: Part List

    F 602 CB 139677_R04 April 2017 8.0 Illustrated Partlist 9.0 Appendix A Alternate floor protection Pos Description .........Dim./Spec. All floor protection materials must be non-combustible ie. Metal, Hot plate ........... 240 mm brick, stone, mineral fiber boards). Any combustible material may Gasket ..........

  • Page 18: Warranty

    F 602 CB 139677_R04 April 2017 10.0 Jøtul Woodburning The warranty period for any replaced component will be the remaining unexpired portion of the warranty period for the Product Warranty original component. Please retain your dated sales receipt in your records as proof of purchase.
  • Page 19 F 602 CB 139677_R04 April 2017 An authorized installer may have been provided with IN NO EVENT SHALL JØTUL, ITS PARENT COMPANY, certain information related particularly to the Jøtul or SHAREHOLDERS, AFFILIATES, OFFICERS, EMPLOYEES, AGENTS Scan Stove or Fireplace; however, no authorized installer...
  • Page 20 F 602 CB 139677_R04 April 2017 We appreciate your trust in welcoming our product into your home and invite your comment and appraisal of our efforts to provide you with the finest in home hearth products. Jøtul maintains a policy of continuous product development. Products supplied may therefore differ in specification, colour and type of accessories from those illustrated and described in this manual.
