3.1.3 Analog Outputs (AO)

NPA
0
1
2
3
4
5
6
7
8
9
10
®
VLT Metasys
Unit Description
% Bus reference
Bus Feedback 1
Bus Feedback 2
Bus Feedback 3
Analog Output 42
Pulse Output 27
Pulse Output 29
Analog Output, GPIOTer-
minal X30/8
Analog Output, IO Option
X42/7
Analog Output, IO Option
X42/9
Analog Output, IO Option
X42/11
®
MG.11.G2.02 - VLT is a registered Danfoss trademark
Range
-200 to 200 Proportionally
1
mapped into the range
-32768 to 32767
FC Par. Number
Shared Variable
3
8-94
8-95
8-96
6-53
5-93
5-95
6-63
26-53
26-63
26-73
