MANUAL
ENGLISH
Dragon 1000
V1
Ordercode: 61101
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dragon 1000 V1 and is the answer not in the manual?

Questions and answers

Summary of Contents for SHOWTEC Dragon 1000 V1

  • Page 1 MANUAL ENGLISH Dragon 1000 Ordercode: 61101 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
  • Page 2: Table Of Contents

    Dragon 1000 Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Return Procedure ................................5 Claims ....................................5 Description of the device ..............................6 Frontside..................................6 Backside ..................................7 Installation ................................... 7 Set Up and Operation ...............................
  • Page 3: Warning

    Dragon 1000 Warning Unpacking Instructions Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure that all parts are present and have been received in good condition. Notify the dealer immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling.
  • Page 4 If the Dragon fails to work properly, discontinue use immediately. Drain all fog liquid from the tank, • pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service. For replacement use fuses of same type and rating only.
  • Page 5: Operating Determinations

    Dragon 1000 The residence time of persons in fog-filled rooms with the visibility lower than 15 m must never exceed • 5 minutes. The fog vapour at the point of release is under pressure and is extremely hot. • The output nozzle becomes very hot during operation (300º C). Keep flammable materials at least 50 •...
  • Page 6: Return Procedure

    Dragon 1000 Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture.
  • Page 7: Description Of The Device

    Dragon 1000 Description of the device Features The Dragon 1000 is a powerful fog machine. With the Dragon, you can create a cosy and foggy atmosphere in any venue. Input Voltage: 220-240V AC, 50Hz • Power consumption: 1000W • Output volume: 10000 cu.ft/min •...
  • Page 8: Backside

    Dragon 1000 Backside Fig. 02 08) 5-pin DIN remote control connector IN 09) Power switch ON/OFF 10) IEC power connector 220-240V + Fuse F5AL/250V 11) 5-pin DIN wireless receiver connector IN (connect the 61120 – Wireless Remote Dragon Series) 12) Fog fluid level indicator Installation Remove all packing materials from the Dragon 1000.
  • Page 9: Set Up And Operation

    Dragon 1000 Set Up and Operation Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Note: Always monitor fog tank level liquid indicator when making fog! Note: Be careful not to exceed the maximum fluid level.
  • Page 10: Troubleshooting

    05) If you are unable to determine the cause of the problem, do not simply continue pushing the remote button, as this may damage the unit. 06) Return the machine to your Showtec dealer. Product Specification Model:...
  • Page 11: Dimensions

    Dragon 1000 Dimensions Ordercode: 61101...
  • Page 12 ©2015 Showtec...
