PCA-6006
Full-size socket 478 Intel
Pentium® 4/ Celeron™
processor-based PCI/ISA
CPU card
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCA-6006 and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech PCA-6006

Summary of Contents for Advantech PCA-6006

  • Page 1 PCA-6006 Full-size socket 478 Intel Pentium® 4/ Celeron™ processor-based PCI/ISA CPU card User’s Manual...
  • Page 2 Copyright Notice This document is copyrighted, 2003, by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improve- ments to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmit- ted in any form or by any means without the prior written permission of Advantech Co., Ltd.
  • Page 3 Advantech equipment is destined for the laboratory or the factory floor, you can be assured that your product will provide the reliability and ease of operation for which the name Advantech has come to be known. Your satisfaction is our primary concern. Here is a guide to Advantech’s customer services.
  • Page 4 PCA-6006 series comparisoin table Model PCA-6006LV-00A1 PCA-6006VE-00A1 CPU: Single socket 478 Intel® Pentium® 4/ Celeron™ 845GV 845GV Chipset Front Side Bus 400/533 MHz 400/533 MHz System chipset: Intel 845GV USB Port PS/2 KB & Mouse Port VGA: Intel 845GV Integrated...
  • Page 5 Advantech assumes no liability under the terms of this warranty as a consequence of such events. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
  • Page 6 It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the PCA-6006, check it for signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.

  • Page 7: Table Of Contents

    Contents Chapter 1 Hardware Configuration .........2 Introduction ............... 2 Features ................3 Specifications ..............4 1.3.1 System................4 1.3.2 Memory................4 1.3.3 Input/Output..............4 1.3.4 VGA interface..............5 1.3.5 Ethernet LAN..............5 1.3.6 Industrial features ............5 1.3.7 Mechanical and environmental specifications....5 Jumpers and Connectors............
  • Page 8 3.4.14 MPS Version Control For OS........33 Advanced Chipset Features..........33 Figure 3.4:Advanced chipset features screen ....33 3.5.1 DRAM Timing Selectable ..........33 3.5.2 CAS Latency Time ............34 3.5.3 Active to Precharge Delay ..........34 PCA-6006 User’s Manual...
  • Page 9 3.5.4 DRAM RAS# to CAS# Delay ........34 3.5.5 RAS# Precharge Time ..........34 3.5.6 System BIOS Cacheable..........34 3.5.7 Video Bios Cacheable........... 34 3.5.8 Memory Hole At 15M-16M ......... 34 3.5.9 Delayed Transaction ............. 34 3.5.10 Delay Prior to Thermal ..........34 3.5.11 AGP Aperture Size (MB) ..........
  • Page 10 6 LAN Configuration ........54 Introduction ..............54 Features ................54 Installation............... 55 Windows 98/2000 Drivers Setup Procedure (Intel® 82562)..............55 Windows NT Wake-on-LAN Setup Procedure....59 Chapter 7 USB 2.0 Configuration........62 Introduction ..............62 Features ................62 Installation........62 PCA-6006 User’s Manual...
  • Page 11 Chapter 8 Ultra ATA Storage Driver Setup ....70 Introduction ..............70 Features ................70 Window 2000 Setup Procedure........71 Displaying Driver Information........74 NT Setup Procedure ............75 Chapter 9 Onboard Security Setup ........80 Introduction ..............80 Windows 9X Drivers Setup Procedure ......81 Windows 2000/NT Drivers Setup Procedure....
  • Page 12 B.25 Interrupt Assignments ........... 117 B.26 1st MB Memory Map............ 118 B.27 PCI Bus Map ..............118 PCA-6006 User’s Manual...
  • Page 13 General Information This chapter gives background infor- mation on the PCA-6006. It then shows you how to configure the card to match your application and prepare it for installation into your PC. Sections include: • Introduction • Features • Specifications •...

  • Page 14: Chapter 1 Hardware Configuration

    478 Pentium 4/Celeron processor (FSB 400/ 533MHz) up to 3.06GHz and above. In addition to high-speed processor, PCA-6006 supports up to 2GB DDR memory with 2 DIMM socket on board. It provides maximum computing power and productivity which is ideal for high-performance demanding application.

  • Page 15: Features

    1.2 Features Fan status monitoring and alarm: To prevent system overheating and damage, the CPU fan can be monitored for speed and failure. The fan is set for its normal RPM range and alarm thresholds. Temperature monitoring and alert: To prevent system overheat- ing and damage, the CPU card supports processor thermal sensing and auto-protection.

  • Page 16: Specifications

    1.3 Specifications 1.3.1 System • CPU: PCA-6006 supports Intel Pentium® 4/ Celeron™ up to 3.06GHz and the above, FSB 400/533 MHz. • Firmware hub: Provides security enhancements on computer plat- forms by supporting Random Number Generator (RNG) •...

  • Page 17: Vga Interface

    • Keyboard and PS/2 mouse connector: One 6-pin mini-DIN connector is located on the mounting bracket for easy connection to a keyboard or PS/2 mouse. An onboard keyboard pin header connector is also avail- able • USB port: Supports USB 2.0 and transmission rate up to 480Mbps. •...

  • Page 18: Jumpers And Connectors

    1.4 Jumpers and Connectors Connectors on the PCA-6006 board link it to external devices such as hard disk drives and a keyboard. In addition, the board has a number of jumpers used to configure your system for your application. The tables below list the function of each of the board jumpers and con- nectors.
  • Page 19 Table 1.2: Connectors CN20 ATX feature connector CN21 ATX soft power switch CN22 HW Monitor Alarm Close: Enable OBS Alarm Open: Disable OBS Alarm CN43 AC-97 Audio connector CN46 Auxiliary 4-pin power connector CN47 Auxiliary 4-pin power connector...

  • Page 20: Board Layout: Jumper And Connector Locations

    1.5 Board Layout: Jumper and Connector Locations Figure 1.1: Jumper and connecter locations PCA-6006 User’s Manual...

  • Page 21: Safety Precautions

    1.6 Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.

  • Page 22: Cmos Clear (J1)

    * default setting 1.7.3 Watchdog timer output (J2) The PCA-6006 contains a watchdog timer that will reset the CPU or send a signal to IRQ11 in the event the CPU stops processing. This feature means the PCA-6006 will recover from a software failure or an EMI problem.

  • Page 23: System Memory

    It will be held low until the watchdog timer is reset. 1.8 System Memory The top-left edge of the PCA-6006 contains two sockets for 184-pin dual in-line memory modules (DIMMs). Both two sockets use 2.5 V unbuf- fered synchronous DRAMs (DDR SDRAM). DIMMs are available in capacities of 64, 128, 256, 512 MB, or 1 GB.

  • Page 24: Sample Calculation: Dimm Memory Capacity

    1.8.1 Sample calculation: DIMM memory capacity Suppose you install a 512 MB DIMM into your PCA-6006's socket 1 and a 512 MB DIMM into sockets 2. Your total system memory is 1 GB, cal- culated as follows: Table 1.6: DIMM memory capacity sample calculation...

  • Page 25: Cpu Installation

    1.11 CPU Installation The PCA-6006 is designed for Intel Pentium® 4 processor/Celeron™ (socket 478) Note: Slim Heatsink & Fan is available from Advan- tech. Part number is 1759252100. Please contact with Advantech's sales representitive if needed.
  • Page 26 PCA-6006 User’s Manual...

  • Page 27: Chapter 2 Connecting Peripherals

    Connecting Peripherals This chapter tells how to connect peripherals, switches, and indicators to the PCA-6006 board. Chapter 2...

  • Page 28: Introduction

    You can attach up to four IDE (Integrated Drive Electronics) drives to the PCA-6006’s built-in controller. The primary (CN1) and secondary (CN2) connectors can each accommodate two drives. Wire number 1 on the cable is red or blue and the other wires are gray.

  • Page 29: Floppy Drive Connector (Cn3)

    2.3 Floppy Drive Connector (CN3) You can attach up to two floppy disk drives to the PCA-6006's onboard controller. You can use 3.5" (720 KB, 1.44 MB) drives. The card comes with a 34-pin daisy-chain drive connector cable. On one end of the cable is a 34-pin flat-cable connector.

  • Page 30: Usb Ports (Cn6, Cn31, And Cn32)

    2.5 USB Ports (CN6, CN31, and CN32) The PCA-6006 provides up to six ports of USB (Universal Serial Bus) interface, which gives complete Plug & Play and hot swapping for up to 127 external devices.The USB interface complies with USB Specification Rev.

  • Page 31: 10/100Base-T Ethernet Connectors (Cn8)

    2.8 Serial Ports (CN9: COM1; CN10: COM2) CN9 and CN10 The PCA-6006 offers two serial ports, CN9 as COM1 and CN10 as COM2. These ports can connect to serial devices, such as a mouse or a printer, or to a communications network.

  • Page 32: Ps/2 Keyboard And Mouse Connectors

    PS/2 mouse. 2.10 External Keyboard Connector (CN12) CN12 In addition to the PS/2 mouse/keyboard connector on the PCA-6006's ear plate, there is also an extra onboard external keyboard connector. This gives system integrators greater flexibility in designing their systems.

  • Page 33: Infrared (Ir) Connector (Cn13)

    2.11 Infrared (IR) Connector (CN13) This connector supports the optional wireless infrared transmitting and receiving module. This module mounts on the system case. You must configure the setting through the BIOS setup (see Chapter 3). CN13 2.12 CPU Fan Connector (CN14) CN14 If fan is used, this connector supports cooling fans of 500mA (6W) or less.

  • Page 34: Front Panel Connectors (Cn16, 17, 18, 19, 21&22)

    2.13.2 External speaker (CN17) CN17 is a 4-pin connector for an extenal speaker. If there is no external speaker, the PCA-6006 provides an onboard buzzer as an alternative. To enable the buzzer, set pins 3-4 as closed PCA-6006 User’s Manual...

  • Page 35: Reset (Cn18)

    2.14.1 ATX feature connector (CN20) and soft power switch connector (CN21) The PCA-6006 can support an advanced soft power switch function if an ATX power supply is used. To enable the soft power switch function: Take the specially designed ATX-to-PS/2 power cable out of the PCA-6006's accessory bag.

  • Page 36: Controlling The Soft Power Switch

    "Wake- on-LAN" function. 2.14.2 Controlling the soft power switch Users can also identify the current power mode through the system's power LED. 2.15 AC-97 Audio Interface The PCA-6006 provides AC-97 audio through PCA-AUDIO-00A1 mod- ule from Advantech. PCA-6006 User’s Manual...

  • Page 37: Auxiliary 4-Pin Power Connector (Cn46 And Cn47)

    2.16 Auxiliary 4-pin power connector (CN46 and CN47) To ensure the sufficiency of power supply for Pentium(R) 4 CPU card, two auxiliary 4 pin power connector are avaliable in PCA-6006. It is strongly suggested to use auxiliary 4 pin power connector for adequate power supply.
  • Page 38 PCA-6006 User’s Manual...
  • Page 39 Award BIOS Setup This chapter describes how to set the card’s BIOS configuration data. Chapter 3...

  • Page 40: Chapter 3 Award Bios Setup

    "CMOS checksum error..." display screen mes- sage. Then enter the "Setup" screen to modify the data. If the "CMOS checksum error..."mes- sage reappears over and over, please check to see if you need to replace the battery in your system. PCA-6006 User’s Manual...

  • Page 41: Entering Setup

    3.2 Entering Setup Turn on the computer and check for the “patch code”. If there is a number assigned to the patch code, it means that the BIOS supports your CPU. If there is no number assigned to the patch code, please contact Advan- tech’s applications engineer to obtain an up-to-date patch code file.

  • Page 42: Standard Cmos Setup

    The “Advanced BIOS Features” screen appears when choosing the “Advanced BIOS Features” item from the “Initial Setup Screen” menu. It allows the user to configure the PCA-6006 according to his particular requirements. Below are some major items that are provided in the Advanced BIOS Features screen.

  • Page 43: Virus Warning

    A quick booting function is provided for your convenience. Simply enable the Quick Booting item to save yourself valuable time. Figure 3.3: Advanced BIOS features screen 3.4.1 Virus Warning If enabled, a warning message and alarm beep activates if someone attempts to write here.

  • Page 44: Boot Up Floppy Seek

    To disable security, select “PASSWORD SET- TING” in the main menu. At this point, you will be asked to enter a password. Simply press <Enter> to disable security. When security is disabled, the system will boot, and you can enter Setup freely. PCA-6006 User’s Manual...

  • Page 45: Apic Mode

    3.5 Advanced Chipset Features By choosing the “Advanced Chipset Features” option from the “Initial Setup Screen” menu, the screen below will be displayed. This sample screen contains the manufacturer’s default values for the PCA-6006, as shown in Figure 3-4: Note:...

  • Page 46: Cas Latency Time

    Select Enabled to support compliance with PCI spec- ification version 2.1. The Choice: Enabled, Disabled. 3.5.10 Delay Prior to Thermal Select Enabled if user wants to lower the CPU speed when CPU tempera- ture is too high. The choice: Enabled, Disabled. PCA-6006 User’s Manual...

  • Page 47: Agp Aperture Size (Mb)

    3.5.11 AGP Aperture Size (MB) Select the size of Accelerated Graphics Port (AGP) aperture. The aper- ture is a portion of the PCI memory address range dedicated for graphics memory address space. Host cycles that hit the aperture range are for- warded to the AGP without any translation.

  • Page 48: On-Chip Secondary Pci Ide

    Option is Enable and Disable. Select Disable if user does not want to use onboard LAN controller1 3.6.8 Onboard LAN2 Control Option is Enable and Disable. Select Disable if user does not want to use onboard LAN controller2 PCA-6006 User’s Manual...

  • Page 49: Ide Hdd Block Mode

    3.6.9 IDE HDD Block Mode You can enable the Primary IDE channel and/or the Secondary IDE chan- nel. Any channel not enabled is disabled. This field is for systems with only SCSI drives. 3.6.10 Onboard FDC Controller When enabled, this field allows you to connect your floppy disk drives to the onboard floppy disk drive connector instead of a separate controller card.

  • Page 50: Ir Transmission Delay

    This selection is available only if you select “ECP” or “ECP + EPP” in the Parallel Port Mode field. In ECP Mode Use DMA, you can select DMA channel 1, DMA channel 3, or Disable. Leave this field on the default setting. PCA-6006 User’s Manual...

  • Page 51: Power Management Setup

    3.7 Power Management Setup The power management setup controls the CPU card’s “green” features to save power. The following screen shows the manufacturer’s defaults:: Figure 3.7: Power management setup screen (1) 3.7.1 Power-Supply Type Choose AT or ATX power supply 3.7.2 ACPI function The choice: Enabled, Disabled.

  • Page 52: Video Off In Suspend

    3.7.10 PowerOn By Modem When Enabled, an input signal on the serial Ring Indicator (RI) line (in other words, an incoming call on the modem) awakens the system from a soft off state. The choices: Enabled, Disabled. PCA-6006 User’s Manual...

  • Page 53: Poweron By Alarm

    3.7.11 PowerOn By Alarm When Enabled, your can set the date and time at which the RTC (real- time clock) alarm awakens the system from Suspend mode. The choices: Enabled, Disabled. 3.7.12 Primary IDE 0 (1) and Secondary IDE 0 (1) When Enabled, the system will resume from suspend mode if Primary IDE 0 (1) or Secondary IDE 0 (1) is active.

  • Page 54: Pnp/Pci Configurations

    “Auto” automatically configures all of the boot and Plug and Play devices but you must be using Windows 95 or above. 3.8.4 PCI/VGA Palette Snoop This is left at “Disabled.” PCA-6006 User’s Manual...

  • Page 55: Pc Health Status

    3.9 PC Health Status 3.9.1 CPU Warning Temperature This item will prevent the CPU from overheating. The choices: 30~120. Figure 3.10: PC health status screen 3.9.2 Current CPU Temperature This shows you the current CPU temperature. 3.9.3 Current CPUFAN Speed This shows you the current CPUFAN operating speed.

  • Page 56: Password Setting

    CMOS memory of the chipset. The micropro- cessor will check this every time you turn your system on and compare this to what it finds as it checks the system. This record is required for the system to operate. PCA-6006 User’s Manual...

  • Page 57: Exit Without Saving

    3.12 Exit Without Saving Selecting this option and pressing <Enter> lets you exit the setup program without recording any new values or changing old ones. Chapter 3...
  • Page 58 PCA-6006 User’s Manual...
  • Page 59 Chipset Software Installation Utility This utility software installs to the Win- dows INF files that outline to the oper- ating system how the components will be configured. This utility has to be installed before other drivers. Chapter 4...

  • Page 60: Chapter 4 Chipset Software Installation Utility

    To facilitate the installation of the enhanced display device drivers and utility software, you should read the instructions in this chapter carefully before you attempt installation. The device drivers for the PCA-6006 board are located on the software installation CD. The auto-run function of the driver CD will guide and link you to the utilities and device drivers under a Windows system.

  • Page 61: Installing The Csi Utility

    • Identification of Intel ® chipset components in the Device Manager. • Integrates superior video features. These include filtered sealing of 720 pixel DVD content, and MPEG-2 motion compensation for soft- ware DVD Note: This utility is used for the following versions of Windows system, and it has to be installed before installing all the other drivers: Windows 98SE...
  • Page 62 Click "Next" when you see the following message. Click "Yes" when you see the following message. PCA-6006 User’s Manual...
  • Page 63 Click "Next" when you see the following message. When the following message appears, click "Finish" to complete the installation and restart Windows. Chapter 4...
  • Page 64 PCA-6006 User’s Manual...
  • Page 65 VGA Setup The PCA-6006 features an integrated VGA interface. This chapter provides instructions for installing the VGA drivers from the driver CD included in your package. Chapter 5...

  • Page 66: Chapter 5 Vga Setup

    For example, a 3D application when launched may require more vertex buffer memory to enhance the complexity of objects, or more texture memory to enhance the richness of the 3D environment. PCA-6006 User’s Manual...

  • Page 67: Installation

    The operating system views the integrated graphics driver as an applica- tion, which uses Direct AGP to request allocation of additional memory for 3D applications, and returns the memory to the operating system when no longer required. The Intel Extreme Graphics Driver determines the size of the pre-allo- cated memory needed and will make additional Non-Local Video Mem- ory requests to achieve the amount needed for the display and application requirement.
  • Page 68 You will see a welcome window. Please chick on "Next" to con- tinue the installation. Click "Yes" when you see the following message. PCA-6006 User’s Manual...
  • Page 69 Click on "Yes" to continue the installation VGA driver is now installing Chapter 5...
  • Page 70 When the following message appears, you can choose to restart the computer now or later. PCA-6006 User’s Manual...
  • Page 71 LAN Configuration The PCA-6006 supports 10/100Base-T Ethernet networking with Intel 82562 Ethernet controller. This chapter gives detailed information on Ethernet con- figuration. It shows you how to config- ure the card to match your application requirements. Sections include: • Introduction •...

  • Page 72: Chapter 6 Lan Configuration

    Chapter 6 LAN Configuration 6.1 Introduction The PCA-6006 features the 32-bit 10/100 Mbps Ethernet network inter- face. This interface supports bus mastering architecture and auto-negotia- tion features. Therefore standard twisted-pair cabling with RJ-45 connectors for 10 Mbps, 100 Mbps and 1000 Mbps connections can be used.

  • Page 73: Installation

    See Chapter 4 for information on installing the CSI utility. The PCA-6006's onboard Ethernet interface supports all major network operating systems. However, the installation procedure varies with differ- ent operating systems. In the following sections, refer to the one that pro- vides driver setup procedure for the operating system you are using.
  • Page 74 In the "PCI Ethernet Controller Properties" window, select the "Driver" tab. Then click on "Update Driver..." In the "Upgrade Device Driver Wizard" window, click on "Next." PCA-6006 User’s Manual...
  • Page 75 In the "Upgrade Device Driver Wizard" window, select "Display for a list of known drivers for this device so that I can choose a spe- cific driver." Then click on "Next." In the following "Upgrade Device Driver Wizard" window,click on Network Adapter and then "Next".
  • Page 76 In the "Upgrate Device Driver Wizer" Window, click on "Have Disk" and then "Next". In the following "Upgrade Device Driver Wizard" window, specify the location at "D:\Drv_Lan\82562" for 10/100Base-T Ethernet LAN and click "Next" to complete the installation. D:\Drv_LAN\82562 PCA-6006 User’s Manual...

  • Page 77: Windows Nt Wake-On-Lan Setup Procedure

    6.5 Windows NT Wake-on-LAN Setup Procedure From the desktop of Windows NT, click on "Start" and select "Set- tings." Then click on the "Control Panel" icon to select "System." In the "Intel(R) PROSet" window, under "Select a Network Adapter," choose "[2] Intel(R) PRO100+ Management Adapter." Then select the "Advanced"...
  • Page 78 In the "Reboot Required" window, click on "Yes." PCA-6006 User’s Manual...
  • Page 79 USB 2.0 Configuration The PCA-6006 supports USB 2.0 device. From this chapter, you will find detail informaiton regarding Windows 2000 USB 2.0 driver setup procedure. Chapter 7...

  • Page 80: Chapter 7 Usb 2.0 Configuration

    Chapter 7 USB 2.0 Configuration 7.1 Introduction The PCA-6006 is designed with Intel ICH4 which supports both USB1.1 and USB 2.0 high-speed transmission. It still remains the compatibility with today's USB device. High-speed USB 2.0 provides data transfer up to 480Mb/s which is 40 times faster than USB 1.1. It is ideal for today's speed-demanding I/O peripherals.
  • Page 81 1. From Windows 2000, select Start and click on Setting. In the window of Setting, click on icon System. Choose the option "Hardware", and then click on "Device Man- ager" Chapter 7...
  • Page 82 In Device Manager, choose "USB Controller" and then double click. Choose the option "Driver" and then click on "Update Driver". PCA-6006 User’s Manual...
  • Page 83 In Upgrade Device Driver Wizar, click on "Next". In Upgrade Device Wizard, choose "search for a suitable device for my driver" and then click on " Next". Chapter 7...
  • Page 84 Tick "Specify a location" and click "Next" In the following windows, please specify the location "D:\Drv_USB\w2k" and then click on "OK". PCA-6006 User’s Manual...
  • Page 85 In the following window, please click on "Finish" to complete USB driver installation. Chapter 7...
  • Page 86 PCA-6006 User’s Manual...
  • Page 87 Ultra ATA Storage Driver Setup This driver must be installed to use the Intel ® Ultra ATA controller to improve storage subsystem performance and overall system performance. Chapter 8...

  • Page 88: Chapter 8 Ultra Ata Storage Driver Setup

    ATA controller cable, where one is the master and the other the slave, without restricting transfer mode to PIO-only for both devices. • Technical details of the ATA subsystem can be viewed via use of the application. • Drivers are optimized. PCA-6006 User’s Manual...

  • Page 89: Window 2000 Setup Procedure

    8.3 Window 2000 Setup Procedure Note: Before installing this driver, make sure the CSI utility has been installed in your system. See Chapter 4 for information on installing the CSI utility. Insert the driver CD into your system's CD-ROM drive. In a few seconds, the software installation main menu appears, as shown in the following figure.
  • Page 90 Click on "Next" when you see the following message. When you see the following message, click on "Yes" to accept the License Agreement. PCA-6006 User’s Manual...
  • Page 91 Click on "Next" when you see the following message. When the following message appears, click "Finish" to complete the installation and restart Windows. Chapter 8...

  • Page 92: Displaying Driver Information

    8.4 Displaying Driver Information From the desktop of Windows, click on "Start" and select "Pro- grams." Then select "Intel Ultra ATA Storage Driver" and then "Companion." Click on the "Device Parameters" or the "Storage Report" tab to view related information. PCA-6006 User’s Manual...

  • Page 93: Nt Setup Procedure

    8.5 NT Setup Procedure Insert the driver CD into your system's CD-ROM drive. In a few seconds, the software installation main menu appears, as shown in the following figure. Under the "IDE DRIVERS" heading, click on the "Install" button. Chapter 8...
  • Page 94 Click on "Next" when you see the following message. When you see the following message, click on "Yes" to accept the License Agreement. PCA-6006 User’s Manual...
  • Page 95 When the following message appears, click "Finish" to complete the installation and restart Windows. Chapter 8...
  • Page 96 PCA-6006 User’s Manual...

  • Page 97: Chapter 9 Onboard Security Setup

    Onboard Security Setup This chapter explains OBS concepts and provides instructions for installing the relevant software drivers. This is done using the driver CD included in your PCA-6006 package. Chapter 9...

  • Page 98: Introduction

    The PCA-6006's hardware monitor is designed with Winbond W83782D. Onboard security (OBS) functions monitor key hardware. They help you maintain your system's stability and durability. The PCA-6006 can moni- tor 5 sets of system positive voltages, 2 sets of system negative voltages, CPU cooling fan speed, and CPU temperature.

  • Page 99: Windows 9X Drivers Setup Procedure

    9.2 Windows 9X Drivers Setup Procedure Insert the driver CD into your system's CD-ROM drive. In a few seconds, the software installation main menu appears, as shown in the following figure. Click on the "WIN 9X" button under the "OBS DRIVERS" heading. When you will see the following message, make sure you have closed all other programs, then click on "OK."...
  • Page 100 Click on the square graphics button when you see the following message. When you see the following message, click on "OK" to complete the installation. PCA-6006 User’s Manual...

  • Page 101: Windows 2000/Nt Drivers Setup Procedure

    9.3 Windows 2000/NT Drivers Setup Procedure Insert the driver CD into your system's CD-ROM drive. In a few seconds, the software installation main menu appears, as shown in the following figure. Click on the "WIN NT" button under the "OBS DRIVERS" heading. Click "Next"...
  • Page 102 Click "Next" when you see the following message. Click "Next" when you see the following message. PCA-6006 User’s Manual...
  • Page 103 Click "Finish" when you see the following message. Click "OK" to restart Windows. Chapter 9...

  • Page 104: Using The Obs Hardware Doctor Utility

    "OBS Hardware Doctor." It is recommended that you load the default values for all the OBS settings. However, if desired, you can establish new conditions for voltage, fan speed, and temperature. For TRANS_VCC, low limit PCA-6006 User’s Manual...
  • Page 105 and high limit have to be adjusted manually. Please set low limit at 1.70V and high limit at 1.90V. Chapter 9...
  • Page 106 PCA-6006 User’s Manual...
  • Page 107 Programming the Watchdog Timer The PCA-6006 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.

  • Page 108: Appendix A Programming The Watchdog Timer

    Appendix A Programming the watchdog timer A.1 Programming the Watchdog Timer The PCA-6006's watchdog timer can be used to monitor system software operation and take corrective action if the software fails to function after the programmed period. This section describes the operation of the watchdog timer and how to program it.
  • Page 109 Unlock W83627H Select register of watchdog timer Enable the function of the watchdog timer Use the function of the watchdog time Lock W83627HF Appendix A...
  • Page 110 (hex). This number decides how long the watchdog timer waits for strobe before generating an inter- rupt or reset signal. Writing a new value to this register can reset the timer to count with the new value. PCA-6006 User’s Manual...

  • Page 111: Example Program

    F7 (hex) read/write Bit 6: Write 1 to enable key- board to reset the timer, 0 to disable.[default] Bit 5: Write 1 to generate a timeout signal immediately and automatically return to 0. [default=0] Bit 4: Read status of watch- dog timer, 1 means timer is ""time out""."...
  • Page 112 Enable watchdog timer and set 5 minutes as timeout interval ;----------------------------------------------------------- Mov dx,2eh ; unlock W83627H Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Mov al,08h Out dx,al PCA-6006 User’s Manual...
  • Page 113 ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Set minute as counting unit Mov al,0f5h Out dx,al al,dx Or al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Set timeout interval as 5 minutes and start counting Mov al,0f6h Out dx,al Mov al,5...
  • Page 114 Mov al,0f7h Out dx,al al,dx Or al,80h Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al Enable watchdog timer to be reset by keyboard ;----------------------------------------------------------- Mov dx,2eh ; unlock W83627H Mov al,87h Out dx,al PCA-6006 User’s Manual...
  • Page 115 Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable watchdog timer to be strobed reset by keyboard Mov al,0f7h Out dx,al al,dx...
  • Page 116 Out dx,al ;----------------------------------------------------------- Dec dx ; Generate a time-out signal Mov al,0f7h Out dx,al ;Write 1 to bit 5 of F7 register al,dx Or al,20h Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al PCA-6006 User’s Manual...
  • Page 117 I/O Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • IDE Hard Drive Connector • Floppy Drive Connector • Parallel Port Connector • USB Connector • VGA Connector • Ethernet 10/100Base-T RJ-45 Con- nector •...

  • Page 118: Appendix B Pin Assignments

    DATA 0 DATA 15 SIGNAL GND DISK DMA REQUEST IO WRITE IO READ IO CHANNEL READY HDACKO* IRQ14 ADDR 1 ADDR 0 ADDR 2 HARD DISK SELECT 0* HARD DISK SELECT 1* IDE ACTIVE* * low active PCA-6006 User’s Manual...

  • Page 119: Floppy Drive Connector (Cn3)

    B.2 Floppy Drive Connector (CN3) Table B.2: Floppy drive connector (CN3) Signal Signal FDHDIN* FDEDIN* INDEX* MOTOR 0* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* GND2 WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE* * low active Appendix B...

  • Page 120: Parallel Port Connector (Cn4)

    B.3 Parallel Port Connector (CN4) Table B.3: Parallel port connector (CN4) Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * low active PCA-6006 User’s Manual...

  • Page 121: Usb Connector (Cn6)

    B.4 USB Connector (CN6) Table B.4: USB1/USB2 connector (CN6) USB1 Signal USB2 Signal +5 V +5 V Chassis GND B.5 VGA Connector (CN7) Table B.5: Table B-6: VGA connector (CN7) Signal Signal GREEN BLUE H-SYNC V-SYNC Appendix B...

  • Page 122: Com1/Com2 Rs-232 Serial Port (Cn9, Cn10)

    B.6 Ethernet 10/100Base-T RJ-45 Connector (CN8, CN34) CN8 and CN34 Table B.6: Ethernet 10/100Base-T RJ-45 connector (CN8, CN34) Signal Signal XMT+ XMT- RCV- RCV+ B.7 COM1/COM2 RS-232 Serial Port (CN9, CN10) Table B.7: COM1/COM2 RS-232 serial port (CN9, CN10) Signal PCA-6006 User’s Manual...

  • Page 123: Keyboard And Mouse Connnector (Cn11)

    B.8 Keyboard and Mouse Connnector (CN11) Table B.8: Keyboard and mouse connector (CN11) Signal KB DATA MS DATA KB CLOCK MS CLOCK B.9 External Keyboard Connector (CN12) Table B.9: External keyboard connector (CN12) Signal DATA Appendix B...

  • Page 124: Ir Connector (Cn13)

    B.10 IR Connector (CN13). Table B.10: IR connector (CN13) Signal Signal +5 V IR_RX IR_TX B.11 CPU Fan Power Connector (CN14) Table B.11: CPU fan power connector (CN14) Signal +12 V Detect PCA-6006 User’s Manual...

  • Page 125: Power Led And Keyboard Lock (Cn16)

    B.12 Power LED and Keyboard Lock (CN16) You can use an LED to indicate when the CPU card is on. Pin 1 of CN16 supplies the LED's power, and Pin 3 is the ground. Table B.12: Power LED and keylock connector (CN16) Function LED power (+5 V) Keyboard Lock...

  • Page 126: Reset Connector (Cn18)

    B.14 Reset Connector (CN18) Table B.14: Reset connector (CN18) Signal RESET B.15 HDD LED Connector (CN19) Table B.15: HDD LED connector (CN19) Signal Vcc(LED+) LED0 (LED-) PCA-6006 User’s Manual...

  • Page 127: Atx Feature Connector (Cn20)

    B.16 ATX Feature Connector (CN20) Table B.16: ATX feature connector (CN20) Signal PS-ON VCCSB B.17 ATX Soft Power Switch (CN21)) Table B.17: ATX soft power switch (CN21) Signal 5VSB PWR-BTN Appendix B...

  • Page 128: H/W Monitor Alarm (Cn22)

    TX0- (DVI) FP_SDAT (DVI) TXD+ (LAN2) FP_SCLK (DVI) H_DEC (DVI) RXIN+ (LAN2) FP_VCC (DVI) TXD- (LAN2) TX2+ (DVI) MS DATA (PS/2 MS) TX2- (DVI) RXIN- (LAN2) TX1+ (DVI) MS CLOCK (PS/2 MS) TX1- (DVI) MS_VCC (PS/2 MS) PCA-6006 User’s Manual...

  • Page 129: Ps/2 Mouse Connector (Cn33)

    B.21 PS/2 Mouse Connector (CN33) Table B.21: PS/2 mouse connector (CN33) Signal MS DATA MS CLOCK B.22 AC-97 Audio Interface (CN43) Table B.22: System I/O ports 1 VCC 2 GND 3 SYNC 4 BITCLK 5 SDOUT 6 SDIN 7 SDIN2 8 -ACRST 9 +12V 10 GND...

  • Page 130: System I/O Ports

    Prototype card 360-36F Reserved 378-37F Parallel printer port 1 (LPT2) 380-38F SDLC, bisynchronous 2 3A0-3AF Bisynchronous 1 3B0-3BF Monochrome display and printer adapter (LPT1) 3C0-3CF Reserved 3D0-3DF Color/graphics monitor adapter 3F0-3F7 Diskette controller 3F8-3FF Serial port 1 PCA-6006 User’s Manual...

  • Page 131: Dma Channel Assignments

    B.24 DMA Channel Assignments Table B.24: DMA channel assignments Channel Function Available Available Floppy disk (8-bit transfer) Available Cascade for DMA controller 1 Available Available Available B.25 Interrupt Assignments Table B.25: Interrupt assignments Priority Interrupt# Interrupt source Parity error detected IRQ0 Interval timer IRQ1...
  • Page 132 INT B, C, D, A GNT A PCI slot 2 AD30 INT C, D, A, B GNT B PCI slot 3 AD29 INT D, A, B, C GNT C PCI slot 4 AD28 INT A, B, C, D GNT D PCA-6006 User’s Manual...
