  • Page 1 PCA-6180- B ® Full-size socket 370 Intel ® ™ Tualatin / Pentium III / Celeron processor based PCI/ISA-bus CPU card...

  • Page 3: Copyright Notice

    Copyright notice This document is copyrighted, 2001, by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improve- ments to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.

  • Page 4: A Message To The Customer

    A Message to the Customer Advantech customer services Each and every Advantech product is built to the most exacting specifications to ensure reliable performance in the harsh and demanding conditions typical of industrial environments. Whether your new Advantech equipment is destined for the laboratory or the...
  • Page 5 PCA-6180 Rev. A Series comparison table l e t ® u i t ® / I I V V V V V V V V V V V V V V V V V V V V ™ V V V V V V V V V V V V V V V V V V V V...
  • Page 6 PCA-6180 Rev. B Series comparison table ® ® l e t n i t u i t I I I V V V V V V V V V V V V V V V V V V V V r e l ™...

  • Page 7: Product Warranty

    Advantech assumes no liability under the terms of this warranty as a consequence of such events. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.

  • Page 8: Initial Inspection

    It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the PCA-6180-B, check it for signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.

  • Page 9: Table Of Contents

    Contents Chapter 1 Hardware Configuration ......1 Introduction ............... 2 Features ................3 Specifications ..............5 1.3.1 System ................. 5 1.3.2 Memory ............... 5 1.3.3 Input/Output ..............5 1.3.4 VGA interface ............. 6 1.3.5 SCSI interface ............. 6 1.3.6 Ethernet LAN ............. 6 1.3.7 Industrial features ............
  • Page 10 Floppy Drive Connector (CN3) ........23 Parallel Port (CN4) ............23 SCSI Connector (CN5) ..........24 USB Ports (CN31 and CN32) ........25 VGA Connector (CN7) ..........25 10/100Base-T Ethernet Connectors (CN8 and CN34) Serial Ports (CN9: COM1; CN10: COM2) ....26 2.10 PS/2 Keyboard and Mouse Connectors (CN11 and CN33) .................
  • Page 11 3.4.4 Quick Power On Self Test ........37 3.4.5 First/Second/Third/Other Boot Device ...... 37 3.4.6 Swap Floppy Drive ............ 37 3.4.7 Boot UP Floppy Seek ..........37 3.4.8 Boot Up NumLock ............ 37 3.4.9 Gate A20 Option ............38 3.4.10 Typematic Rate Setting ........... 38 3.4.11 Typematic Rate (Chars/Sec) ........
  • Page 12 3.6.10 UART Mode Select..........44 3.6.11 RxD, TxD Active ............ 44 3.6.12 IR Transmission Delay ..........44 3.6.13 UR2 Duplex Mode ..........44 3.6.14 Use IR Pins ............. 45 3.6.15 Onboard Parallel Port (378H/IRQ7) ....... 45 3.6.16 Parallel Port Mode (ECP + EPP) ......45 3.6.17 EPP Mode Select ............
  • Page 13 Before You Begin ............54 Introduction ..............54 Installing the CSI Utility ..........56 Chapter 5 AGP SVGA Setup ........59 Introduction ..............60 Installation ............... 60 Chapter 6 LAN Configuration ........65 Introduction ..............66 Features ................66 Installation ............... 67 Windows 95/98/2000 Drivers Setup Procedure ..
  • Page 14 Appendix B Pin Assignments ........117 B.1 IDE Hard Drive Connector (CN1, CN2) ....118 B.2 Floppy Drive Connector (CN3) ........119 B.3 Parallel Port Connector (CN4) ........120 B.4 SCSI Connector (CN5) ..........121 B.5 USB Connector (CN6)..........122 B.6 VGA Connector (CN7) ..........
  • Page 15 Figures Figure 1-1: Board layout: main features ................ 8 Figure 1-2: Rear plate ....................9 Figure 1-3: Location of jumpers and connecters ............12 Figure 3-1: Awards BIOS setup initial screen ............. 34 Figure 3-2: Standard CMOS features screen ............... 35 Figure 3-3: Awards BIOS features screen (1) ..............
  • Page 16 Tables Table 1-1: Jumpers ......................9 Table 1-2: Connectors ....................10 Table 1-3: CMOS clear (J1) .................... 14 Table 1-4: Watchdog timer output (J2) ................15 Table 1-5: DIMM module allocation table ................. 16 Table 1-6: DIMM memory capacity sample calculation ..........16 Table 2-1: Serial port connections (COM1, COM2) ............

  • Page 17: Chapter 1 Hardware Configuration

    Hardware Configuration This chapter gives background informa- tion on the PCA-6180. It then shows you how to configure the card to match your application and prepare it for installation into your PC. Sections include: • Introduction • Features • Specifications •...

  • Page 18: Introduction

    Introduction The PCA-6180 Rev. B Series all-in-one industrial grade CPU card uses Intel 's highly acclaimed Tualatin/Pentium III / Celeron processor, ® ® ™ together with the Intel 815E (B)chipset. The card works with stan- ® dard ISA- or PCI/ISA-bus passive backplanes. The CPU provides 512/256/128 KB on-CPU L2 cache, eliminating the need for external SRAM chips.

  • Page 19: Features

    Features 1. Fan status monitoring and alarm: To prevent system overheating and damage, the CPU fan can be monitored for speed and failure. The fan is set for its normal RPM range and alarm thresholds. 2. Temperature monitoring and alert: To prevent system overheating and damage, the CPU card supports processor thermal sensing and auto-protection.
  • Page 20 9. CMOS RAM backup: When BIOS CMOS setup has been complet- ed, data in the CMOS RAM is automatically backed up to the Flash ROM. This is particularly useful in industrial environments which may cause soft errors. Upon such an error, BIOS will check the data and automatically restore the original data for rebooting.

  • Page 21: Specifications

    Specifications 1.3.1 System • CPU: PCA-6180 Rev B: Intel Tualatin processor up to 1.26 GHz, Intel Pentium III processor up to 1 GHz, and Celeron up to 800 MHz • Firmware hub: Provides security enhancements on computer platforms by supporting Random Number Generator (RNG). •...

  • Page 22: Vga Interface

    • Keyboard and PS/2 mouse connector: Two 6-pin mini-DIN connector is located on the mounting bracket for easy connection to a keyboard or a PS/2 mouse. An onboard keyboard pin header connector is also available. • HISA : ISA bus high-driving capability up to 64 mA. ®...
  • Page 23 • Storage temperature: 0°~ 60° C (32° ~ 140° F). • Humidity: 20 ~ 95% non-condensing. • Power supply voltage: +5 V, ±12 V. • Power consumption (depends on CPU and memory): +5V @ 6.5A, -5V @30mA, +12V @225mA, -12V @50mA ( Tualatin 1.2 GHz, 128 MB SDRAM) •...

  • Page 24: Figure 1-1: Board Layout: Main Features

    Figure 1-2: Board layout: main features (PCA-6180 Rev. B) PCA-6180 User's Manual...

  • Page 25: Figure 1-2: Rear Plate

    Figure 1-3: PCA-6180-B Chapter 1 Hardware Configuration...

  • Page 26: Jumpers And Connectors

    Jumpers and Connectors Connectors on the PCA-6180 board link it to external devices such as hard disk drives and a keyboard. In addition, the board has a number of jumpers used to configure your system for your application. The tables below list the function of each of the board jumpers and connectors.
  • Page 27 CN16 Keyboard lock and power LED CN17 External speaker CN18 Reset connector CN19 HDD LED connector CN20 ATX feature connector CN21 ATX soft power switch CN22 H/W monitor alarm: close - enable OBS alarm open - disable OBS alarm CN23 SM bus connector CN27 Connector to extension I/O board...

  • Page 28: Location Of Jumpers And Connectors

    Location of Jumpers and Connectors Figure 1-3: Location of jumpers and connecters Note: See Chapter 2 for the location of CN31~CN34. PCA-6180 User's Manual...

  • Page 29: Safety Precautions

    Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. Caution! Always ground yourself to remove any static charge before touching the CPU card.

  • Page 30: Jumper Settings

    Jumper Settings This section provides instructions on how to configure your card by setting the jumpers. It also includes the card's default settings and your options for each jumper. 1.8.1 How to set the jumpers You configure your card to match the needs of your application by setting the jumpers.

  • Page 31: Watchdog Timer Output (J2)

    1.8.3 Watchdog timer output (J2) The PCA-6180 contains a watchdog timer that will reset the CPU or send a signal to IRQ11 in the event the CPU stops processing. This feature means the PCA-6180 will recover from a software failure or an EMI problem.

  • Page 32: System Memory

    System Memory The top-left edge of the PCA-6180 contains three sockets for 168-pin dual in-line memory modules (DIMMs). All three sockets use 3.3 V unbuffered synchronous DRAMs (SDRAM). DIMMs are available in capacities of 16, 32, 64, 128, or 256 MB. The sockets can be filled in any combination with DIMMs of any size, giving your PCA-6180 single board computer between 16 MB and 512 MB of memory.

  • Page 33: Supplementary Information About Dimms

    1.9.2 Supplementary information about DIMMs Your PCA-6180 can accept SDRAM memory chips (with or without parity). Also note: • If the PCA-6180 operates at 133 MHz, only use PC/133-compliant DIMMs. Most systems will not even boot if non-compliant modules are used. This is due to strict timing issues involved at this speed. •...

  • Page 34: Memory Installation Procedures

    1.10 Memory Installation Procedures To install DIMMs, first make sure the two handles of the DIMM socket are in the "open" position (i.e., the handles lean outward). Slowly slide the DIMM module along the plastic guides on both ends of the socket. Then press the DIMM module right down into the socket, until you hear a click.

  • Page 35: Cpu Installation

    1.12 CPU Installation The PCA-6180 provides a socket 370 for an Intel FC-PGA Pen- ® tium III processor. The CPU on the board must have a fan or heat ® sink attached to prevent overheating. Warning: Without a fan or heat sink, the CPU will overheat and cause damage to both the CPU and the moth- erboard.

  • Page 37: Chapter 2 Connecting Peripherals

    Connecting Peripherals This chapter tells how to connect peripherals, switches, and indicators to the PCA-6180 board.

  • Page 38: Introduction

    Introduction You can access most of the connectors from the top of the board while it is installed in the chassis. If you have a number of cards installed or have a packed chasis, you may need to partially remove the card to make all the connections.

  • Page 39: Floppy Drive Connector (Cn3)

    Connect the first hard drive to the other end of the cable. Wire 1 on the cable should also connect to pin 1 on the hard drive connector, which is labeled on the drive circuit board. Check the documentation that came with the drive for more information. Connect the second hard drive to the remaining connector (CN2 or CN1), in the same way as described above.

  • Page 40: Scsi Connector (Cn5)

    The parallel port is normally used to connect the CPU card to a printer. The PCA-6180 includes an onboard parallel port, accessed through a 26-pin flat-cable connector, CN4. The card comes with an adapter cable which lets you use a traditional DB-25 connector. The cable has a 26-pin connector on one end and a DB-25 connector on the other, mounted on a retaining bracket.

  • Page 41: Usb Ports (Cn31 And Cn32)

    USB Ports (CN31 and CN32) The PCA-6180 provides four ports of USB (Universal Serial Bus) interface, which gives complete Plug & Play and hot swapping for up to 127 external devices.The USB interface complies with USB Specification Rev. 1.0 and is fuse-protected. The USB interface can be disabled in the system BIOS setup.

  • Page 42: 10/100Base-T Ethernet Connectors (Cn8 And Cn34)

    10/100Base-T Ethernet Connectors (CN8 and CN34) The PCA-6180 is equipped with one or two high-performance 32-bit PCI-bus Ethernet interfaces, which are fully compliant with IEEE 802.3/u 10/100 Mbps CSMA/CD standards. They are supported by all major network operating systems and are 100% Novell NE-2000 compatible.

  • Page 43: Table 2-1: Serial Port Connections (Com1, Com2)

    The PCA-6180 offers two serial ports, CN9 as COM1 and CN10 as COM2. These ports can connect to serial devices, such as a mouse or a printer, or to a communications network. Table 2-1: Serial port connections (COM1, COM2) Connector Ports Address Interrupt...

  • Page 44: Ps/2 Keyboard And Mouse Connectors (Cn11 And Cn33)

    PS/2 keyboard and a PS/2 mouse, respectively. CN11 can also be connected to an adapter cable (P/N: 1700060202, available from Advantech) for connecting to both a PS/ 2 keyboard and a PS/2 mouse. 2.11 External Keyboard Connector (CN12)

  • Page 45: Infrared (Ir) Connector (Cn13)

    2.12 Infrared (IR) Connector (CN13) This connector supports the optional wireless infrared transmitting and receiving module. This module mounts on the system case. You must configure the setting through the BIOS setup (see Chapter 3). 2.13 CPU Fan Connector (CN14) This connector supports cooling fans of 500 mA (6 W) or less.

  • Page 46: Front Panel Connectors (Cn16, Cn17, Cn18, Cn19, Cn21 And Cn22)

    2.14 Front Panel Connectors (CN16, CN17, CN18, CN19, CN21 and CN22) There are several external switches to monitor and control the PCA-6180. 2.14.1 Keyboard lock and power LED (CN16) CN16 is a 5-pin connector for the keyboard lock and power on LED. Refer to Appendix B for detailed information on the pin assignments.

  • Page 47: Hdd Led (Cn19)

    2.14.4 HDD LED (CN19) You can connect an LED to connector CN19 to indicate when the HDD is active. 2.14.5 ATX soft power switch (CN21) If your computer case is equipped with an ATX power supply, you should connect the power on/off button on your computer case to CN21.

  • Page 48: Controlling The Soft Power Switch

    Warnings: 1. Make sure that you unplug your power supply when adding or removing expansion cards or other system components. Failure to do so may cause severe damage to both your CPU card and expansion cards. 2. ATX power supplies may power on if certain motherboard components or connections are touched by metallic objects.

  • Page 49: Chapter 3 Award Bios Setup

    Award BIOS Setup This chapter describes how to set the card’s BIOS configuration data.

  • Page 50: Introduction

    CPU. If there is no number assigned to the patch code, please contact Advantech’s applications engineer to obtain an up-to-date patch code file. This will ensure that your CPU’s system status is valid. After ensuring that you have a number assigned to the patch code, press <Del>...

  • Page 51: Standard Cmos Setup

    Standard CMOS Setup Choose the “Standard CMOS Features” option from the “Initial Setup Screen” menu, and the screen below will be displayed. This menu allows users to configure system components such as date, time, hard disk drive, floppy drive, display, and memory. Figure 3-2: Standard CMOS features screen 3.3.1 CMOS RAM backup The CMOS RAM is powered by an onboard button cell battery.

  • Page 52: Advanced Bios Features

    Advanced BIOS Features The “Advanced BIOS Features” screen appears when choosing the “Advanced BIOS Features” item from the “Initial Setup Screen” menu. It allows the user to configure the PCA-6180 according to his particular requirements. Below are some major items that are provided in the Advanced BIOS Features screen.

  • Page 53: Cpu L2 Cache Ecc Checking

    3.4.3 CPU L2 Cache ECC Checking Enabling allows CPU L2 cache checking. The commands are “En- abled” or “Disabled.” 3.4.4 Quick Power On Self Test This option speeds up the Power On Self Test (POST) conducted as soon as the computer is turned on. When enabled, BIOS shortens or skips some of the items during the test.

  • Page 54: Gate A20 Option

    3.4.9 Gate A20 Option Normal The A20 signal is controlled by the keyboard controller. Fast (Default) The A20 signal is controlled by the chipset. 3.4.10 Typematic Rate Setting The typematic rate is the rate key strokes repeat as determined by the keyboard controller.

  • Page 55: Os Select For Dram > 64Mb

    3.4.14 OS Select for DRAM > 64MB This setting allows selecting an OS with greater than 64MB of RAM. Commands are “Non-OS2” or “OS2.” 3.4.15 Report No FDD For Win 95 This reports if an FDD is available for Windows 95. The commands are “Yes”...

  • Page 56: Sdram Cas Latency Time

    Figure 3-5: Advanced chipset features screen 3.5.1 SDRAM CAS Latency Time This controls the latency between SDRAM read command and the time that the data actually becomes available. Leave this on the default setting. 3.5.2 SDRAM Cycle Time Tras/Trc This selects the number of SCLKs for an access cycle. 3.5.3 SDRAM RAS-to-CAS Delay This controls the latency between SDRAM active command and the read/write command.

  • Page 57: System Bios Cacheable

    3.5.5 System BIOS Cacheable Selecting Enabled allows caching of the system BIOS ROM at F0000h-FFFFFh, resulting in better system performance. However, if any program writes to this memory area, a system error may occur. The Choices: Enabled, Disabled. 3.5.6 Video Bios Cacheable Selecting Enabled allows caching of the video BIOS, resulting in better system performance.

  • Page 58: On-Chip Video Window Size

    3.5.11 On-Chip Video Window Size This selects the on-chip video window size for VGA drives use. The Choices: 32MB, 64MB, Disabled. Integrated Peripherals 3.6.1 On-Chip Primary/Secondary PCI IDE If you enable IDE HDD Block Mode, the enhanced IDE driver will be enabled.

  • Page 59: Usb Controller

    3.6.3 USB Controller Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have USB peripherals. The choices: Enabled, Disabled. 3.6.4 USB Keyboard Support Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have a USB keyboard. The choices: Enabled, Disabled.

  • Page 60: Uart Mode Select

    3.6.10 UART Mode Select This item allows you to select UART mode. The choices: IrDA, ASKIR, Normal. Figure 3-7: Integrated peripherals (2) 3.6.11 RxD, TxD Active This item allows you to determine the active of RxD, TxD. The Choices: “Hi, Hi,” “Lo, Lo,” “Lo, Hi,” “Hi, Lo.” 3.6.12 IR Transmission Delay This item allows you to enable/disable IR transmission delay.

  • Page 61: Use Ir Pins

    3.6.14 Use IR Pins This item allows you to select IR transmission routes, one is RxD2, TxD2 (COM Port) and the other is IR-Rx2Tx2. The choices: IR- Rx2Tx2, RxD2,TxD2. 3.6.15 Onboard Parallel Port (378H/IRQ7) This field sets the address of the on-board parallel port connector. You can select either 3BCH/IRQ7, 378H/IRQ7, 278H/IRQ5 or Disabled.

  • Page 62: Power Management Setup

    Power Management Setup The power management setup controls the CPU card’s “green” features to save power. The following screen shows the manufactur- er’s defaults: Figure 3-8: Power management setup screen (1) 3.7.1 Power Management This option allows you to determine if the values in power management are disabled, user-defined, or predefined.

  • Page 63: Poweron By Lan

    You can choose “Delay 4 sec.” If you do, then pushing the button for more than 4 seconds will turn off the system, whereas pushing the button momentarily (for less than 4 seconds) will switch the system to “suspend” mode. 3.7.4 PowerOn By LAN This item allows you to wake up the system via LAN from the remote host.

  • Page 64: Pnp/Pci Configurations

    Figure 3-9 Power Management (2) PnP/PCI Configurations 3.8.1 Resources controlled by: The commands here are “Auto” or “Manual.” Choosing “manual” requires you to choose resources from each following sub-menu. “Auto” automatically configures all of the boot and Plug and Play devices but you must be using Windows 95 or above.

  • Page 65: Reset Configuration Data

    Figure 3-10: PnP/PCI configurations screen 3.8.3 Reset Configuration Data Note: This is left “Disabled.” Select “Enabled” to reset Extended System Configuration Data (ECSD) if you have installed a new add-on and your OS won’t boot and you need to reconfigure. 3.8.4 PCI/VGA Palette Snoop This is left at “Disabled.”...

  • Page 66: Current Cpu Temperature

    Figure 3-11: PC health status screen 3.9.3 Current CPU Temperature This shows you the current CPU1 temperature. 3.9.4 Current CPUFAN Speed This shows you the current CPUFAN operating speed. 3.9.5 +5V/+12V/-12V/-5V This shows you the voltage of +5V/+12V/-12V/-5V. 3.9.6 Shutdown Temperature This item allows you to set up the CPU shutdown Temperature.

  • Page 67: Load Setup Defaults

    3.10 Load Setup Defaults “LOAD SETUP DEFAULTS” loads the values required by the system for maximum performance. 3.11 Password Setting To change the password: 1. Choose the “Set Password” option from the “Initial Setup Screen” menu and press <Enter>. The screen will display the following message: Enter Password: Press <Enter>.

  • Page 68: Save & Exit Setup

    3.12 Save & Exit Setup If you select this and press <Enter>, the values entered in the setup utilities will be recorded in the CMOS memory of the chipset. The microprocessor will check this every time you turn your system on and compare this to what it finds as it checks the system.

  • Page 69: Chapter 4 Chipset Software Installation (Csi) Utility

    Chipset Software Instal- lation (CSI) Utility This utility software installs to the Windows INF files that outline to the operating system how the components will be configured. This utility has to be installed before other drivers.

  • Page 70: Before You Begin

    Before You Begin To facilitate the installation of the enhanced display device drivers and utility software, you should read the instructions in this chapter carefully before you attempt installation. The device drivers for the PCA-6180 board are located on the software installation CD. The auto- run function of the driver CD will guide and link you to the utilities and device drivers under a Windows system.
  • Page 71 Note: This utility is used for the following versions of Windows system, and it has to be installed before installing all the other drivers: Windows 95 4.00.950 (Original release) Windows 95 4.00.950a (OSR1) Windows 95 4.00.950b (OSR2 without USB Supplement) Windows 95 4.00.950b (OSR2.1 with USB Supplement) Windows 95...

  • Page 72: Installing The Csi Utility

    Installing the CSI Utility 1. Insert the driver CD into your system's CD-ROM drive. In a few seconds, the software installation main menu appears. Move the mouse cursor over the "Auto" button under the "CSI UTILITY" heading, a message pops up telling you to install the CSI utility before other device drivers, as shown in the following figure.
  • Page 73 2. Click "Next" when you see the following message. 3. Click "Yes" when you see the following message. Chapter 4 Chipset Software Installation (CSI) Utility...
  • Page 74 4. Click "Next" when you see the following message. 5. When the following message appears, click "Finish" to complete the installation and restart Windows. PCA-6180 User's Manual...

  • Page 75: Chapter 5 Agp Svga Setup

    AGP SVGA Setup The PCA-6180 features an integrated AGP SVGA interface. This chapter provides instructions for installing the AGP SVGA drivers from the driver CD included in your package.

  • Page 76: Introduction

    Introduction AGP (Accelerated Graphics Port) is a graphics interface that pro- vides faster connection between the display card and memory than a ® PCI slot. Your PCA-6180 CPU card uses the Intel 815 chipset that supports AGP SVGA. The features include: •...
  • Page 77 2. Click "Next" when you see the following message. Chapter 5 AGP SVGA Setup...
  • Page 78 3. Click "Next" when you see the following message. 4. Click "Finish" when you see the following message. PCA-6180 User's Manual...
  • Page 79 5. Click "Yes" to accept the License Agreement. 6. When the following message appears, click "Finish" to complete the installation and restart Windows. Chapter 5 AGP SVGA Setup...

  • Page 81: Chapter 6 Lan Configuration

    LAN Configuration The PCA-6180 supports dual 10/ 100Base-T Ethernet networking with one ® chipset integrated LAN controller (Intel ® 82562ET) and one Intel GD82559 (optional). This chapter gives detailed information on Ethernet configuration. It shows you how to configure the card to match your application requirements.

  • Page 82: Introduction

    Introduction The PCA-6180 features the 32-bit 10/100 Mbps Ethernet network interface. This interface supports bus mastering architecture and auto-negotiation features. Therefore standard twisted-pair cabling with RJ-45 connectors for both 10 Mbps and 100 Mbps connections can be used. Extensive driver support for commonly-used network systems is also provided.

  • Page 83: Installation

    Installation Note: Before installing the LAN drivers, make sure the CSI utility has been installed in your system. See Chapter 4 for information on installing the CSI utility. The PCA-6180's onboard Ethernet interface supports all major network operating systems. However, the installation procedure varies with different operating systems.

  • Page 84: Windows 95/98/2000 Drivers Setup Procedure

    Windows 95/98/2000 Drivers Setup Procedure Note: The CD-ROM drive is designated as "D" throughout this section. 1. From the desktop of Windows 95/98/2000, click on "Start" and select "Settings." Then click on the "Control Panel" icon to select "System." PCA-6180 User's Manual...
  • Page 85 2. In the "System Properties" window, select the "Device Manager" tab. Select "View devices by type," and navigate to: Computer\Other devices. Highlight "PCI Ethernet Controller" and click on "Properties." Chapter 6 LAN Configuration...
  • Page 86 3. In the "PCI Ethernet Controller Properties" window, select the "Driver" tab. Then click on "Update Driver..." 4. In the "Update Device Driver Wizard" window, click on "Next." PCA-6180 User's Manual...
  • Page 87 5. In the "Update Device Driver Wizard" window, select "Search for a better driver than the one your device is using now. (Recom- mended)." Then click on "Next." 6. In the following "Update Device Driver Wizard" window, click on "Browse." Chapter 6 LAN Configuration...
  • Page 88 7. In the "Browse for Folder" window, navigate to the CD-ROM drive and click on the "82562" folder. Then click on "OK." 8. In the following "Update Device Driver Wizard" window, click on "Next." PCA-6180 User's Manual...
  • Page 89 9. In the following "Update Device Driver Wizard" window, click on "Next." 10. In the following "Update Device Driver Wizard" window, click on "Finish." Chapter 6 LAN Configuration...
  • Page 90 11. In the "System Settings Change" window, click on "Yes" to complete the installation and restart Windows. PCA-6180 User's Manual...

  • Page 91: Windows Nt Drivers Setup Procedure

    Windows NT Drivers Setup Procedure Note: The CD-ROM drive is designated as "D" throughout this section. 1. From the desktop of Windows NT, click on "Start" and select "Settings." Then click on the "Control Panel" icon to select "System." 2. In the "Network" window, select the "Adapters" tab. Then click on "Add..."...
  • Page 92 3. In the "Select Network Adapter" window, click on "Have Disk..." 4. When the "Insert Disk" window appears, insert the driver CD into the CD-ROM drive and type in "d:\drv_lan\82562." When you have the correct file path, click on "OK." PCA-6180 User's Manual...
  • Page 93 5. In the "Select OEM Option" window, click on "OK." 6. In the "Network" window, select the "Adapters" tab. Under "Network Adapters," highlight "[2] Intel(R) PRO/100+ Manage- ment Adapter" and "[3] Intel(R) PRO/100 VE Network Connec- tion." Then click on "Close." Chapter 6 LAN Configuration...

  • Page 94: Windows 98Se/Me Drivers Setup Procedure

    Windows 98SE/ME Drivers Setup Procedure Note: The CD-ROM drive is designated as "D" throughout this section. For computers using Windows 98SE or Windows ME, the operating system will automatically install the "Intel(R) Pro/100+ Management Adapter" driver the first time it detects the LAN device. If your CPU card has two Ethernet ports and you are experiencing problems with LAN connections (one of the ports does not work) after you have installed drivers for both LANs, perform the following steps to...
  • Page 95 2. In the "System Properties" window, select the "Device Manager" tab. Select "View devices by type," and navigate to: Computer\Network adapters. Highlight "Intel(R) PRO/100+ Management Adapter" and click on "Properties." Chapter 6 LAN Configuration...
  • Page 96 3. In the "Intel(R) PRO/100+ Management Adapter Properties" window, select the "Driver" tab. Then click on "Update Driver..." 4. In the "Update Device Driver Wizard" window, click on "Specify the location of the driver (Advanced)" and then click on "Next." PCA-6180 User's Manual...
  • Page 97 5. In the following "Update Device Driver Wizard" window, select "Search for a better driver than the one your device is using now. (Recommended)." Select "Specify a location:" and then click on "Browse." 6. In the "Browse for Folder" window, navigate to the CD-ROM drive and click on the "82562"...
  • Page 98 7. In the following "Update Device Driver Wizard" window, click on "Next." 8. In the following "Update Device Driver Wizard" window, select "The updated driver (Recommended)/Intel(R) PRO/100+ Management Adapter." Then click on "Next." PCA-6180 User's Manual...
  • Page 99 9. In the following "Update Device Driver Wizard" window, click on "Next." 10. In the following "Update Device Driver Wizard" window, click on "Next." Chapter 6 LAN Configuration...
  • Page 100 11. In the "System Settings Change" window, click on "Yes" to complete the installation and restart Windows. PCA-6180 User's Manual...

  • Page 101: Windows Nt Wake-On-Lan Setup Procedure

    Windows NT Wake-on-LAN Setup Procedure 1. From the desktop of Windows NT, click on "Start" and select "Settings." Then click on the "Control Panel" icon to select "System." Chapter 6 LAN Configuration...
  • Page 102 2. In the "Intel(R) PROSet" window, under "Select a Network Adapter," choose "[2] Intel(R) PRO100+ Management Adapter." Then select the "Advanced" tab. Under "Setting," highlight the "Enable PME" item. Under "Value," select "Enabled." Then click on "OK." 3. In the "Reboot Required" window, click on "Yes." PCA-6180 User's Manual...

  • Page 103: Chapter 7 Ultra Ata 100 Storage Driver Setup

    Ultra ATA 100 Storage Driver Setup This driver must be installed to use the ® Intel Ultra ATA controller to improve storage subsystem performance and overall system performance.

  • Page 104: Introduction

    Introduction ® This driver takes advantage of the latest Intel Ultra ATA controller features to improve both storage subsystem performance and overall system performance. A useful diagnostic tool, Intel Ultra ATA ® Companion , shows technical information of the ATA subsystem. Features •...

  • Page 105: Installation

    Installation Note: Before installing this driver, make sure the CSI utility has been installed in your system. See Chapter 4 for information on installing the CSI utility. 1. Insert the driver CD into your system's CD-ROM drive. In a few seconds, the software installation main menu appears, as shown in the following figure.
  • Page 106 2. Click on "Next" when you see the following message. 3. When you see the following message, click on "Yes" to accept the License Agreement. PCA-6180 User's Manual...
  • Page 107 4. Click on "Next" when you see the following message. 5. Click on "Next" when you see the following message. Chapter 7 Ultra ATA 100 Storage Driver Setup...
  • Page 108 6. When the following message appears, click "Finish" to complete the installation and restart Windows. PCA-6180 User's Manual...

  • Page 109: Displaying Driver Information

    Displaying Driver Information 1. From the desktop of Windows, click on "Start" and select "Pro- grams." Then select "Intel Ultra ATA Storage Driver" and then "Companion." 2. Click on the "Device Parameters" or the "Storage Report" tab to view related information. Chapter 7 Ultra ATA 100 Storage Driver Setup...

  • Page 111: Chapter 8 Onboard Security Setup

    Onboard Security Setup This chapter explains OBS concepts and provides instructions for installing the relevant software drivers. This is done using the driver CD included in your PCA-6180 package.

  • Page 112: Introduction

    Introduction Onboard security (OBS) functions monitor key hardware. They help you maintain your system's stability and durability. The PCA-6180 can monitor 5 sets of system positive voltages, 2 sets of system negative voltages, CPU cooling fan speed, and CPU temperature. The positive system voltage sets which can be monitored include: •...

  • Page 113: Windows 9X Drivers Setup Procedure

    8.3 Windows 9X Drivers Setup Procedure 1. Insert the driver CD into your system's CD-ROM drive. In a few seconds, the software installation main menu appears, as shown in the following figure. Click on the "WIN 9X" button under the "OBS DRIVERS"...
  • Page 114 2. When you will see the following message, make sure you have closed all other programs, then click on "OK." 3. Click on the square graphics button when you see the following message. PCA-6180 User's Manual...

  • Page 115: Windows Nt Drivers Setup Procedure

    4. When you see the following message, click on "OK" to complete the installation. 8.4 Windows NT Drivers Setup Procedure 1. Insert the driver CD into your system's CD-ROM drive. In a few seconds, the software installation main menu appears, as shown in the following figure.
  • Page 116 2. Click "Next" when you see the following message. 3. Click "Next" when you see the following message. PCA-6180 User's Manual...
  • Page 117 4. Click "Next" when you see the following message. 5. Click "Finish" when you see the following message. Chapter 8 Onboard Security Setup...
  • Page 118 6. Click "OK" to restart Windows. PCA-6180 User's Manual...

  • Page 119: Using The Obs Hardware Doctor Utility

    8.5 Using the OBS Hardware Doctor Utility After completing the setup, all the OBS functions are permanently enabled. When a monitored reading exceeds safe limits, a warning message will be displayed and an error beep tone will activate to attract your attention. OBS Hardware Doctor will show an icon on the right side of the bottom window bar.
  • Page 120 2. It is recommended that you load the default values for all the OBS settings. However, if desired, you can establish new conditions for voltage, fan speed, and temperature. PCA-6180 User's Manual...

  • Page 121: Scsi Setup And Configurations

    SCSI Setup and Configurations The PCA-6180 features an onboard SCSI interface. This chapter provides basic SCSI concepts.

  • Page 122: Understanding Scsi

    Introduction The PCA-6180 is equipped with an Adaptec AIC-7892 single-chip PCI-to-SCSI host adapter which provides a powerful Ultra160 multitasking interface between your computer’s PCI bus and SCSI devices (disk drives, CD-ROM drives, scanners, tape backups, removable media drives, etc.). Ultra160 is a new generation of SCSI technology that expands SCSI performance from 80 MBytes/sec to 160 MBytes/sec.
  • Page 123 must be assigned to the SCSI interface and each SCSI device con- nected to it, and the SCSI bus must be properly terminated. SCSI IDs Each device attached to the AIC-7892, as well as the AIC-7892 itself, must be assigned a unique SCSI ID number from 0 to 15. A SCSI ID uniquely identifies each SCSI device on the SCSI bus and determines priority when two or more devices are trying to use the SCSI bus at the same time.

  • Page 124: Terminating The Scsi Bus

    SCSISelect utility must correspond to the SCSI ID of the device from which you are booting. By default, the Boot SCSI ID is set to 0. We recommend that you do not change this setting. • ® In Windows 95/98, you can use the Device Manager to determine which SCSI ID is assigned to each installed SCSI device.

  • Page 125: Configuring The Scsi Interface With Scsi Select

    mum speed. If you use a different kind of terminator plug, the data I/O rate will decrease. • By default, termination on the AIC-7892 itself is set to Automatic (the preferred method). We recommend that you do not change this default setting.

  • Page 126: Starting Scsi Select

    SCSI Select Options Available Settings Default Setting SCSI Device Configuration: Sync Transfer Rate (MBytes/sec) 160, 80.0, 53.4, 40.0, 160 32.0, 26.8, 20.0, 16.0, 13.4, 10.0, ASYN Initiate Wide Negotiation Yes, No Yes (Enabled) Enable Disconnection Yes, No Yes (Enabled) Send S tart Unit Command Yes, No Yes (Enabled) Enable Write Back Cache...

  • Page 127: Using Scsi Select Settings

    Press <Ctrl><A> for SCSISelect (TM) Utility! 3. From the menu that appears, use the arrow keys to move the cursor to the option you want to select, then press Enter. Note: If you have difficulty viewing the display, press F5 to toggle between color and monochrome modes.

  • Page 128: Boot Device Options

    this setting enabled unless any SCSI device connected to the Adaptec SCSI Card 29160 does not support SCSI parity. • Host Adapter SCSI Termination—(Default: Automatic) Deter- mines the termination setting for the SCSI card. The default setting for both the LVD/SE (low voltage differential/single ended) connectors and SE connectors is Automatic, which allows the SCSI card to adjust the termination as needed depending on the configu- ration of the connected SCSI devices.

  • Page 129: Advanced Configuration Options

    Note: Set Initiate Wide Negotiation to No if you are using an 8-bit SCSI device that hangs or exhibits other performance problems with 16-bit data transfer rate enabled. • Enable Disconnection—(Default: Yes) When set to Yes, allows the SCSI device to disconnect from the SCSI bus. Leave the set- ting at Yes if two or more SCSI devices are connected to the SCSI card.
  • Page 130 • Display <Ctrl> <A> Messages during BIOS Initialization— (Default: Enabled) When set to Enabled, the SCSI card BIOS displays the Press <Ctrl> <A> for SCSISelect (TM) Utility! message on your screen during system bootup. If this setting is dis- abled, you can still invoke the SCSISelect Utility by pressing <Ctrl>...
  • Page 131 • Set to Disabled: Scan Bus if you do not need the BIOS, but you want it to scan the SCSI devices on the bus and you need to spin up the devices. The following four options have no effect when the SCSI Card BIOS is disabled.

  • Page 132: Using Scsi Disk Utilities

    Using SCSI Disk Utilities To access the SCSI disk utilities, follow these steps: 1. Select the SCSI Disk Utilities option from the menu that appears after starting SCSISelect. SCSISelect scans the SCSI bus (to determine the devices installed) and displays a list of all SCSI IDs and the devices assigned to each ID.

  • Page 133: Programming The Watchdog Timer

    Programming the Watchdog Timer The PCA-6180 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.

  • Page 134: Watchdog Timer Overview

    A.1 Programming the Watchdog Timer The PCA-6180's watchdog timer can be used to monitor system software operation and take corrective action if the software fails to function after the programmed period. This section describes the operation of the watchdog timer and how to program it. A.1.1 Watchdog timer overview The watchdog timer is built-in the super I/O controller W83627HF.
  • Page 135 Unlock W83627H Select register of watchdog timer Enable the function of the watchdog timer Use the function of the watchdog timer Lock W83627HF Appendix A Programming the Watchdog Timer...

  • Page 136: Table A-1: Watchdog Timer Registers

    . t l . t i ] t l ] t l t i r ] t l ] t l y l l i t " . " Table A-1: Watchdog timer registers PCA-6180 User's Manual...

  • Page 137: Example Program

    A.1.4 Example Program 1. Enable watchdog timer and set 10 sec. as timeout interval ;----------------------------------------------------------- Mov dx,2eh ; Unlock W83627HF Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx...
  • Page 138 Mov al,0f6h Out dx,al Inc dx Mov al,10 Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al 2. Enable watchdog timer and set 5 minutes as timeout interval ;----------------------------------------------------------- Mov dx,2eh ; unlock W83627H Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h...
  • Page 139 Out dx,al Inc dx In al,dx Or al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Set timeout interval as 5 minutes and start counting Mov al,0f6h Out dx,al Inc dx Mov al,5 Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al 3.
  • Page 140 Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable watchdog timer to be reset by mouse Mov al,0f7h Out dx,al Inc dx In al,dx Or al,80h Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al 4.
  • Page 141 Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable watchdog timer to be strobed reset by keyboard Mov al,0f7h Out dx,al Inc dx In al,dx Or al,40h Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al 5.
  • Page 142 Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Generate a time-out signal Mov al,0f7h Out dx,al ;Write 1 to bit 5 of F7 register Inc dx In al,dx Or al,20h Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al PCA-6180 User's Manual...

  • Page 143: Pin Assignments

    Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • IDE Hard Drive Connector • Floppy Drive Connector • Parallel Port Connector • SCSI Connector • USB Connector • VGA Connector • Ethernet 10/100Base-T RJ-45 Connector •...

  • Page 144: Table B-1: Ide Hard Drive Connector (Cn1, Cn2)

    B.1 IDE Hard Drive Connector (CN1, CN2) Table B-1: IDE hard drive connector (CN1, CN2) Signal Signal IDE RESET* DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14...

  • Page 145: Appendix B Pin Assignments

    B.2 Floppy Drive Connector (CN3) Table B-2: Floppy drive connector (CN3) Signal Signal FDHDIN* FDEDIN* INDEX* MOTOR 0* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE* * low active Appendix B Pin Assignments...

  • Page 146: Parallel Port Connector (Cn4)

    B.3 Parallel Port Connector (CN4) Table B-3: Parallel port connector (CN4) Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * low active PCA-6180 User's Manual...

  • Page 147: Scsi Connector (Cn5)

    B.4 SCSI Connector (CN5) 34 33 68 67 36 35 Table B-4: SCSI connector (CN5) Function Function SD+12 SD-12 SD+13 SD-13 SD+14 SD-14 SD+15 SD-15 SDP+1 SDP-1 SD+0 SD-0 SD+1 SD-1 SD+2 SD-2 SD+3 SD-3 SD+4 SD-4 SD+5 SD-5 SD+6 SD-6 SD+7 SD-7...

  • Page 148: Usb Connector (Cn6)

    B.5 USB Connector (CN6) Table B-5: USB1/USB2 connector (CN6) USB1 Signal USB2 Signal +5 V +5 V Chassis GND B.6 VGA Connector (CN7) Table B-6: VGA connector (CN7) Signal Signal GREEN BLUE H-SYNC V-SYNC PCA-6180 User's Manual...

  • Page 149: Ethernet 10/100Base-T Rj-45 Connector

    B.7 Ethernet 10/100Base-T RJ-45 Connector (CN8, CN34) Table B-7: Ethernet 10/100Base-T RJ-45 connector (CN8, CN34) Signal Signal XMT+ XMT- RCV- RCV+ B.8 COM1/COM2 RS-232 Serial Port (CN9, CN10) Table B-8: COM1/COM2 RS-232 serial port (CN9, CN10) Signal Appendix B Pin Assignments...

  • Page 150: Keyboard And Mouse Connnector (Cn11)

    B.9 Keyboard and Mouse Connnector (CN11) Table B-9: Keyboard and mouse connector (CN11) Signal KB DATA MS DATA KB CLOCK MS CLOCK B.10 External Keyboard Connector (CN12) Table B-10: External keyboard connector (CN12) Signal DATA PCA-6180 User's Manual...

  • Page 151: Ir Connector (Cn13)

    B.11 IR Connector (CN13) Table B-11: IR connector (CN13) Signal Signal +5 V FIRRX CIRRX IR_RX +5VSB IR_TX B.12 CPU Fan Power Connector (CN14) Table B-12: CPU fan power connector (CN14) Signal +12 V Detect Appendix B Pin Assignments...

  • Page 152: Power Led And Keylock Connector (Cn16)

    B.13 Power LED and Keylock Connector (CN16) You can use an LED to indicate when the CPU card is on. Pin 1 of CN16 supplies the LED's power, and Pin 3 is the ground. You can use a switch (or a lock) to disable the keyboard so that the PC will not respond to any input.

  • Page 153: Reset Connector (Cn18)

    B.15 Reset Connector (CN18) Table B-15: Reset connector (CN18) Signal RESET B.16 HDD LED Connector (CN19) Table B-16: HDD LED connector (CN19) Signal LED0 (LED-) Vcc(LED+) B.17 ATX Feature Connector (CN20) Table B-17: ATX feature connector (CN20) Signal PS-ON Appendix B Pin Assignments...

  • Page 154: Atx Soft Power Switch (Cn21)

    B.18 ATX Soft Power Switch (CN21) Table B-18: ATX soft power switch (CN21) Signal 5VSB PWR-BTN B.19 H/W Monitor Alarm (CN22) Table B-19: H/W monitor alarm (CN22) Signal (LED+) LED0 (LED-) B.20 SM Bus Connector (CN23) Table B-20: ATX soft power switch (CN21) Signal SMB_CLK SMB_DATA...

  • Page 155: Extension I/O Board Connector (Cn27)

    B.21 Extension I/O Board Connector (CN27) Table B-21: Extension I/O board connector (CN27) Signal Signal D+ (USB3) D- (USB1) D+ (USB2) D- (USB0) D- (USB3) Vcc (USB1) D- (USB2) Vcc (USB0) Vcc (USB3) GND (USB1) Vcc (USB2) GND (USB0) GND (USB3) 5VSB GND (USB2) ACT LED (LAN2)

  • Page 156: Ps/2 Mouse Connector (Cn33)

    B.23 PS/2 Mouse Connector (CN33) Table B-23: PS/2 mouse connector (CN33) Signal MS DATA MS CLOCK PCA-6180 User's Manual...

  • Page 157: System I/O Ports

    B.24 System I/O Ports Table B-24: System I/O ports Addr. range (Hex) Device 000-01F DMA controller 020-021 Interrupt controller 1, master 022-023 Chipset address 040-05F 8254 timer 060-06F 8042 (keyboard controller) 070-07F Real-time clock, non-maskable interrupt (NMI) mask 080-09F DMA page register 0A0-0BF Interrupt controller 2 0C0-0DF...

  • Page 158: Dma Channel Assignments

    B.25 DMA Channel Assignments Table B-25: DMA channel assignments Channel Function Available Available Floppy disk (8-bit transfer) Available Cascade for DMA controller 1 Available Available Available B.26 Interrupt Assignments Table B-26: Interrupt assignments Priority Interrupt# Interrupt source Parity error detected IRQ0 Interval timer IRQ1...

  • Page 159: 1St Mb Memory Map

    B.27 1st MB Memory Map Table B-27: 1st MB memory map Addr. range (Hex) Device F0000h - FFFFFh System ROM C8000h - EFFFFh Unused C0000h - C7FFFh VGA BIOS B8000h - BFFFFh CGA/EGA/VGA text B0000h - B7FFFh Unused A0000h - AFFFFh EGA/VGA graphics 00000h - 9FFFFh Base memory...
  • Page 160 PCA-6180 User's Manual...
  • Page 161 Security Driver Installation Guide This appendix contains information on the security driver quick installation guide. It includes: • Security Driver Installation Instructions • Additional Information and Assistance...
  • Page 162 C.1 Security Driver The Intel(R) Security Driver installs to the target system the Win- dows* driver files for the Intel(R) 82802 Firmware Hub component. It provides access to the Hardware Random Number Generator located in the Firmware Hub device. Your system must have one of these operating systems: Windows 95 4.00.950c (OSR2.5 with or without USB Supplement)

  • Page 163: Software Installation

    C.2 Software Installation This software can be installed in three modes: Interactive, Silent, or via the Simple Installation method. The Interactive Mode requires user input during installation; the Silent Mode does not. The Simple Installation method copies over the key driver files and README.TXT for a simple or "Have Disk"...

  • Page 164: Silent Mode Installation

    C.2.2 Silent Mode Installation 1. Check the System Requirements. The operating system must be fully installed and running on the system before running this software. 2. Close any running applications. Otherwise, you may experience difficulties. 3. Run the InstallShield installation program: Compressed .ZIP distribution : SETUP.EXE -s 4.
  • Page 165 "version" String <varies> Current version number of the Intel(R) Security Driver C.2.2 AVAILABLE COMMAND LINE FLAG OPTIONS The Intel(R) Security Driver supports command line flags for various installation options. All command line flags and parameters must be separated by a space, except for the language code after the '-L' flag.
  • Page 166 Runs the Installer in silent mode. No user interface is displayed. This flag and the '-L' flag must be placed at the end of the command line flag list. Below are the language codes used with the '-L' flag: Language <LangCode>...
  • Page 167 Spanish 000A Swedish 001D Thai 001E C.3 VERIFYING INSTALLATION OF THE SOFT- WARE Run Device Manager to verify the correct installation and usage of the Intel(R) Security Driver. For Windows 95, Windows 98, and Windows 98 Second Edition: 1. Click on Start. 2.
  • Page 168 NOTE: if either the Driver File Details button, or the "isecdrv.sys" listing is not present, the driver is not currently installed on the system. For Windows NT 4.0: 1. Click on Start. 2. Click on Settings. 3. Select Control Panel. 4.
  • Page 169 of the software currently installed on this system. * 5. CONTENTS OF THE DISTRIBUTION PACKAGE The Intel(R) Security Driver package contains the following items: File(s) ------- ISECDRV_AUTOL.ZIP ISECDRV_ENU.ZIP README.TXT After installation on any system one or more of the following files are copied to the <InstallPath>\Document directory: README.TXT LICENSE.TXT*...
  • Page 170 the following files are copied to the <Windows>\SYSTEM32\DRIVERS directory: ISECDRV.SYS After installation on a Windows 98, Windows 98 SE, or Windows 2000 system, the following INF files are copied 1. to the <Windows>\SYSTEM32\DRIVERS directory: ISECDRV.SYS 2. to the <Windows>\INF directory: ISD_WDM.INF 3.
  • Page 171 9. Select the Properties button. 10. The Device Status dialog should indicate: "The device is working properly." 11. Select the Driver tab. 12. Click on the Driver File Details button. 13. A list of installed drivers will be displayed. The "isecdrv.sys"...
  • Page 172 For Windows 2000: 1. Click on Start. 2. Select Settings. 3. Select Control Panel. 4. Double-click on System icon. 5. Click on Hardware tab. 6. Click on Device Manager button. 7. Click on System Devices. 8. Click on "Intel(R) 82802 Firmware Hub Device" 9.

  • Page 173: Uninstalling The Software

    7. The file information should be listed. C.4 UNINSTALLING THE SOFTWARE NOTE: This procedure assumes that the above installation process was successful. This uninstall procedure is specific only to the version of the driver and installation file included in this package. To uninstall the Intel Security Driver and associated documentation (following an installation), do the following: 1.
  • Page 174 the event of system lockup, restart the machine and view Device Manager. If devices are listed properly and the system experiences no further problems, then the .INF file restore process was successful. If devices are not configured correctly, try re-running the procedures outlined in Section 3.

This manual is also suitable for:

Pca-6180e-00a1Pca-6180e2-00a1Pca-6180es-00a1Pca-6180f-00a1Pca-6180e-00b1Pca-6180e2-00b1 ... Show all

Table of Contents
