Pipishell PISM02 Instruction Manual page 5

Step 1 Prepare your TV [If mounted]
CAUTION: Follow your TV mount's manual for instructions on how to
safely remove your TV and TV bracket.
NOTE: Your TV wall mount may vary from the illustrations throughout
this manual — the procedure to install the soundbar is the same.
1 2
a
05
3
TOSS
a. If your TV brackets fit inside the
vertical soundbar brackets, follow
Figure a.
b. If your TV brackets do not fit
inside the vertical soundbar
brackets, follow Figure b.
b
