Side preparation

3.1

Packaging

3.1.1

Packaging Version 1

No Machine parts
1 Machine with cover
2 Operating console
3 Laser tube
4 Table system (for each table)
5 Cooling system
6 Traveling exhaust
3.1.2

Packaging Version 2

No Machine parts
1 Machine and x-axis
2 Cover and traveling exhaust
2 Laser tube
3 Table system (for each table)
4 Operating console
IV 8034_2.0_EN (01/2017)
Packaging
(L x W x H) /mm (inch)
3340 x 2620 x 1220
(131.5 x 103.1 x 48)
990 x 810 x 1425
(38.9 x 31.8 x 56.1)
1470 x 400 x 500
(57.8 x 15.7 x 19.7)
1890 x 965 x 690
(74.4 x 37.9 x 27.2)
800 x 1000 x 1100
(31.5 x 39.4 x 43.3)
600 x 800 x 144
(23.6 x 31.5 x 5.7)
Packaging
(L x W x H) /mm (inch)
3190 x 2270 x 1510
(125.6 x 89.4 x 59.4)
3390 x 1160 x 955
(133.5 x 45.7 x 37.6)
1560 x 540 x 680
(61.4 x 21.3 x 26.8)
1890 x 965 x 690
(74.4 x 38 x 27.2)
990 x 810 x 1425
(39 x 31.9 x 56.1)
Side preparation
Weight /
Type
kg (pound)
2500 wooden crate
(5511.6)
200 wooden crate
(440.9)
250 wooden crate
(551)
250 wooden crate
(551)
150 wooden crate
(330,7)
50 pallet
(110,2)
Weight /
Type
kg (pound)
1360 wooden crate
(53.5)
575 wooden crate
(22.7)
145 wooden crate
(5.7)
200 wooden crate
(7.9)
150 wooden crate
(6)
