Limp-home mode
When battery charge becomes low, the mower will go into Limp-Home mode:
◾
The mower automatically stop grass cutting;
◾
The beep indicator will continue to sound;
◾
The mower status indicator will flash red every second, the first segment of the mower fuel-gauge will flash red
and both the low-power indicator and the battery graphics on the fuel gauge will flash.
The operator should:
a) Push the PTO switch downward (Fig. H3) to disengage the blades. The beep indicator will stop sounding when the
blade stops;
b) Stop working and go to the battery charging area as soon as possible. The maximum distance the mower can
travel is 1000 m.
When the battery is nearly depleted, the icon of each occupied battery compartment and low-power indicator will
blink every half a second. The mower will stop working immediately. The operator should transport the mower to the
battery charging area for charging.
Manual pushing
If manual pushing is needed, be sure that the batteries are disconnected from the mower and the parking-brake
pedal is release from the braking position.
DRIVING THE MOWER (Fig. I1 – Fig. I9)
To stop, decrease or increase speed, slowly change the steering lever's distance from neutral.
DANGER: Stay at least two mowing widths away from any ditches, drop-offs, or water. Front wheels can rotate
when the mower is stopped, even with the brake applied, and cause the mower to go over the edge or into the
water and result in death or serious personal injury.
WARNING: Be aware of what is behind the mower before backing up. DO NOT mow in reverse unless absolutely
necessary. Always look down and behind before and while backing to make sure no children, bystanders, or pets
enter the mowing area. Remember that a careless fraction of a second is sufficient to inflict death or serious injury.
WARNING: Do not operate this machine on public roadways.
WARNING: If blockage happens or you strike a foreign object, stop the motors and remove the batteries.
Remove grass clippings, leaves, dirt and any other accumulated debris; thoroughly inspect the mower for damage
and repair the damage before restarting and operating the mower.

MAINTENANCE

WARNING: Always wear eye protection with side shields. Failure to do so could result in objects being thrown
into your eyes resulting in possible serious injury.
WARNING: Always protect your hands by wearing heavy gloves or wrapping the cutting edges with rags or other
materials when performing any maintenance on the mower blade. Always remove the safety key and battery packs
when servicing or transporting the mower.
