Safety Guide & Assembly Instructions
Guide de sécurité et Instructions de montage
Directrices de Seguridad e Instrucciones de Construcción
SAFETY ZONE
PS 73401
(Gold Design Option
requires additional kit*)
*PS 73403
PS 7744
PS 73402
PS 73403
SAFETY ZONE
SAFETY ZONE
PS 7766 (2)
PS 7668 (2)
PS 7690 (2)
PS 7744
We Will Gladly Help! • ¡Le Ayudaremos Con Mucho Gusto! • C'est avec joie que nous vous aiderons!
1-888-PLAYSTAR
Monday through Friday, 8:00 A.M. to 5:00 P.M. C.S.T.
www.playstarinc.com
( 752- 9782)
De Lunes a Viernes de 8:00 A.M. a 5:00 P.M. C.S.T.
(450) 699-3083
Du lundi au vendredi, de 8 h à 16 h EST
Advertisement
Related Manuals for PLAYSTAR FACTORY BUILT CLIFFHANGER
Summary of Contents for PLAYSTAR FACTORY BUILT CLIFFHANGER
- Page 1 PS 7668 (2) PS 7690 (2) PS 7744 We Will Gladly Help! • ¡Le Ayudaremos Con Mucho Gusto! • C’est avec joie que nous vous aiderons! 1-888-PLAYSTAR Monday through Friday, 8:00 A.M. to 5:00 P.M. C.S.T. www.playstarinc.com ( 752- 9782) De Lunes a Viernes de 8:00 A.M.
- Page 2 • Thoroughly read all safety instructions before Testing and Materials (ASTM) Home Playground beginning. Safety Standard. In order for PlayStar to comply with the ASTM Standard, we cannot recommend • Children must remain clear of construction site until anyone above these limits.
-
Page 3: Annual Maintenance Checklist
SAFETY INSTALLATION: seat or single planned activity should The chains or ropes provided are the be allowed on this set at one time, with maximum length designed for the swinging 1. Follow the instructions provided, do not a maximum weight of 105 pounds for element(s). -
Page 4: Icon Glossary
Icon Glossary Place tower or component in desired location. Secure screw (flush to top) with bit size shown. Mark board with template using pattern shown on this step. Secure hardware with socket/wrench size shown. Drill through board at correct location with bit size shown. Pre-drill into second board with correct depth and bit size shown. -
Page 5: Safety Warnings
Safety Warnings CAUTION: Minimum spacing is required from the CAUTION: These boards should be pre-drilled closest point of all other rides or stationary objects. to avoid cracking. Note: Pre-drill into second board using first board as a template before attaching. CAUTION: Use wrench to tighten Quick-Link Connectors. - Page 6 (24) FC 3217 SA 4496 LT 7000 FP 2159 HW 1201 HW 1219 HW 1411 (50) C/," C/," x 3" (10) C/," x 1Z/x" HW 1223 #8 x B/," #8 x 2Z/x" (116) #8 x 1Z/v" HW 1231 HW 1234 HW 1527 HW 1528 HW 1301...
-
Page 7: Play Handles
Outer Monkey Rings & Bars Additional Hardware - Silver Only (20) #8 x 1Z/v" HW 1231 HW 1411 (20) C/," HW 1301 (44) C/," #8 x 2Z/x" HW 1234 SA 4495 HW 1219 HW 1528 FC 3217 C/," x 1Z/x" (20) C/,"... - Page 8 Add Brackets to Climbing Walls - All Design Options Gold Design Option involves building two climbing towers. (You will repeat most steps using double the hardware listed.) HW 1411 HW 1301 FP 2159 (2) C/," C/," C/," x 3Z/x" HW 1527 Each wall will be marked on the end.
- Page 9 HW 1219 C/," x 1Z/x" HW 1301 FP 2159 (1) C/," BOTTOM END...
- Page 10 HW 1527 (14) C/," x 3Z/x" HW 1411 HW 1301 C/," x 2" HW 1528 (21)C/," (21) (21) C/," FP 2159 HW 1527 HW 1528 HW 1527 BOTTOM END Repeat until all walls have brackets.
- Page 11 Combine Walls- All Design Options HW 1527 HW 1411 HW 1301 C/," x 3Z/x" (2) C/," C/," HW 1527 Start with the Full Rock Wall and attach any other climbing wall of your choice. HW 1527 HW 1219 HW 1301 C/,"...
- Page 12 HW 1527 (14) C/," x 3Z/x" HW 1528 HW 1411 HW 1301 (21) C/," (21) C/," C/," x 2" HW 1527 HW 1528 HW 1527 Continue repeating Step 3 until entire octagon climbing structure is completed. ONLY requirement: The two walls containing climbing bars must be placed directly across from one another.
- Page 13 T-25 HW 1231 (96) #8 x 1Z/v" Continue repeating Step 4 until all brackets are secured with screws.
- Page 14 Inner Monkey Rings- All Design Options T-25 #8 x 2Z/x" HW 1234 Attach Monkey Rings between the two walls with climbing bars. T-25 (16) #8 x 1Z/v" HW 1231 SA 4496...
- Page 15 C/," x 2" HW 1528 HW 1301 HW 1411 (4) C/," (4) C/," HW 1219 HW 1301 (4) C/," C/," x 1Z/x"...
- Page 16 Anchoring- Bronze Design Only HW 1219 C/," x 1Z/x" HW 1301 (4) C/," FC 3217 Alternate anchors on every other wall.
- Page 17 Outer Monkey Rings & Bars Assemblies HW 1411 (20) C/," HW 1301 (20) C/," x 2" HW 1528 (40) C/," SA 4495 Bolt heads located on the inside. HW 1231 (16) #8 x 1Z/v" TRX Repeat steps 1 & 2 for second assembly.
- Page 18 HW 1231 #8 x 1Z/v" TRX 3Z/x" 21Z/x" 92" Dig into ground for leg beams. 2Z/x" Repeat process for both frames.
- Page 19 HW 1201 HW 1301 (4) C/," C/," x 3" Repeat process for both frames.
- Page 20 Anchoring- Silver Design Only HW 1219 C/," x 1Z/x" HW 1301 (8) C/," FC 3217 Alternate anchors on every other wall.
- Page 21 Connector Monkey Ring Assemblies HW 1231 #8 x 1Z/v" TRX 3Z/x" 21Z/x" Be sure boards face opposite directions so the monkey ring chains are staggered. 60"...
- Page 22 HW 1201 HW 1301 (4) C/," C/," x 3"...
- Page 23 Anchoring - Gold Design Only HW 1219 C/," x 1Z/x" HW 1301 (8) C/," FC 3217 Alternate anchors on every other wall.
- Page 24 Du lundi au vendredi, de 8 h à 16 h E.S.T. PlayStar, Incorporated, Janesville, WI 53547 © 2022, 2021, 2017 PlayStar, Inc. Reproduction of this document in part or whole is prohibited without the permission of PlayStar, Inc. PlayStar, Incorporated, Janesville, WI 53547 Protected by one or more of the following United States or Foreign Patents: US D418,189;...
