Summary of Contents for PLAYSTAR Little Sprout Play House PS 7490
- Page 1 Play House Safety Guide & Assembly Instructions Play House 1-888-752-9782 Call Toll Free We’re Here To Help! PS 7490 Customer Service: Monday - Friday, 8:00 A.M. to 5:00 P.M. C.S.T.
- Page 2 • Thoroughly read all safety instructions before Testing and Materials (ASTM) Home Playground beginning. Safety Standard. In order for PlayStar to comply with the ASTM Standard, we cannot recommend • Children must remain clear of construction site until anyone above these limits.
- Page 3 SAFETY INSTALLATION: 2. Only one child, for each single planned 4. Dress children appropriately and do not seat or single planned activity should allow them to wear inappropriate items, 1. Follow the instructions provided, do not be allowed on this set at one time, with such as but not limited to, loose fitting alter its design in any way.
-
Page 4: Tools Required
COMPONENTS INCLUDED (not actual size) Roof Cap (2) Sunlight Door Window (1) Window (1) Assembly Drill Door Hinge Tool Kit (1) Template (1) Knob (2) Strap (2) TOOLS REQUIRED Level Adjustable Wrench Screwdriver (regular or phillips) Square Socket Wrench Tape Measure Pencil 9/16"... - Page 5 BOARDS INCLUDED Before starting to assemble your playset, make sure all boards and hardware are identified and stacked by size. This will improve your assembly time. All boards are identified by "nominal" dimensions. The "actual" width and thickness of boards will vary.
- Page 6 BOARDS INCLUDED All boards are identified by "nominal" dimensions. The "actual" width and thickness of boards will vary. During assembly process, hide the marked end of the board to the inside so it is not visible on your completed playset. (1) Door Panel Note: These boards require some...
- Page 7 PLEASE NOTE: Letters represent pattern not position Note: When the PlayStar logo is showing, the three tabs on the bottom will position the template square with any two edges. When the arrow is showing, the two tabs on the bottom will position the template square with one edge only, which will allow you to slide the template anywhere along the board.
- Page 8 PLEASE NOTE Patterns can be created (Letters represent pattern not position) anywhere along the board by turning the template over (arrow side up) and sliding it to the desired position. Use the shaded holes for that pattern. 2" x 4" 1"...
-
Page 9: Frame Assembly
FRAME ASSEMBLY Items for STEP 1: 2" x 4" x 46C\v" board On a flat work surface, lay out two 2" x 4" x 44Z\v" board 2" x 4" x 44Z\v" boards 34C\v" apart. 2" x 4" x 34C\v" boards (16) #8 x 2Z\x"... - Page 10 Items for STEP 3: 7 ³/₄" 2" x 4" x 44Z\v" boards 16 ¹/₂" (18) #8 x 2Z\x" deck screws 21¹/₂" 7 ³/₄" Attach three 2" x 4" x 44Z\v" boards at dimensions shown. Secure with # 8 x 2Z\x" deck screws. 7 &...
- Page 11 Items for STEP 5: (2) 1" x 4" x 29Z|x" boards (8) #8 x 1Z|x" deck screws Install two pre-drilled and counter-sank 1" x 4" x 29Z\x" boards 1" below the edge of the opening as shown. Equally space them between the 2"...
- Page 12 Items for STEP 7: (2) 1" x 6" x 34" boards Flush (4) #8 x 1Z|x" deck screws Attach two pre-drilled and counter-sank 1" x 6" x 34" boards. Attach the top board flush with the bottom edge of window opening as shown. Attach the bottom board flush with the bottom as shown.
- Page 13 Items for STEP 9: (6) 1" x 4" x 34C\v" beveled boards (24) #8 x 1Z|x" deck screws Attach six 1" x 4" x 34C\v" beveled boards. Start at the bottom making sure the first board is tight against the 2" x 4" x 34C\v" board as shown.
- Page 14 Items for STEP 11: 2" x 4" x 28" boards 2" x 4" x 31Z\x" boards (12) #8 x 2Z\x" deck screws On a flat work surface, lay out one 2" x 4" x 31Z\x" and two 2" x 4" x 28" boards as shown. Make sure assembly remains square while securing with #8 x 2Z\x"...
- Page 15 Items for STEP 13: Step 12 assembly (12) #8 x 2Z\x" deck screws Attach Step 12 assembly to Play House. End of 2" x 4" x 28" boards must be flush with side of Flush 2" x 4" x 44Z\v" boards as shown. Secure with #8 x 2Z\x"...
- Page 16 Items for STEP 15: (11) 1" x 4" x 21M\zn" boards (66) #8 x 1Z\x" deck screws Attach eleven pre-drilled and counter- sank 1" x 4" x 21M\zn" boards as shown. Attach the two end boards flush with the 2" x 4" x 28" boards and equally space the remaining boards.
- Page 17 Items for STEP 17: (18) 1" x 4" x 7M\," beveled boards (72) #8 x 1Z|x" deck screws Attach nine 1" x 4" x 7M\," beveled boards to each side of the Play Flush House. Start at the bottom making Tight sure the first board is tight against the decking as shown.
- Page 18 Items for STEP 19: (2) Roof Caps (2) 2" x 4" x 31Z\x" boards (2) 2" x 4" x 34C\v" boards (12) #14 x 1Z|v" pan head screws On a flat surface, position boards as shown. Keep boards square while attaching roof cap to boards with #14 x 1Z|v"...
- Page 19 Items for STEP 21: (2) Step 19 assemblies 1" x 4" x 47Z|x" (1) Step 20 assembly (4) 1" x 4" x 47Z\x" beveled boards (23) #8 x 1Z|x" deck screws 45C\v" 22Z\v" 1" x 4" x 47Z|x" 1" x 4" x 47Z|x" M\,"...
- Page 20 Position Roof Assembly on the Play House so that the 1" x 4" x 47Z\x" Items for STEP 23: beveled boards are firmly resting on the 2" x 4" x 46C\v" boards. Make sure the roof is level with the tower and with equal overhang on all four (1) Roof Assembly corners.
-
Page 21: Door Assembly
DOOR ASSEMBLY On a flat surface, lay out two 1" x 4" x 15Z\x" boards 19Z\x" apart. Set Items for STEP 24: door panel back side up at dimensions shown. Make sure assembly remains square while securing with #8 x 1Z|v" deck screws. (2) 1"... - Page 22 Items for STEP 26: (5) 3-prong t-nuts (5) Z\v" x 1" machine screws (5) Z\v" fender washers Hammer t-nuts from back side. Secure with Z\v" x 1" machine screws and Z\v" fender washers from front. Items for STEP 27: Fold door window at scoring lines as shown. Helpful Hint: Using a straight edge will help.
- Page 23 Items for STEP 28: Attach hinge straps at dimensions shown. Use hinges as template and drill Z|," holes C|v" deep. Secure with #8 x 1" truss head screws. (2) hinge straps (6) #8 x 1" truss head screws 2C\v" 1B\," 1M\,"...
- Page 24 Items for STEP 30: Place door at dimensions shown. Using clamps to hold the door tight against 2" x 4" x 46C|v" at the locations shown will (1) door assembly greatly help. Use hinges as template and drill Z|," holes C|v" (6) #8 x 1"...
- Page 25 SUNLIGHT WINDOW SIDE WINDOW INSTALLATION The Sunlight Window can be attached either on the side or back window openings. Choose your preferred location and follow the appropriate installation step. If you purchased Deco Kit second window is included. Items for STEP 31-A: Use a straight edge and fold on the scoring lines at 90º...
- Page 26 SUNLIGHT WINDOW BACK WINDOW INSTALLATION Items for STEP 31-B: Use a straight edge and fold on the scoring lines at 90° angle as shown. (1) sunlight window From the inside of Play House, center sunlight window flat in opening as (16) #8 x truss head screws B\,"...
-
Page 27: Add-On Components
COMPONENTS - Mounting Instructions USE THE INSTALLATION INSTRUCTIONS AND MOUNTING HARDWARE WHICH ARE SUPPLIED WITH THE FOLLOWING COMPONENTS TODDLER TUNNEL (PS 8814) DECORATIVE KIT (PS 7980) ADD-ON COMPONENTS Grow With Me! Turn your Playhouse into a full sized playset with the PS 7492 Swingbeam / Riser Kit and PS 8813 Scoop Slide. -
Page 28: Important - Please Read
PlayStar, Incorporated, Janesville, WI 53547 © 2017 PlayStar, Inc. Reproduction of this document in part or whole is prohibited without the permission of PlayStar, Inc. Protected by one or more of the following United States or Foreign Patents: US D418,189; US D409,708; US D424,154; US D428,637; US 6,402,663; US D422,332; US D410,059;...
