- Page 1 Rollator Walker H1020 applies to H1020 - H1029 User instructions...
- Page 2 Rollator Series H1020 English User instructions Intended use This rollator is intended to be used by persons with You can assemble this rollator on your own in a few reduced mobility as a walking aid and for transporting steps. Assembly takes about 10 minutes. No tools are needed for assembly.
- Page 3 Scope of delivery The Helavo Series H1020 comes with a frame and the following parts: • Removable cane holder • Adjustable Backrest • Bag • Wing screws • Front wheels • Rear axle with rear wheels • Velcro strap • User instructions •...
- Page 4 Description of the rollator A.) Handle grip G.) Parking brake H.) Width adjustment B.) Backrest C.) Seat I.) Wing screw J.) Height adjustment D.) Bag K.) Cane holder E.) Wing screw on front wheel L.) Rear wheel axle with rear wheel M.) Wing screws on frame F.) Front wheel N.) Rear wheel brake...
- Page 5 4. Keep your hands away from the folding mechanism to avoid entrapment. If you have any questions regarding the assembly, the rollator or if you are unsure about anything, please contact our customer service at the e-mail address: support@helavo-rollators.com User instructions |...
- Page 6 Assembly instructions Remove the rollator from Remove the two wing the packaging and remove screws ("M") on the frame of the rollator at the protective foils. Spread the "RB" mark. out the parts for assembly as shown. The seat ("C") of the rollator lies flat.
- Page 7 Assembly instructions Now repeat steps 2. - 5. for Fasten the rear wheel axle the second rear wheel axle with rear wheel ("L") with with rear wheel ("L") with the wing screws ("M") mark "LB" on the other side loosened before. of the frame.
- Page 8 ("A") and fix it by Push it down on both sides tightening the grey wing of the seat ("C") as shown. screws ("I"). The Helavo Important: For the rollator logo should be facing the to be fully unfolded, it must front of the rollator.
- Page 9 Assembly instructions Our recommendation: Fix Press and hold the gray the brake cables on both height adjustment button sides of the frame using ("J") and insert the two the velcro tape as shown. handles ("A") into the Be careful not to cover frame one after the other.
-
Page 10: Adjusting The Height
Adjusting the height Press the gray button on the height adjustment ("J") on the frame of the rollator and adjust the handle to the appropriate height. Repeat for the other side. Make sure the gray buttons on both handles are locked. Make sure that both handles are set to the same height. - Page 11 Brakes Push the brake handles ("G") Pull the brake handles down to lock the rear ("G") up to brake the wheels. In this position, the rollator. parking brake of the rollator is active. To release the parking brake again, pull the brake handles ("G") upward.
-
Page 12: Adjusting The Brakes
Adjusting the brakes To adjust the rear brake ("N"), adjust the adjustment screw and locking nut. These are located on the rear wheels ("L") rollator. Turn adjustment screw counterclockwise to increase the tension. Then secure the adjustment by turning the locking nut clockwise. Hold the adjustment screw in place while doing so. - Page 13 Removable cane holder 1. Attach the cane holder ("K") To do this, slide the cane to the side of the frame in holder ("K") onto the the provided position. holder from above. User instructions |...
- Page 14 Folding and storing the rollator 1. Pull the handle in the Continue to push the middle of the seat ("C") rollator on both sides of firmly upwards to fold the the frame. rollator. | User instructions...
-
Page 15: Adjusting The Backrest
Adjusting the backrest Press the gray width adjustment button ("H") on the backrest ("B") of the rollator and adjust the backrest to the appropriate width. Repeat for the other side. Make sure the width adjustment buttons on both sides are locked. -
Page 16: Maintenance
Maintenance 1. Check the rollator at regular intervals for loose wing screws ("E" / “I” / "M") and defective height adjustments ("J"). 2. Periodically check for proper operation of the rear wheel brakes ("N"). 3. Replace damaged or worn parts. Cleaning The rollator can be cleaned with a damp cloth / sponge and warm soapy water.
