Rollator Series H1030
applies to H1030 - H1039
User instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the H1030 Series and is the answer not in the manual?

Questions and answers

Related Manuals for helavo H1030 Series

Summary of Contents for helavo H1030 Series

  • Page 1 Rollator Series H1030 applies to H1030 - H1039 User instructions...
  • Page 2 Consult your medical professional to determine please contact our customer service at the e-mail if the rollator is suitable for your needs. address: support@helavo-rollators.com | User instructions...

  • Page 3: Scope Of Delivery

    Scope of delivery The Helavo model series H1030 is delivered with a frame and the following parts: • Removable cup holder • Basket • Tray with anti-slip mat • Wing screws • Rear axles with rear wheels • Front wheels •...
  • Page 4 Description of the Rollator G.) Parking Brake A.) Handle H.) Brake handle I.) Height adjustment B.) Tray with anti-slip mat C.) Removable cup holder J.) "Pull" button D.) Basket K.) Wing screw on frame L.) Rear wheel axle with rear wheel E.) Wing screw on front wheel M.) Rear wheel brake F.) Front wheel...
  • Page 5 4. Keep your hands away from the folding mechanism to avoid entrapment. If you have any questions regarding the assembly, the rollator or if you are unsure about anything, please contact our customer service at the e-mail address: support@helavo-rollators.com User instructions |...
  • Page 6 Assembly instructions Remove the rollator from 2. Remove the wing the packaging and remove screws on the frame the protective foils. Spread ("K") marked "RB" on out the parts for assembly the rollator. as shown. Insert the rear wheel axle Fasten the rear wheel with rear wheel ("L") with axle with rear wheel...
  • Page 7 Assembly instructions Repeat steps 2. - 4. for the Remove the wing screw second rear wheel axle with ("E") from the front wheel rear wheel ("L") with the "LB" ("F") marked "RF". mark on the other side of the frame. Fasten the front wheel Insert the front wheel ("F") ("F") with the previously...
  • Page 8 Assembly instructions Repeat steps 6. - 8. for the Put the rollator in an upright second front wheel ("F") position to unfold it. To do with the "LF" mark on the this, pull the "Pull" button other side of the frame. ("J").
  • Page 9 Assembly instructions Our recommendation: Fix 14. Place the tray with anti- the brake cables on both slip mat ("B") on the sides of the frame using frame. the velcro tape as shown. User instructions |...

  • Page 10: Adjusting The Height

    Adjusting the height Open the gray height adjustment ("I") and adjust the handle into an appropriate height. Repeat for the other side. Make sure the height adjustment on both sides are securely locked and closed. Make sure that the handle is set to the same height on both sides. Handle height: 35.4 - 40.2 inch Your ideal handle height Adjust the rollator so that your arms are slightly...
  • Page 11 Removable cup holder Attach the cup holder 2. To do this, slide the cup ("C") to the basket in holder ("C") onto the the provided position. bracket from above. User instructions |...
  • Page 12 Brakes Pull the brake handle 2. Push the brake handle ("H") ("H") upwards to brake upwards and fix it with the the rollator. parking brake ("G") to lock the rear wheels. In this position, the parking brake of the rollator is active. To release the parking brake, push the brake handle up slightly and pull...

  • Page 13: Adjusting The Brakes

    Adjusting the brakes To adjust the rear brake ("M"), adjust the adjustment screw and locking nut. These are located on the rear wheels ("L") of the rollator. Turn the adjustment screw counterclockwise to increase the tension. Then secure Locking nut the adjustment by turning the locking nut clockwise.
  • Page 14 Folding and storing the rollator Grasp the rollator by the Remove the tray ("B"). handle ("A") and tilt it in Then activate the your direction so that it parking brake ("G") stands on the rear wheels (See also chapter ("L"). "Brakes"...

  • Page 15: Maintenance

    Maintenance 1. Check the rollator periodically for loose wing screws ("E" / "K") and defective height adjustments ("I"). 2. Periodically check for proper operation of rear wheel brakes ("M"). 3. Replace damaged or worn parts. Cleaning The rollator can be cleaned with a damp cloth / sponge and warm soapy water. If necessary, you can use an antibacterial surface cleaner.
