- Page 1 Rollator Series H1050 applies to H1050 - H1059 User instructions...
- Page 2 If you have any questions regarding the assembly, the your medical professional to determine if the rollator is rollator or if you are unsure about anything, please suitable for your needs. contact our customer service at the e-mail address: support@helavo-rollators.com | User instructions...
-
Page 3: Scope Of Delivery
Scope of delivery The Helavo Series H1050 comes with a frame and the following parts: • Removable cane holder • Basket • Front wheel axles with front wheels • Rear wheel axle with rear wheels • Velcro strap • Assembly instructions •... - Page 4 Description of the rollator F.) Handle grip G.) Brake handle A.) Backrest H.) Wing screw I.) Height adjustment B.) Seat C.) Basket J.) Spring button D.) Front wheel axle with K.) Rear wheel axle with front wheel rear wheel L.) Rear wheel brake E.) Cane holder | User instructions...
- Page 5 4. Keep your hands away from the folding mechanism to avoid entrapment. If you have any questions regarding the assembly, the rollator or if you are unsure about anything, please contact our customer service at the e-mail address: support@helavo-rollators.com User instructions |...
- Page 6 Assembly instructions Insert the rear wheel axle Remove the rollator from with rear wheel ("K") with the packaging and remove the marking "RB" into the the protective foils. Spread frame at the corresponding out the parts for the marking "RB". Both assembly as shown.
- Page 7 Assembly instructions Press and hold the two Insert the front wheel axle spring buttons ("J") on the with front wheel ("D") with sides of the front wheel axle mark "RF" into the frame at ("D") to slide the parts into the corresponding mark each other.
- Page 8 ("F") and fix it by tightening frame by pressing and the grey wing screws ("H"). holding the grey button of The Helavo logo should be the height adjustment ("I"). facing the front of the Adjust the handles so that rollator.
-
Page 9: Adjusting The Handle Height
Adjusting the handle height Press the gray button on the height adjustment (" " I") on the frame of the rollator and adjust the handle to the appropriate height. Repeat for the other side. Make sure the gray buttons on both handles are locked. Make sure that both handles are set to the same height. -
Page 10: Adjusting The Seat Height
Adjusting the seat height Press the spring button ("J") on the frame of the rollator and adjust the seat to the appropriate height. Repeat this for all wheel axles. Make sure all push buttons are engaged. Make sure that all wheel axles ("D" / "K") are set to the same height. - Page 11 Brakes 1. Pull the brake handles Push the brake handles ("G") ("G") up to brake the down to lock the rear rollator. wheels. In this position, the parking brake of the rollator is active. To release the parking brake again, pull the brake handles ("G") upward.
-
Page 12: Adjusting The Brakes
Adjusting the brakes To adjust the rear brake ("L"), adjust the adjustment screw and locking nut. These are located on the rear wheels ("K") rollator. Turn adjustment screw counterclockwise to increase the tension. Then secure the adjustment by turning the locking nut clockwise. Hold the adjustment screw in place while doing so. - Page 13 Removable cane holder 1. Attach the cane holder To do this, slide the ("E") to the side of the cane holder ("E") onto frame in the provided the holder from position. above. User instructions |...
- Page 14 Folding and storing the rollator 1. Lift the seat ("C") of the Pull up the black metal rollator. brace inside the basket to fold the rollator. | User instructions...
-
Page 15: Maintenance
Maintenance 1. Check the rollator at regular intervals for loose wing screws ("H") and defective spring buttons ("J"). 2. Periodically check for proper operation of the rear wheel brakes ("L"). 3. Replace damaged or worn parts. Cleaning The rollator can be cleaned with a damp cloth / sponge and warm soapy water. If necessary, you can use an antibacterial surface cleaner.
