Audio Output Cables

MCSR5PXLR5P
MCSR5PXLR2
RATPAC Adapter Kit
MCSRPT
12 inch long TA3 female to stripped and tinned wires for
balanced output.
MCSRXLR
12 inch long TA3 female to XLR male 3-pin for balanced
output.
MCSRTRS
Rio Rancho, NM
Right angle TA5F plug
to 5-pin XLR; balanced
outputs; 25 inches long.
For SRa5P/5P outputs.
Right angle TA5F plug to
two 3-pin XLR; balanced
outputs; 20 inches long.
For SRa5P/5P outputs.
Adapter kit to build either
a 3-pin or 5-pin TA Series
right angle connector.
Includes standard 5-pin
connector, modified 3-pin
insert and backshell,
aluminum right angle
housing, strain relief
tubing, set screws and
wrenches.
PIN 1: Shield
PIN 2: Audio (+) white
PIN 3: Audio (-) green
PIN 1: Shield
PIN 2: Audio (+)
PIN 3: Audio (-)
Male 3.5 mm TRS plug
to two female TA3 (mini
XLR) connectors for
dual channel use.

External Power Cables

21747
21746
PS200
UHF Digital Hybrid Wireless
Locking LZR style plug
to stripped and tinned;
6 feet long.
Locking LZR style plug
to stripped and tinned;
12 inches long.
Hirose 7-4 pin to LZR
type locking plug, 12"
long.
®
