SRc5P & SRc
Camera Slot Dual UHF Receiver
SRc5P, SRc, SRC5p-941, SRc-941, SRc5P-961, SRc-961
Featuring
Digital Hybrid Wireless
U.S. Patent 7,225,135
Quick Start Summary
The following checklist includes the minimum required
settings to start using the receiver.
• Install either a battery sled, camera slot adapter or
other power source (see pages 9-13).
• Connect power to the receiver (see pages 11, 12,
15).
• Set the DIVMODE for single or dual channel opera-
tion (see page 21).
• Set the COMPAT (compatibility) mode for the trans-
mitters to be used (see page 21).
• Find clear operating frequencies for one or both
receivers using SmartTune or manual scanning (see
pages 24, 25).
Fill in for your records:
Serial Number:
Purchase Date:
Technology
®
• Set transmitters on the matching frequencies (see
• Verify transmitters are set to the same compatibility
• Adjust transmitter input gain to match voice level
• Adjust receiver output level as needed for the
INSTRUCTION MANUAL
transmitter manual).
mode as the receiver (see transmitter manual).
and mic position (see transmitter manual).
camera or mixer input level desired (see LEVEL on
page 21).
IMPORTANT:
Performance will be degraded if
FREQ.
Receiver 2 is set 4.2 to 4.8 MHz higher
WARNING
than Receiver 1. The LCD will also flash
this message periodically.
Rio Rancho, NM, USA
www.lectrosonics.com
