Audio Output Cables

MCSR5PXLR5P
MCSR5PXLR2
RATPAC Adapter Kit
MCSRPT
MCSRXLR
MCSRTRS
External Power Supply
Rio Rancho, NM
Right angle TA5F plug
to 5-pin XLR; balanced
outputs; 25 inches long.
For TA5M output jacks.
Right angle TA5F plug to
two 3-pin XLR; balanced
outputs; 20 inches long.
For TA5M output jacks.
Adapter kit to build either
a 3-pin or 5-pin TA Series
right angle connector.
Includes standard 5-pin
connector, modified 3-pin
insert and backshell,
aluminum right angle
housing, strain relief
tubing, set screws and
wrenches.
12 inch long TA3 female to
stripped and tinned wires
for balanced output.
PIN 1: Shield
PIN 2: Audio (+) white
PIN 3: Audio (-) green
12 inch long TA3 female to
XLR male 3-pin for balanced
output.
PIN 1: Shield
PIN 2: Audio (+)
PIN 3: Audio (-)
Male 3.5 mm TRS plug
to two female TA3 (mini
XLR) connectors for
dual channel use.
DCR12/A5U
AC power supply for IFBT4
transmitters; 100-240 V, 50/60
Hz, 0.3 A input, 12 VDC
regulated output; 7-foot cord
with LZR threaded locking
plug and interchangeable
blades/posts for use in Europe,
UK, Australia and USA (sold
separately).

External Power Cables

21747
21746
PS200
21425
6 ft. long power cord; coaxial to stripped & tinned leads.
Coaxial plug: ID-.080"; OD-.218"; Depth- .5".
21472
6 ft. long power cord; coaxial to stripped & tinned leads.
Right angle coaxial plug: ID-.075"; OD-.218"; Depth-
.375"
21586
DC16A Pigtail power cable, LZR stripped & tinned.
Thread lock collar.
UHF Digital Hybrid Wireless
Locking LZR style plug
to stripped and tinned;
6 feet long.
Locking LZR style plug
to stripped and tinned;
12 inches long.
Hirose 7-4 pin to LZR
type locking plug, 12"
long.
Locking collar with
5/16"-32 thread
®
