Remote Control System

Take some time to learn about the remote system fitted to this fire.
This Fire remote control system which is powered batteries. The fire is
supplied with a hand set to switch the fire on/off and regulate the flame
up/down. In order to operate the appliance the handset must be pointed
directly at the magic eye (line of sight) on the fire.
The hand set has a child safe feature to avoid accidental lighting. Please read
"lighting the fire" section later in this handbook before operating the
appliance.
The remote is powered by 6 x 'AA' Batteries in the appliance and a 9V
battery in the handset.
It is recommended that only "Lithium" batteries are used in the remote
system to ensure a long life.
Note: that if the fire shuts down it is set in "safe mode" to reactivate the fire
press button #1 only on the handset. This will cause a beep. Now the fire
can be lit again using the standard start-up sequence.
The remote system has a fault diagnosis system built in which is indicated by
a number of beeps. Review the "fault diagnosis" section later in this manual
for the code. A warning sound when the internal batteries become low will e
heard however if the batteries are totally dead there will be no sund. If the
appliance fails to operate on the hand set change the batteries in both the
appliance and the hand set as this is the most common cause of failure.
IMPORTANT NOTE: All CVO fires are given a 100% full function test at
the factory before being shipped. Never remove any wires from the
black box or the remote system. All connections are required. There
is no need to remove any connections from the remote system during
installation. Removal of any connections will result in the warranty being
invalidated and no claims will be accepted for the unit not working.
