PIN NUMBER: 0558CP1695
Rev 2
RIBBON (FR850) & RIBBON (FR850NV)
[With ANTOSS Remote]
TECHNICAL MANUAL & USER HANDBOOK
CE APPROVAL: BS EN509:2000+A1:2003+A2:2004
Serial Number ....................................
For use with Natural Gas (G20) or LPG (G31) see data plate.
Important:
It is recommended, even if you have fitted these appliances
before, that you take the time to read through these instructions and follow
them step by step.
Please quote this serial number when calling to discuss installation and spare
part requests. The Warranty is valid for 1 Year from date of delivery.
To register the appliance complete the warranty card supplied and return to:
Spirit Fires Limited. 4 Beaumont Square, Aycliffe Industrial Park,
Newton Aycliffe, County Durham, DL5 6XN.
This manual must be handed to the owner of the property once the
appliance has been installed and commissioned
Page 1 of 58
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CVO Fire FR-850-V
Summary of Contents for CVO Fire FR-850-V
- Page 1 PIN NUMBER: 0558CP1695 Rev 2 RIBBON (FR850) & RIBBON (FR850NV) [With ANTOSS Remote] TECHNICAL MANUAL & USER HANDBOOK CE APPROVAL: BS EN509:2000+A1:2003+A2:2004 Serial Number ……………………………… For use with Natural Gas (G20) or LPG (G31) see data plate. Important: It is recommended, even if you have fitted these appliances before, that you take the time to read through these instructions and follow them step by step.
-
Page 2: Table Of Contents
Contents Page 3 Description Page 4 Technical Data Page 5 Read This First Page 6 Unpacking the Appliance Page 6 Parts List Page 7 Construction Drawings Page 8 Gas Burner Construction Page 9 Remote Control System Page 10 Installation Requirements Page 12 Burner Ventilation Page 14... -
Page 3: Description
Description of FR-850 Design This appliance is supplied as a complete suite of gas fire burner unit, enclosure and fascia. To comply with the approval this fire must be installed as designed. There are two versions which can be purchased by the customer depending on site specific conditions like chimney size and room ventilation. -
Page 4: Technical Specification
Important Note: This fire is available in two versions. Please check the paperwork and data plate on the fire to confirm which version has been purchased. [Read the description on page 3] MODEL FR-850-V FR-850-V FR-850-NV* Gas Type Natural Gas... -
Page 5: Read This First
Flue System: • RIBBON FR-850-V – Class 1 or 180mm flue of minimum 2 metres. RIBBON FR-850-NV – Class 2 or 130mm flue of minimum 3 metres... -
Page 6: Parts List
Read this installation booklet fully before starting to install the appliance. Special note should be taken to the different installation requirements of the two versions (FR-850-V and FR-850-NV). Check the delivery paperwork and Data Plate inside the fire to confirm which version was purchased by the customer. - Page 7 Construction Dimensions The Spigot on the gather depends on which version was ordered by the customer. Check the data plate and the description on page 3. Page 7 of 58...
-
Page 8: Gas Burner Construction
Gas Burner Construction Use the image below to review the burner construction taking note of the positions of the main components and the required connections. The burner bar is pre-fitted to the enclosure. There is no reason why this should ever be removed. Before starting to install the appliance review the Data Plate fitted to the appliance for the gas type and pressure requirements of the appliance. -
Page 9: Remote Control System
Remote Control System Take some time to learn about the remote system fitted to this fire. The remote system features an RF (radio frequency) handset. The handset and the remote black box must be matched together to work correctly. Read the full section later in this manual to ensure you understand how the remote system works. -
Page 10: Installation Requirements
FR-850-V – Class 1 or 180mm flue of minimum 2 metres FR-850-NV – Class 2 or 130mm flue of minimum 3 metres (this model can also be used with the same flue as the FR-850-V) Page 10 of 58... - Page 11 FR-850-V: This version of the gas fire requires an air vent within the room which will provide a minimum of 100cm2 free air in accordance with National Regulations.
-
Page 12: Burner Ventilation
Did you check the flow rates as shown on page 4? Air Ventilation: First check if you are installing FR-850-V by checking the data plate within the fire. If this model is installed you will need to install a 100cm2 air vent in the same room. - Page 13 When the fascia is fitted to the wall air is provided a gap at the bottom and the slot on the enclosure. The slot in the enclosure must not be covered. The fascia is mounted so that it allows air to pass between it and the wall into the burner slot.
-
Page 14: Building & Installation Work
Building and Installation Work Gas Supply Consult the Data Plate within the appliance to ensure the correct gas type and pressure is available within the property. Before commencing to create the fire opening for the inglenook unit note that a gas supply is required. The gas supply pipe should run into the installed enclosure from either the rear, left or right hand sides, the gas supply is best run through the right side of the enclosure. - Page 15 Preparing the Fireplace Opening Above shows the minimum fireplace opening width and height. The image shows the fireplace opening required to install the fireplace unit. The gather can be installed by first inserting this into the fireplace opening. The fire body is then inserted into the opening and the gather lowered down onto the enclosure.
- Page 16 Above shows the minimum depth of the wall and the maximum lintel size when fitting the fire with the gather. Add 20mm to this for the front face of the finished wall (plaster board). The enclosure can be deeper however any voids should be filled otherwise there is a risk of “banging”...
- Page 17 Fireplace Clearance The fire must sit forward 40mm from the brickwork. This is to ensure the fire is correctly fitted for the stone fascia and burner ventilation. Position the enclosure in the opening so there is a minimum clearance of 10mm on each side and 10mm at the top.
- Page 18 Without Gather When not using the optional gather the enclosure must be sealed to the chimney. With Gather The gather should be sealed to ensure all flue gases enter the chimney and cannot leak back in to the room. Once the fire is fixed in place the fire can be finished with plasterboard.
- Page 19 Add the Plaster Board WARNING: The burner needs ventilation from the room and this is provided by a slot behind the fascia. To achieve the correct ventilation the enclosure must protrude into the room 20mm from the finished wall. See following images.
- Page 20 The image above shows the fire correctly positioned with the enclosure 20mm forward of the finished wall. When installed correctly the fire will look like the below image. Page 20 of 58...
- Page 21 Add the Stone Fascia The stone fascia is mounted to the wall using a special 2-part bracket. The first part is mounted onto the wall. The second part is fixed to the stone at the factory. If the fascia is damaged a new one must be obtained from the factory. Only the fascia supplied with the fire can be used with FIRE RIBBON.
- Page 22 Lift the Stone into Position. Lift the stone on to the wall bracket and secure by replacing the screws around the perimeter. When installed correctly air can flow below the fascia into the burner tray – see image below. The gas can now be connected and the fire commissioned. Page 22 of 58...
- Page 23 Connecting the Gas. Remove the front shelf. The gas line should now be connected to the 8mm inlet isolation valve with built in test point. Once connected perform a drop test to ensure no leaks in the pipe work up to the gas appliance. Remove the heat shield to gain access to the remote control unit so that the power switch put in the “on”...
-
Page 24: Commissioning The Appliance
COMMISSIONING THE APPLIANCE WARNING: The burner inlet flow rates are factory set and cannot be changed. The aeration is fixed; do not change the burner aeration. This fire must not be operated without the heat shield in place over the remote system. Failure to do this will result in serious damage to the remote system which will not be covered by the warranty. - Page 25 IF THE TEST IS FAILED: If it is not possible to maintain the pressure • at the required level the problem may be caused by blockages in the pipework, incorrect pipe sizing or a faulty meter. If the problem is the meter then TRANSCO, BORD GAIS or the propane supplier must be called to adjust the governor.
- Page 26 FR850 – Log Layout - 14 Piece Log Set Fit logs numbered 4 & 3 Fit logs numbered 9 & 13 Add the Wool to the burner Add the Wool on top of cut out. Do not put wool near the pilot assembly.
- Page 27 Add logs numbered 14 & 17 Add logs numbered 5 & 8 Add logs numbered 15 & 11 Page 27 of 58...
- Page 28 Add logs numbered 16 & 6 Add logs numbered 10 & 12 Final layout Page 28 of 58...
- Page 29 FR850 – Pebble Layout – 20 Pebbles The fire is supplied with 20 pebbles of various colours. These are arranged with 9 Pebbles along the back, 11 pebbles along the front. The pebbles must not touch the burner and are positioned on the vanity cover. See images below. Add the Wool between the pebbles and along the burner bar.
-
Page 30: Final Safety Check List
• The customer must be told not to block the air vent (FR-850-V only) • The warranty card is to be completed by the registered engineer who has commissioned the appliance. This is to validate the warranty. The card must then be given to the customer for postage back to the factory. - Page 31 Commissioning Checklist This product is guaranteed for 1 year from the date of delivery, as set out in the terms and conditions of sale. This guarantee will be invalid, to the extent permitted by law, if the above Commissioning Checklist is not fully completed by the installer. Installation Company…………………………………….………………………………………………..
-
Page 32: Fire Guards & Hearths
Warning: Fire Guards & Hearths This appliance is not fitted with an integral guard. In normal use consideration may be given to the use of a fireguard conforming to BS6539 or BS6778, so that the approach to the appliance is limited such that access to the flame is minimised It is recommended that a fireguard conforming to BS6539 or BS6778 is used for the protection of young children, the elderly and infirm. -
Page 33: Technical: Fault Diagnosis & Troubleshooting
Technical: Fault Diagnosis & Troubleshooting Every gas fire manufactured by Spirit Fires is tested at the factory and given a full 40 point performance check to ensure it operates correctly. It is highly unlikely that when installed in line with these instructions that it would not operate as designed. -
Page 34: Hand Set Error Codes
Faults – Hand Set Error Codes The handset will display an error code if a fault occurs. Refer to the separate sheet included with the manual for a full description of why the fire has failed before attempting to repair the fire. If the error code sheet is not available call customer services on 01325-327221. -
Page 35: Spark Or Ignition Failure
Pilot Assembly / ODS There is a highly sensitive oxygen depletion sensor designed into the pilot light. If any part is damaged the entire unit must be replaced. Do not attempt to bend or alter the flame head, thermocouple or aeration hole. Use only genuine spare parts as similar looking parts from other appliances may well give different or inferior performance and could lead to a hazard. -
Page 36: Burner Flame
Burner Flame The flame on this type of appliance is normally directed towards the rear of the enclosure. This is normal due to the opening size and flue system. The flame will never stand “upright”. It is to be expected that over time the surface on the rear of the enclosure will tarnish. -
Page 37: Service And Aftercare Requirements
Service and Aftercare Requirements Every 12 months the gas fire unit should undergo a regular service; this work should be carried out by a Gas Safe registered engineer only. The annual service of the unit must be performed in line with the instructions in the manual. -
Page 38: Servicing Instructions
Servicing Instructions The following servicing procedure should be carried out every 12 months and only by a registered Gas Safe Engineer. As foreign bodies, which can gather on the surface of the burner unit, it is inevitable that servicing can be a dusty operation therefore suitable precautions should be taken. -
Page 39: Spare Parts / Components List
• BURNER: Using a soft brush or vacuum cleaner, carefully remove any debris from the burner unit. • FINAL STEPS: Re-assemble the fire in the reverse order, and re- connect the gas supply and check for leaks. • Check the pilot assembly for a good strong flame. - Page 40 Page 40 of 58...
- Page 41 PIN NUMBER: 0558CP1695 Rev 2 RIVER (FR850 & FR850NV) [With ANTOSS Remote] USER HANDBOOK Serial Number ……………………………… For use with Natural Gas (G20) or LPG (G31) refer to data plate Please quote this serial number when calling to discuss installation and spare part requests.
- Page 42 Contents Page 43 General Information Page 44 Start/Shutdown Instructions Page 53 Using the Manual Switch Panel Page 54 Replacing the Batteries Page 55 Cleaning Instructions Page 56 Fire Guards and Hearths Page 57 Warranty Information Page 58 Contact Details Page 42 of 58...
-
Page 43: General Information
General Information A qualified GAS SAFE registered installer is required to fully install the appliance, failure to do this may render the appliance dangerous and will invalidate the warranty. This fire is intended for decorative purposes. Any purpose-provided ventilation should be checked regularly to ensure that it is free from obstruction. The fire should be serviced regularly by a qualified person. - Page 44 Lighting/Adjusting the Fire The appliance is supplied with an internal battery power supply and is operated via a handset. There are 3 x ‘AA’ batteries inside the appliance and 2 x AA batteries in the handset. Only use good quality alkaline batteries to ensure a long life from the handset and remote box.
-
Page 45: Operating Instruction
Mode – Time (12hour or 24 hr MAN (Manual), Zzz display) (Snooze), thermostat or timed Day of the week In Range of fire (missing if not in range or if Fire Control turned off) Gas fire burner status Room Temperature Battery condition –... - Page 46 Ensure the power isolator switch on the front corner of Fire Control Black Box within the Fire is in the on position (I). Note: The handset has a child safe function. To unlock the handset you must grasp the handset in the palm of your hand. The green unlock light will illuminate to show when the handset is unlocked and ready to accept commands.
- Page 47 Adjusting the Flame • Grasp the handset in the palm of the hand and sides to unlock the child safe mode. The green unlock light will illuminate. Keep the handset held to keep the control unlocked, to enable operation of the buttons. •...
- Page 48 Setting the Time Should you have to set the time or change the time you need to enter the SETUP menu. Hold the handset to unlock the keypad and keep held throughout the following steps, (if you release too soon the menu will exit and you will have to start again).
- Page 49 Setting the Hour Press and release the + or – button to change the hour to the correct hour and press set to store and to move to setting the minute. Repeat this for setting the minutes. Setting the temperature display to Celsius or Fahrenheit. Press and release the + or - button to toggle between C and F.
- Page 50 How to Find the Hand Set If you have misplaced the handset you can page it by pressing the + button only on the fire control for around 5 seconds. The handset will flash and make a noise to help you to locate it. Once you pick up the TESC it knows you hold it and so the sound stops.
- Page 51 Use these instructions to “Pair” the handset to the fire gas control inside the READ WARNING ABOVE BEFORE PROCEEDING. fire. Step 1 - Factory Reset of display handset This needs to be done first to enable the handset to be paired again. •...
- Page 52 N.B. If the display returns to the one shown above with the word “TESC” shown, then too much time has passed before pressing “SET” and so the handset has not paired yet. Simply repeat pairing again. N.B. Only ever press “+” and “-“ buttons together when pairing handsets. If done afterwards this will break the pairing made and a factory reset of the handset will need to be performed See Factory Reset of display handset later on in the instructions.
- Page 53 Thermostatic Mode The handset has within it a thermostat sensor and this can be set so the fire will heat the room to match the temperature set in the handset. Hold handset so that it unlocks then press and release the mode button several times as necessary until the display has a thermometer symbol flashing at the top of the display.
- Page 54 Replacing the Batteries Handset Batteries. To replace the handset batteries open the cover on the back of the handset. Remove the old batteries and using the diagram on the inside of the cover fit new high quality alkaline batteries. Main Appliance Batteries These are inside the gas fire body.
-
Page 55: Cleaning Instructions
Step 3: Remove the heat shield from the gas control. This is a special sleeve that is over the gas control. It must be replaced. Step 4: Remove the battery cover from the gas control. Remove the old batteries and using the diagram on the inside of the cover fit new high quality alkaline batteries. - Page 56 Removing the Burner Bar Deposits It is normal for the burner bar to show a reddish or white deposit. This is caused by bi-products of the gas being burnt and is unavoidable. This can be remedied by cleaning off the deposits with a using cloth then using a stove paint like Hotspot High Temperature Stove Paint which is sold in 100ml cans online for approx £7.
-
Page 57: Warranty Information
WARRANTY INFORMATION This appliance is supplied with a 12 month warranty from the date of delivery. The Warranty covers defective parts only and does not cover typical wear and tear that occurs with a gas fire appliance. This gas appliance carries full CE approval and has a long and reliable history. The fire is given over 40 function tests during the manufacturing process and is fully working before being shipped. - Page 58 ONLY USE GENUINE REPLACEMENT PARTS. Spirit Fires Ltd, 4 Beaumont Square Aycliffe Industrial Park, Newton Aycliffe County Durham, DL5 6XN T – 01325 327 221 F – 01325 327 292 www.spiritfires.co.uk sales@spiritfires.co.uk This revision is dated on the 20-10-2015. The information supplied in this manual is correct at the time of publication.
