CE PIN NUMBER: 0558BQ5590
PIN: 160590
Appliance Type: B-11AS
Appliance Catergories: I2H, I2E, I2E+, I2L, I3P(37), I3+, I3B/P(30)
Serial Number
Please quote this serial number when contacting CVO Fire regarding warranty and spare part issues.
•
It is recommended, even if you have installed these appliances before, that you take the
time to read through these instructions and follow them step by step.
•
The appliance is CE approved for use with Natural Gas – I2H, I2E, I2L, I2E+ and LPG I3P, I3+,
I3B/P. Check the data plate for actual appliance setting.
•
This manual must be handed to the owner of the property once the appliance is
commissioned and retained onsite for operation and servicing reference.
•
The appliance has a manufacturers warranty valid for 1 year from date of delivery. In order
to validate the warranty the appliance must be installed by a CORGI Engineer. The warranty
card supplied with this booklet should be completed by the CORGI Engineer and posted to :
Customer Service Dept, CVO Fire. 4 Beaumont Square, Aycliffe Industrial Park, Newton
Aycliffe. County Durham. DL5 6XN.
•
Whenever contacting CVO Fire regarding the appliance please have the serial number and the
installers CORGI registration number available.
GEOMETRIX™ - CUBE
(Manual Control Version)
INSTALLATION MANUAL
Important
Advertisement
Chapters
Table of Contents
Related Manuals for CVO Fire GEOMETRIX - CUBE
Summary of Contents for CVO Fire GEOMETRIX - CUBE
- Page 1 Appliance Type: B-11AS Appliance Catergories: I2H, I2E, I2E+, I2L, I3P(37), I3+, I3B/P(30) Serial Number Please quote this serial number when contacting CVO Fire regarding warranty and spare part issues. Important • It is recommended, even if you have installed these appliances before, that you take the time to read through these instructions and follow them step by step.
-
Page 2: Table Of Contents
Contents Appliance Technical Data Appliance General Information Warning for Fire Guards and Hearths Appliance Unpacking Instructions Appliance Installation Instructions Appliance Commissioning Instructions Appliance Start Up / Shut Down Instructions Appliance Fault Diagnosis Instructions Appliance Cleaning Instructions Appliance Servicing Instructions Appliance Spare Parts Every appliance has been designed, manufactured and type tested to ensure that it conforms to the current national and European DFE (decorative fuel effect gas fire) legislation. -
Page 3: Appliance Technical Data
1. Appliance Technical Data 1.1. General Specification Oxy Pilot Assembly Marking Natural Gas Burner : P4-10D , LPG Burner – P4-16 Gas Connection Size 8.0mm O.D. tubing Minimum Flue Diameter (Millimetres/Inches) 127.0/5.0 Minimum Flue Height (metres) Appliance Mass (kilograms) Countries of Destination Gas Category, Type Type And Supply Pressure... -
Page 4: Appliance General Information
2. Appliance General Information The appliance is intended for decorative purposes only. The chimney should be swept before the appliance is installed, and should be swept and inspected regularly to ensure that all products of combustion are entering the flue and there is no excessive build up of soot. - Page 5 placing combustible material directly in front of the appliance.
-
Page 6: Appliance Unpacking Instructions
4. Appliance Unpacking Instructions Carefully examine the carton for damage before unpacking. If the appliance is damaged, consult your supplier over whether to proceed. Remove the appliance and examine its general condition. If satisfied by the condition of the product, proceed with the installation. 5. - Page 7 The appliance is supplied with a base plate. This must be installed to a flat, level surface using the two fixing points shown below. When using the standard CVO Fire Enclosure pilot holes are given to ensure correct positioning of the burner.
-
Page 8: Appliance Commissioning Instructions
If you have any questions, or the appliance is not operating correctly, please consult the fault diagnosis chart and then contact the CVO Fire technical team BEFORE you leave the installation. As part of our customer service procedure you will be asked for the appliance serial number on the front cover of this booklet and the CORGI Registration number of the Engineer. -
Page 9: Appliance Start Up / Shut Down Instructions
7. Appliance Start Up / Shut Down Instructions If the main burner or pilot light is extinguished during lighting, do not attempt to re- light the pilot within three minutes. The functions of the control valve are depicted on the control panel around the control knob. -
Page 10: Appliance Fault Diagnosis Instructions
8. Appliance Fault Diagnosis Instructions All CVO Fire appliances are given a full function test at the factory including being run for a number of minutes on full gas supply to ensure that the appliance functions correctly. It is highly unlikely, that if the appliance has been installed correctly as set out in this manual that the appliance will not function. -
Page 11: Appliance Cleaning Instructions
Always move in the direction of the grain of the steel. Ensure no cleaning materials come in contact with the matting surface as damage may occur. 10. Appliance Servicing Instructions CVO Fire recommends that the appliance is serviced every 12 months by a CORGI Engineer. -
Page 12: Appliance Spare Parts
NG – P4 – 10D – AC047 3. Pilot Assembly –[ LPG – P4 – 16 – AC007 If the ceramic matting becomes damaged it can only be replaced by CVO Fire. To order spare parts please contact: CVO Fire Customer Service on 01325 301 020... - Page 13 December 2008. There may be changes made in future as we improve our products. If there are any queries please write to or call our technical department. The CVO Fire brand is owned and manufactured by: Spirit Fires Ltd,...
- Page 14 CORGI Engineer and posted to : Customer Service Dept, CVO Fire. 4 Beaumont Square, Aycliffe Industrial Park, Newton Aycliffe. County Durham. DL5 6XN. • Whenever contacting CVO Fire regarding the appliance please have the serial number and the installers CORGI registration number available.
- Page 15 Contents Appliance General Information Warning for Fire Guards and Hearths Appliance Unpacking Instructions Appliance Installation Procedure Appliance Start Up / Shut Down Instructions Appliance Cleaning Instructions Appliance Servicing Instructions Appliance Spare Parts Every appliance has been designed, manufactured and type tested to ensure that it conforms to the current national and European DFE (decorative fuel effect gas fire) legislation.
-
Page 16: Appliance General Information
1. Appliance General Information The appliance is intended for decorative purposes only. The chimney should be swept and inspected regularly to ensure that all products of combustion are entering the flue and there is no excessive build up of soot. Foreign objects should not be placed on to the appliance or otherwise disturb the fuel bed. -
Page 17: Appliance Installation Procedure
4. Appliance Installation Procedure (For User Reference Only) Clearances between the appliance and all combustible materials must conform to national regulations. The appliance must be installed and used in accordance with these instructions. Prior to installation, ensure that the local distribution conditions (identification of the type of gas and pressure and the adjustment of the appliance) are compatible. -
Page 18: Appliance Cleaning Instructions
Once the pilot is lit, continue to hold the control knob in for 10-12 seconds. In this time the pilot flame will heat the flame supervision thermocouple, operating a hold-on magnet within the valve. Next release the knob and turn anti-clockwise a further 90°. This will allow gas to enter the burner at a low rate and be ignited by the pilot flame. -
Page 19: Appliance Servicing Instructions
Always move in the direction of the grain of the steel. Ensure no cleaning materials come in contact with the matting surface as damage may occur. 7. Appliance Servicing Instructions CVO Fire recommends that the appliance is serviced every 12 months by a CORGI Engineer. - Page 20 December 2008. There may be changes made in future as we improve our products. If there are any queries please write to or call our technical department. The CVO Fire brand is owned and manufactured by: Spirit Fires Ltd,...
