Above/Below Clamp-on 13" Dual Shelf
Instruction Manual
SKU: STAND-SHELF2C
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-shelf2c
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo STAND-SHELF2C
Summary of Contents for Vivo STAND-SHELF2C
- Page 1 Above/Below Clamp-on 13” Dual Shelf Instruction Manual SKU: STAND-SHELF2C Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-shelf2c GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Secure Shelf (A) into top holes on Vertical Support (B) using M6x30mm Screws (S-C) and 4mm Allen Wrench (T-A). Secure remaining Shelf (A) to Shelf Bracket (C) using M6x30mm Screws (S-C) and 4mm Allen Wrench (T-A). Attach Shelf Bracket (C) to middle holes of Vertical Support (B) using M6x30mm Screws (S-C) and 4mm Allen Wrench... -
Page 4: Installation Steps
INSTALLATION STEPS INSTALLATION OPTIONS: Choose your desired installation method and follow appropriate steps below. ABOVE DESK BELOW DESK Page 4-5 Page 6-7 Above Desk STEP 1 Thread M8x40mm Screws (S-D) into Clamp Braces (D) with Clamp Plate (E), M4x10mm Screws (S-A) and M4 washer (S-E). Tighten using 6mm Allen Wrench (T-B) and a Phillips Screwdriver. - Page 5 STEP 2 Remove adhesive backing from Soft Pads (F) and Foam Pads (G) and apply them to Vertical Supports (B) as shown below. STEP 3 Secure the shelf assembly above the desktop by tightening M8x40mm Screws (S-D) using 6mm Allen Wrench (T-B).
- Page 6 Below Desk STEP 1 Thread M8x40mm Screws (S-D) into Vertical Supports (B) with Clamp Plates (E), M4x10mm Screws (S-A) and M4 Washers (S-E). Tighten using 6mm Allen Wrench (T-B) and a Phillips Screwdriver. STEP 2 Assemble Clamp Braces (D) to Vertical Supports (B) using M6x12mm Screws (S-B) and 4mm Allen Wrench (T-A).
- Page 7 STEP 3 Remove adhesive backing from Soft Pads (F) and apply them to Clamp Braces (D) as shown below. Secure the shelf assembly below the desktop by tightening M8x40mm Screws (S-D) using 6mm Allen Wrench (T-B).
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
