Sit to Stand Dual Monitor Desk Mount Workstation
with USB
Instruction Manual
SKU: STAND-SIT2DD
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-sit2dd
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo STAND-SIT2DD
Summary of Contents for Vivo STAND-SIT2DD
- Page 1 Sit to Stand Dual Monitor Desk Mount Workstation with USB Instruction Manual SKU: STAND-SIT2DD Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-sit2dd GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. Failure to do so may result in serious injury. 0 - 13.2 lbs 2.2 lbs Phillips (0 - 6 kg) (1 kg) Screwdriver PER ARM KEYBOARD ASSEMBLY STEPS STEP 1 OPTION A: Clamp Installation Attach clamp brace (I) to base (A) using M6x12 bolts (V), and tighten with 4mm Allen wrench (O).
- Page 4 STEP 2 Carefully extend the adjustable arm (B) to the raised position as shown. Insert the adjustable arm into the socket of the base, then secure using the 3mm Allen wrench (N). STEP 3 Remove the knob from the lower support arm (E) to separate into lower support arm (E1) and knob (E2).
- Page 5 STEP 6 Mount upper support arm (G) to lower support arm using M8x25 bolts (T) and tighten with 6mm Allen wrench (P). STEP 7 Place the support arm/tray assembly onto the upper post of the adjustable arm, then secure using the wrench (N).
- Page 6 STEP 9 Remove the knob from arm (F). Slide the arm onto the upper support arm, then reinstall the knob. Tighten the bolts with the 4mm Allen wrench (O) to secure height. STEP 10 Install the VESA plate (L) to monitor using M4x12 bolts (M-A) or M5x12 bolts (M-B) with washers (M-C), making sure the rounded edges of the rear bracket are facing up.
- Page 7 STEP 12 Loosen knob in back to adjust monitor height. To adjust gas spring support, turn the hex screw on top of the rear joint using the 6mm Allen wrench (P). Counter- clockwise will increase support, and clockwise will decrease support. STEP 13 STEP 14 Install rear cover (H) to clamp brace if the clamp...
- Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
