- Page 1 Sit-Stand Desk Mount Instruction Manual SKU: STAND-SIT2B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-sit2b help@vivo-us.com www.vivo-us.com 1-800-371-5654...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
-
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 17.6 lbs Failure to do so may result in serious injury. (8 kg) Per Arm Phillips 2.2lbs Screwdriver (1kg) Keyboard ASSEMBLY STEPS STEP 1 Slide base cover (E) over pole (M). STEP 2 OPTION A: Clamp Installation Attach five rubber pads (K) to clamp (B). - Page 4 STEP 2 (Continued) OPTION B: Grommet Installation If you are securing the stand to the desktop without clamp (B), use existing grommet hole, or drill a ⅜” (10mm) hole. Attach base (C) to pole (M). Tighten grub screws in base (C) using 3mm Allen key (P).
- Page 5 STEP 3 (Continued) Attach keyboard tray (H) to arm (A) using four bolts (O) and four nuts (N). Tighten using wrench (R) and Phillips screwdriver. Place pad (I) on left or right side of keyboard tray (H). STEP 4 OPTION A: Flat Back Monitor Attach VESA plates (F) to back of monitors using bolts (M-A,M-C) and washers (M-E).
- Page 6 STEP 5 Slide monitors with VESA plates (F) onto monitors arms (G). Secure using thumb screws (L). STEP 6 Adjust the tension of monitor and keyboard arms using 6mm Allen key (Q). Remove the bottom covers as shown. Place cables into covers, then reattach to arms. Use cable management clips (J) to further organize cables.
- Page 7 STEP 7 Adjust tension of tilt joints using 6mm Allen key (Q) to hold monitor and keyboard at desired angles. Store Allen keys (Q, P) in clips. Adjust as Desired 90° +35° -35° 180° 90° 180° 30° 90°...
- Page 8 Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product.
