Ruijie Reyee RG-EG105GW-X Hardware Installation And Reference Manual page 13

Hardware Installation and Reference Guide
Power Adjustment
Dimensions (W × D × H)
Weight
Service Port
Management Port
Status LED
Power Supply
Max Power Consumption
Environment
Mounting Method
Safety Regulation
Compliance
Shock and Vibration
Radio Standard
MTBF
Thailand：
2400MHz~2483.5MHz：≤ 20dBm
5150MHz~5350MHz：≤ 23dBm
5470MHz~5725MHz：≤ 25dBm
5725MHz~5850MHz：≤ 30dBm
Configurable in increments of 1 dBm
283 mm × 172 mm × 46 mm (11.14 in. × 6.77 in. × 1.81 in.)
Note: The value (46 mm/1.81 in.) only indicates the height of the main unit,
excluding that of the antenna.
≤ 2 kg (4.41 lbs)
One 10/100/1000Base-T WAN port
One 10/100/1000Base-T LAN port
Three 10/100/1000Base-T WAN/LAN switchable ports
N/A
System status LED, Mesh LED and port LEDs
Local power supply: 100 V AC to 240 V AC
20 W
Operating temperature: 0° C to 40° C (32° F to 104° F)
Storage temperature: –40° C to 70° C (–40° F to 158° F)
Operating humidity: 5% to 95% (non-condensing)
Storage humidity: 5% to 95% (non-condensing)
Workbench mounting and wall mounting
GB 4943.1
IEC61373
EN300 328, EN301 893
> 400,000 hours
7
Product Overview
