007333 D17 Kohler/Lombardini
Used with
LT28D17
LT28D18
Designation changed from D18 to D17 per
ECN 19807 on 11/122013 to more accurately
describe the power.
WARNING! Read and understand this
!
manual before using this machine.
LT28 D17 Engine
& Parts Manual
Safety is our #1 concern!
October 2009
rev. D
Form #1633
rev. A6.07 - A6.17
rev. A6.00 - A6.06
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wood-mizer LT28 D17
Summary of Contents for Wood-mizer LT28 D17
- Page 1 LT28 D17 Engine Safety, Operation, Maintenance & Parts Manual 007333 D17 Kohler/Lombardini rev. D Safety is our #1 concern! October 2009 Form #1633 Used with LT28D17 rev. A6.07 - A6.17 LT28D18 rev. A6.00 - A6.06 Designation changed from D18 to D17 per ECN 19807 on 11/122013 to more accurately describe the power.
- Page 2 Active Patents assigned to Wood-Mizer, LLC Wood-Mizer, LLC has received patents that protect our inventions which are a result of a dedication to research, innovation, development, and design. Learn more at: woodmizer.com/patents ©2023 Wood-Mizer LLC Printed in the United States of America, all rights reserved. No part of this manual may be reproduced in any form by any...
-
Page 3: Table Of Contents
Table of Contents Section-Page SECTION 1 OPERATION AND MAINTENANCE Starting The Engine ................1-1 Safety ..................... 1-1 Battery....................1-2 Fuel Filter....................1-2 SECTION 2 SECTION 3 REPLACEMENT PARTS Fuel Tank Rev. A6.13+................. 2-1 Fuel Tank Rev. A6.06 - A6.12 ............2-2 Engine Assembly ................... -
Page 4: Section 1 Operation And Maintenance
ABOUT THIS MANUAL This manual is provided as a supplement to the equipment manufacturer’s manuals. This manual provides information spe- cific to the use of this equipment on the Wood-Mizer sawmill. Refer to the sawmill operator’s manual and manufacturer's ®... -
Page 5: Battery
Maintenance Battery DANGER! Always be aware of and take proper protective measures against rotating shafts, pul- leys, fans, etc. Always stay a safe distance from rotating members and make sure that loose clothing or long hair does not engage rotating members. Never touch or perform service functions on a hot engine. -
Page 6: Fuel Tank Rev. A6.13
Replacement Parts Fuel Tank Rev. A6.13+ SECTION 2 REPLACEMENT PARTS Fuel Tank Rev. A6.13+ 280062B PART # DESCRIPTION COMMENTS QTY. 074829 TRAY ASSEMBLY, LT28/35 FUEL TANK 103810 Weldment, Fuel Tank Tray 103867 Cover, Fuel Tank 103928 Tank, 5 Gallon Low Pro Diesel 061257 Cap, Fuel Tank Diesel 080185BE 061255... -
Page 7: Fuel Tank Rev. A6.06 - A6.12
Replacement Parts Fuel Tank Rev. A6.06 - A6.12 Fuel Tank Rev. A6.06 - A6.12 280047-1C PART # DESCRIPTION COMMENTS QTY. TRAY ASSEMBLY, LT28 DIESEL CAN 038580 Rev. A6.06 - A6.12 only A12132 Tank Assembly, 5-Gallon Diesel Fuel P12166 Tank, 5-Gallon Diesel Fuel Available in assemblies only. -
Page 8: Engine Assembly
Replacement Parts Engine Assembly Engine Assembly 150174-1C PART # DESCRIPTION COMMENTS QTY. 007333 ENGINE ASSEMBLY, LT15 17HP DIESEL 007332 Engine, 17HP Kohler Diesel Model KDW702 Available in assemblies only. 007401 Filter Assembly, Kohler #ED0037004550-S 007613 Filter, Kohler Secondary Air #ED0021751250-S 007408 Filter, Kohler Primary Air #ED0021751240-S... - Page 9 Replacement Parts Engine Assembly PART # DESCRIPTION COMMENTS QTY. 014278 Plug, Diesel Glow 062308 Bracket, Air Filter Mount F05006-18 Bolt, 5/16-18 x 1 1/4” Hex Head Full Thread F05011-17 Washer, 5/16” SAE Flat F05010-20 Nut, 5/16-18 Self-Locking Hex P09895 Clamp, 2 1/2” Hose 007394 Elbow, 90°...
-
Page 10: Throttle/Clutch Assembly
Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly 280059-2D PART # DESCRIPTION COMMENTS QTY. BLOCK WELDMENT, LINKAGE CLUTCH/BRAKE 065574 F05012-16 PIN, 3/16” X 1 1/4” ROLL 016486 BUSHING, 5/8” ID X 7/8” OD X 1 1/4” LONG FL BRONZE 049340 SHAFT, LT28 THROTTLE 034815 ACTUATOR WELDMENT, THROTTLE LT15D&G F05007-68... - Page 11 Replacement Parts Throttle/Clutch Assembly PART # DESCRIPTION COMMENTS QTY. BRAKE/CLUTCH ASSEMBLY 065874 065873 Arm Weldment, Clutch/Brake F05007-124 Bolt, 3/8-16 x 2 Hex Head Grade 5 F05010-10 Nut, 3/8-16 Hex Nyl Lock F05011-3 Washer, 3/8” Flat SAE F05010-25 Nut, 3/8-16 Swaged 034810 Spring, Idler Arm LT15/D/E/G 034602...
