- Page 1 LT28 D17 Engine Safety, Operation, Maintenance & Parts Manual LT28D17 rev. A6.00 - A6.15 only Safety is our #1 concern! Read and understand all safety information and instructions before oper- ating, setting up or maintaining this machine. October 2009 Form #1633...
- Page 2 For more information go to www.P65Warnings.ca.gov/wood. Active Patents assigned to Wood-Mizer, LLC Wood-Mizer, LLC has received patents that protect our inventions which are a result of a dedication to research, innovation, development, and design. Learn more at: woodmizer.com/patents ©2022 Wood-Mizer LLC...
-
Page 3: Table Of Contents
Table of Contents Section-Page SECTION 1 ABOUT THIS MANUAL SECTION 2 OPERATION Starting The Engine................2-1 SECTION 3 MAINTENANCE Maintenance ...................3-1 Safety......................3-1 Battery ....................3-1 Fuel Filter ....................3-2 SECTION 4 REPLACEMENT PARTS Fuel Tank....................4-1 Engine Assembly..................5-1 Throttle/Clutch Assembly ..............6-1 Table of Contents WMdoc091622... -
Page 4: About This Manual
SECTION 1 ABOUT THIS MANUAL This manual is provided as a supplement to the equipment manufacturer’s manuals. This manual provides information specific to the use of this equipment on the Wood-Mizer ® sawmill. Refer to the sawmill operator’s manual and manufacturer's manual before attempting to operate this equipment. -
Page 5: Operation
Operation Starting The Engine SECTION 2 OPERATION Starting The Engine DANGER! Always be sure the blade is disengaged and clear the path of the blade before starting the engine. Failure to do so will result in serious injury or death. DANGER! Operate your engine/machine only in well ventilated areas.Exhaust gases can cause nausea, delirium and potentially death unless adequate ventilation is pres-... -
Page 6: Maintenance
Maintenance Maintenance SECTION 3 MAINTENANCE Maintenance Refer to the manufacturer’s manual for maintenance intervals and procedures unless otherwise instructed in this manual. Fol- low the manufacturer’s recommendations for dusty conditions. IMPORTANT! This manual only provides information about additional proce- dures or procedures to be performed at different time intervals than found in the manufacturer's manuals. -
Page 7: Fuel Filter
Maintenance Fuel Filter Fuel Filter Replace the fuel filter every 100 hours of operation or as required for engine performance. Maintenance WM doc 9/16/22... -
Page 8: Replacement Parts
Replacement Parts Fuel Tank SECTION 4 REPLACEMENT PARTS Fuel Tank 280062B PART # DESCRIPTION COMMENTS QTY. 074829 TRAY ASSEMBLY, LT28/35 FUEL TANK 103810 Weldment, Fuel Tank Tray 103867 Cover, Fuel Tank 103928 Tank, 5 Gallon Low Pro Diesel 061257 Cap, Fuel Tank Diesel 080185BE 061255 Fitting, Pick-Up/Tube Diesel 468871A 061250... -
Page 9: Engine Assembly
Replacement Parts Engine Assembly Engine Assembly 150174-1C PART # DESCRIPTION COMMENTS QTY. 007333 ENGINE ASSEMBLY, LT15 17HP DIESEL 007332 Engine, 17HP Kohler Diesel Model KDW702 Available in assemblies only. 007401 Filter Assembly, Kohler #ED0037004550-S 007613 Filter, Kohler Secondary Air #ED0021751250-S 007408 Filter, Kohler Primary Air #ED0021751240-S... - Page 10 Replacement Parts Engine Assembly PART # DESCRIPTION COMMENTS QTY. 014278 Plug, Diesel Glow 062308 Bracket, Air Filter Mount F05006-18 Bolt, 5/16-18 x 1 1/4” Hex Head Full Thread F05011-17 Washer, 5/16” SAE Flat F05010-20 Nut, 5/16-18 Self-Locking Hex P09895 Clamp, 2 1/2” Hose 007394 Elbow, 90°...
-
Page 11: Throttle/Clutch Assembly
Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly 280059-2D PART # DESCRIPTION COMMENTS QTY. BLOCK WELDMENT, LINKAGE CLUTCH/BRAKE 065574 F05012-16 PIN, 3/16” X 1 1/4” ROLL 016486 BUSHING, 5/8” ID X 7/8” OD X 1 1/4” LONG FL BRONZE 049340 SHAFT, LT28 THROTTLE 034815 ACTUATOR WELDMENT, THROTTLE LT15D&G F05007-68... - Page 12 Replacement Parts Throttle/Clutch Assembly PART # DESCRIPTION COMMENTS QTY. BRAKE/CLUTCH ASSEMBLY 065874 065873 Arm Weldment, Clutch/Brake F05007-124 Bolt, 3/8-16 x 2 Hex Head Grade 5 F05010-10 Nut, 3/8-16 Hex Nyl Lock F05011-3 Washer, 3/8” Flat SAE F05010-25 Nut, 3/8-16 Swaged 034810 Spring, Idler Arm LT15/D/E/G 034602...
