Eclipse
Four Drawer
11
Attach panels [11] to panel [2] as shown using 6x screws (O).
Tighten with a screwdriver.
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
O
11
2
O
O
O
O
11
O
O
12
C
C
Drawers x4
C
C
Insert 20x bolts (C) into panels [13] and [14]. Tighten with a screwdriver.
C
C
C
14
x2
C
C
C
13
x2
