Altronix TROVE T1SAK34D Installation Manual page 3

1. Fasten spacers onto metal pems configuration (A) of backplane (Fig. 2, pg. 3).
2. Position SALTO modules over corresponding spacers and mount them utilizing pan head screws (provided) (Fig. 2a, pg. 3).
3. Mount backplane to enclosure with hardware.
Access Controller Position Chart for the Following Models:
SALTO Access Controller
CU42E0, CU4200 or CU4EB8
Fig. 2
Altronix
AL600ULXB
+BAT-
Trove SALTO ULXB D Kits Installation Guide
T1SAK34D: Configuration of SALTO Modules:
+ DC -
A
PWR1 + OFF
IN1 Fuse
Altronix - PDS8CB
IN1
IN2
P
OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7
COM (--- )
N
PWR2 +
1 2 3 4 5 6 7
Common Power Outputs (NEG)
Altronix VR6 is mounted under PDS8CB
TRIGGER
INPUT
IN GND IN GND IN GND IN GND
1 2 3 4
Altronix - ACM4CB
LED1 LED2 LED3 LED4
MAIN
NC C NO COM NC C NO COM NC C NO COM NC C NO COM
OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4
A
Backplane
PWR1 +
OUT8
COM (--- )
PWR2 +
8
TRG
ACM4
ACCESS POWER
CONTROLLER
Pem Mounting
A
Fig. 2a
Pem
Spacer
HS4 Module
Pan Head Screw
- 3 -
