Classica Series - Opera PRIMA Installation Instructions Manual

TECHNICAL SPECIFICATIONS AND DIMENSIONS - CLASSICA series
20
3
70
90
157
210
HORIZONTAL SECURITY SOLENOID LOCK
› Stainless steel face plate and striking plate, hardened steel deadbolt/spring latch
› Versions with fail-safe or fail-secure deadbolt/spring latch
› Power supply: 12 ÷ 24 Vdc, peak current 3 A, holding current 130 ÷ 230 mA
› Ready for interlocking between 2 or more doors
› Opto-electronic control of deadbolt / spring latch position
› Electronic control (can be disabled) of reclosing timings
› Anti-rebound alignment ball (optional)
266/268
10
276/278
77
28
10
OP54036/38
160
76.5
25
8
23
240
90
115.7
25
23
4.5
12
25
150
12
55
4.5
Striking plate
25
13
160
13
30
7
