16
(22/27/32)
PRIMA OP
4
PRIMA / P . MAXI
(4) Gently insert the quick plug-in connector into the receiving connector
located on the solenoid lock at the indicated position.
PAY ATTENTION TO THE DIRECTION OF INSERTION.
14
8
23
255
23
8
23
PRIMA OP
32.5
26
32.5
PRIMA MAXI
CLASSICA
14
8
23
198
85
28
72
8
42.5
23
Continues...
11
42.5
355
