Table Of Functions - Opera PRIMA Installation Instructions Manual

16
Wire colour
Black
Black
Orange (green band)
Red (green band)
Brown (green band)
Green / black
Red / black
Brown
Yellow / black
Blue
Green
Orange
Yellow

TABLE OF FUNCTIONS

Function
Power supply
(non-polarized)
Common contact
Contact (N.O.)
Contact (N.C.)
Signal ground
(GND)
Opening
Door status
Interlock
Alarm / Failure
(item 246 - 248
only)
RESET
(item 246 - 248
only)
Emergency
(item 246 - 248
only)
Lockout
(item 246 - 248
only)
Description
Voltage : 12 ÷ 24 Vdc
Peak current : 3 A
Current (holding) : 300 mA
Voltage-free microswitch for remote
signalling of deadbolt position.
See NOTES.
GND reference of each control.
Not the - of power supply.
Impulsive command for deadbolt
release, from clean N.O. contact.
Door position signalling / alternate
magnetic sensor status. See NOTES
Input / output of interlock
connection.
See INTERLOCKING DIAGRAM.
Open Collector output for alarm
signalling. See NOTES.
N.O. impulsive contact to be
connected to GND for alarm reset.
N.O. impulsive contact to be
connected to GND for the immediate
unlocking of the door.
N.O. contact to be steadily
connected to GND in order to disable
the opening/closing of the deadlock
(excluding Emergency).
