Operating the Remote Controller
Install / Replace Batteries
Use two alkaline dry batteries (R03/LR03X2). Do not use rechargeable batteries.
(1) Remove the battery cover by pulling it according to the arrow direction.
(2) Insert new batteries making sure that the (+) and (-) of battery are installed correctly.
(3) Reattach the cover by sliding it back into position.
NOTE
When the Air Conditioner is ready for use, switch on the power and the OPERATION
indicator lamp on the display panel of the indoor unit starts flashing.
1. Use the Mode select button to select AUTO.
2. Push the or button to set the desired room temperature. The most comfortable temperature
settings are between 21°C to 28 °C.
3. Push the On/off button to start the air conditioner. The OPERATION lamp on the display
panel of the indoor unit lights. The operating mode is AUTO. The FAN SPEED is
automatically controlled.
4. Push the On/off button again to stop the unit operation.
AUTOMATIC OPERATION
1. When replacing batteries, do not use old batteries or a different type battery. This may
cause the remote controller to malfunction.
2. If you do not use the remote controller for several weeks remove the batteries. Otherwise
battery leakage may damage the remote controller.
3. The average battery life under normal use is about 6 months.
4. Replace the batteries when there is no answering beep from the indoor unit or if the
Transmission Indicator light fails to appear.
NOTE
1. In the AUTO mode, the air conditioner can logically choose the mode of COOL, FAN,
HEAT and DRY by sensing the difference between the actual ambient room temperature and
the set temperature on the remote controller.
2. If the AUTO mode is not comfortable for you , the desired mode can be selected manually.
COOL , HEAT, and FAN ONLY Operation
1. If the AUTO mode is not comfortable , you may manually override the settings by using
COOL, DRY, HEAT( HEAT PUMP units only), or FAN ONLY modes.
2. Push the or button to set the desired room temperature. When in COOLING mode, the
most comfortable settings are 21 °C or above. When in HEATING mode, the most
comfortable settings are 28 °C or b elow.
3. Push the Fan button to select the FAN mode of AUTO, HIGH, MED or LOW.
4. Push the On/off button. The operation lamp lights and the air conditioner starts to operate
per your settings. Push the On/off button again to stop this unit operation.
NOTE:
The FAN ONLY mode cannot be used to control the temperature. While in this mode, only
steps 1 3 and 4 may be performed.
