4RU filler panel
Terminal server 2
Terminal server 1
C3524 Ethernet switch
C3508 Ethernet switch
Rack
Airflow baffle
Sun TCF Star Rack Front View
FIGURE 3
Sun Technical Compute Farm Read Me First • December 2000
Cisco 2600
Cisco 2600
Compute
engine 4
Compute
engine 3
Compute
engine 2
Compute
engine 1
File server
Disk array 2
(behind 5RU
filler panel)
Disk array 1
7
