Removing and Replacing the Rack Front and Back
Doors
Use the following procedure to remove and replace the rack front and back doors.
This section supplements the information in Chapter 3 of the Sun Technical Compute
Farm Installation and Service Manual.
To Remove a Rack Door
1. Reach inside the door and push down on the lever attached to the spring of the
top hinge pin.
This causes the hinge pin to retract into the door.
2. Tilt the door out from the top mounting bracket.
3. Remove the door and set it aside.
To Replace a Rack Door
1. Tilt the door and insert the bottom hinge pin into the outside hole of the bottom-
left mounting bracket.
2. Reach inside the door and push down on the lever attached to the spring of the
top hinge pin.
This causes the hinge pin to retract into the door.
3. Align the top hinge pin with the outside hole of the top-left mounting bracket.
4. Release the lever.
The hinge pin extends into the mounting bracket.
