X-NUCLEO-53L3A2 Hardware Description
• The X-NUCLEO-53L3A2 is a ranging sensor with multi target detection
evaluation and development board designed around the VL53L3CX
sensor based on ST FlightSense™ Time-of-Flight technology.
• The VL53L3CX communicates with the STM32 Nucleo developer board
host microcontroller through an I2C link available on the Arduino UNO R3
connector.
Key Product on board
• VL53L3CX Time-of-Flight (ToF) ranging sensor with multi target detection
• 0.25, 0.5 and 1mm spacers to simulate air gaps, with the cover glass
• Cover window (made by Hornix) sample with low cross-talk ready to use / clipable on
VL53L3CX
• Two VL53L3CX breakout boards
VL53L3CX Nucleo expansion board (X-NUCLEO-53L3A2)
Hardware Overview (3/3)
VL53L3cx
Latest info available at www.st.com
X-NUCLEO-53L3A2
