P-NUCLEO-WB55 Hardware Description
• The P-NUCLEO-WB55 is designed around the STM32WB55RG microcontroller in a 68-pin
VFQFPN68 package.
Key Product on board
•
2.4 GHz RF transceiver supporting Bluetooth® specification v5.0 and IEEE802.15.4-2011 PHY and
MAC
•
Dedicated Arm® 32-bit Cortex® M0+ CPU for real-time Radio layer
•
Three user LEDs
•
Three user buttons and one reset button
•
Board connector: USB user with Micro-B
•
Board expansion connectors:
– Arduino™UnoV3
– Stmorpho
•
Integrated PCB antenna or footprint for SMA connector
•
Flexible power-supply options: ST-LINK USB VBUS or external sources
•
On-board socket for CR2032 battery
•
On-board ST-LINK/V2-1 debugger/programmer with USB re-enumeration capability: mass storage,
virtual COM port and debug port
P-NUCLEO-WB55
Hardware Overview (1/3)
Latest info available at www.st.com
P-NUCLEO-WB55
