MicroBlock Three-Axis Flexure Stage

4.7 Dimensions

4.7.1 Top platform

20
(0.79)
60
(2.36)
20
(0.79)
Page 8
60.0 (2.36)
3 Pitches of 15.00 (0.59) = 45.0
17.0 (0.67) 17.0 (0.67)
7.5
(0.3)
10.0 (0.39) 10.0 (0.39)
5.3 (0.21)
5.3 (0.21)
20.0 (0.79) 20.0 (0.79)
30.0 (1.18)
3.00 (0.12)
60 (2.36)
7.5
(0.3)
Product No
AMA001 28 (1.10
AMA003 35 (1.38)
AMA005 45 (1.77)
Fig. 4.3 Top platform
all dimensions in millimetres (inches)
A
B holes M3 (6-32 UNC)
A B
12 (0.47)
12 (0.47)
14 (0.55)
4.0 (0.16)
1.6 (0.06)
11056-D01
