Arena Zoom 10x40 IP65
User Manual
This manual contains important information.
Please read before operating fixture.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Arena Zoom and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FOS Technologies Arena Zoom

Summary of Contents for FOS Technologies Arena Zoom

  • Page 1 Arena Zoom 10x40 IP65 User Manual This manual contains important information. Please read before operating fixture.

  • Page 2: Safety Tips

    1 SAFETY TIPS WARNING!!! To reduce the risk of fire, electric shock, or injury to persons, follow these important safety instructions: non-professionals users should not disassemble the light arbitrarily • for maintenance or repairs. rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ •...

  • Page 3: Technical Specifications

    2 TECHNICAL SPECIFICATIONS Input Voltage: AC100-240V 50/60Hz Power: 400W Light Source: 10pcs LED each 40 W, RGBW 4in1. Led Feature: Individual control of each LED. Led life: 50,000 hours life expectancy. Zoom Angle: 5.8~60° DMX Channels: 33CH / 19CH / 34CH / 28CH / 29CH / 48CH / 49CH Control mode: DMX 512, master-slave, sound, Auto Dimmer: 0-100% electronic Shutter: Max 10Hz electronically...
  • Page 4 Product Dimensions(mm): 3 DISPLAY MENU LAYOUT DMX MODE 001-512 DMX512 Auto1 Auto 2 DMX MODE 33CH 19CH 34CH 28CH...
  • Page 5 29CH 48CH 49CH TEST Pan&Tilt Lamp Test Display Shutoff time Flip display Key lock Disp flash Tilt Reverse No DMX Status Black Hold Language English 中文 INFO Time info Total 0000:00 Power on 0000:00 Version SX- V1.01 Manual Zoom 000-255 Tilt 000-255 Fuction...

  • Page 6: Dmx Channel Sheet

    White 000-255 Chase 000-255 Speed 000-255 Reset All Reset 4 DMX CHANNEL SHEET 33CH Channel DMX value Function 0-255 Tilt 0-255 Tilt fine 0-255 Zoom,wide(flood)-Narrow(spot) Reserved 8-255 Reserved Set 1 color(fixed) Colors adjustable via RGB 8-15 Color 01-red 16-23 Color 02- amber 24-31 Color 03-warm yellow 32-39...
  • Page 7 120-127 White-CTB (7200K) 128-255 Rainbow effect 0-255 Set 1 red, color mixing system 0-255 Set 1 green, color mixing system 0-255 Set 1 blue, color mixing system 0-255 Set 1 white, color mixing system 0-255 Set 1 intensity Shutter Shutter closed 10-109 Shutter pulse random, slow to fast 110-239...
  • Page 8 0-255 Pattern movement 0-255 Set 2 pattern select 0-255 29ch pattern movement Speed, fast to slow 0-255 Reserved 0-255 Reserved 19CH Channel DMX value Function Reserved Reserved 0-255 Tilt 0-255 Tilt fine Set 1 color(fixed) Colors adjustable via RGB 8-15 Color 01-red 16-23 Color 02- amber...
  • Page 9 0-255 Set 1 red, color mixing system 0-255 Set 1 green, color mixing system 0-255 Set 1 blue, color mixing system 0-255 Set 1 white, color mixing system Shutter Shutter closed 10-109 Shutter pulse random, slow to fast 110-239 Strobe effect, slow to fast 240-255 Shutter closed 0-255...
  • Page 10 8-15 Color 01-red 16-23 Color 02- amber 24-31 Color 03-warm yellow 32-39 Color 04-yellow 40-47 Color 05-green 48-55 Color 06-Turquoise 56-63 Color 07-cyan 64-71 Color 08-blue 72-79 Color 09-lavender 80-87 Color 10-malve 88-95 Color 11-magenta 96-103 Color 12-Pink 104-111 White-CTO (3200K) 112-119 White (5600K) 120-127...
  • Page 11 Set 2 color :Values see channel 5 0-255 Set 2 red, color mixing system 0-255 Set 2 green, color mixing system 0-255 Set 2 blue, color mixing system 0-255 Set 2 white, color mixing system 0-255 Set 2 intensity Set 3 color: values se channel 5 0-255 Set 3 red, color mixing system 0-255...
  • Page 12 8-255 Reserved 0-250 No function 251-255 Reset 0-255 Reserved 0-255 Zoom,wide(flood)-Narrow(spot) 0-255 Set 1&2 red, color mixing system 0-255 Set 1&2 green, color mixing system 0-255 Set 1&2 blue, color mixing system 0-255 Set 1&2 white, color mixing system 0-255 Set 3&4 red, color mixing system 0-255 Set 3&4 green, color mixing system...
  • Page 13 0-255 Tilt fine Shutter Shutter closed 10-109 Shutter pulse random, slow to fast 110-239 Strobe effect, slow to fast 240-255 Shutter closed 0-255 Intensity 0-255 Reserved Reserved 8-255 Reserved 0-250 No function 251-255 Reset 0-255 Reserved 0-255 Zoom,wide(flood)-Narrow(spot) 0-255 Set 1&2 red, color mixing system 0-255 Set 1&2 green, color mixing system 0-255...
  • Page 14 0-255 Set 9&10 white, color mixing system 0-255 Set 9&10 red, color mixing system 0-255 Set 9&10 green, color mixing system 0-255 Set 9&10 blue, color mixing system 48CH Channel DMX value Function 0-255 Tilt 0-255 Tilt fine Shutter Shutter closed 10-109 Shutter pulse random, slow to fast 110-239...
  • Page 15 0-255 Set 3 red, color mixing system 0-255 Set 3 green, color mixing system 0-255 Set 3 blue, color mixing system 0-255 Set 3 white, color mixing system 0-255 Set 4 red, color mixing system 0-255 Set 4 green, color mixing system 0-255 Set 4 blue, color mixing system 0-255...
  • Page 16 49CH Channel DMX value Function 0-255 Tilt 0-255 Tilt fine Shutter Shutter closed 10-109 Shutter pulse random, slow to fast 110-239 Strobe effect, slow to fast 240-255 Shutter closed 0-255 Intensity 0-255 Reserved Reserved 8-255 Reserved 0-250 No function 251-255 Reset 0-255 Reserved...
  • Page 17 0-255 Set 3 blue, color mixing system 0-255 Set 3 white, color mixing system 0-255 Set 4 red, color mixing system 0-255 Set 4 green, color mixing system 0-255 Set 4 blue, color mixing system 0-255 Set 4 white, color mixing system 0-255 Set 5 red, color mixing system 0-255...
  • Page 18 5 FIXED EQUIPMENT Please fasten the fixture clamp before hanging. The clamp can be fastened by the little hole in the middle of the bracket, then tie with a safety belt. The loading capacity of the safety belt should be 10 times than the weight of the fixture itself.

  • Page 19: Maintenance & Troubleshooting

    7 Maintenance / Troubleshooting Problems Check list Trouble Shooting The fixture 1. If your power as same as the input 1. Make sure the voltage. does not work. of the machine. 2. Replace the same fuse. 2. If the fuse was broken. LED dimmed.
  • Page 20 Note: The manufacturer continues to improve the product, and all specifications are subject to change without notice. Consult the online user manual for an updated version in such case. Thank you for your understanding.
