- Page 1 ® HANAULUX 2000 Operating instructions for all HANAULUX 2000 ceiling- and wall modells 56351039/C...
-
Page 2: Table Of Contents
Operating Instructions 56351039/C HANAULUX 2000 TABLE OF CONTENTS PAGE Important safety information Description of the HANAULUX 2000 system 2.1 The HANAULUX concept 2.2 Standard components 2.3 Special components 2.4 Expandability The HANAULUX benefits 3.1 Briliant cool light 3.2 In-depth illumination 3.3 Optimal hygiene... -
Page 3: Important Safety Information
Dear Operator! These instructions apply to all HANAULUX 2000 ceiling and wall models. • Your HANAULUX 2000 operating theatre lighting system was developed with consideration for the high demands made on the surgeon’s eyes during surgery. - Page 4 This helps you follow the instructions in the text more easily. These operating instructions refer to the following HANAULUX 2000 luminaire systems, as a single light or in combination with other HANAULUX 2000 lights or accessories:...
- Page 5 1.2.3 Transport and Storage • A HANAULUX 2000 operation luminaire system with several lamps is suitable without limitation. The following storage conditions apply for up to 15 weeks: •...
-
Page 6: The Hanaulux Concept
56351039/C HANAULUX 2000 2.1 The HANAULUX 2000 concept The HANAULUX 2000 system is a modern operating theatre lighting concept which fulfils the highest requirements for light quality, hygiene and flexibility. The basic principle of the HANAULUX 2000 lighting systems is the compatibility and interchangeability of the individual components. -
Page 7: Special Components
2.3 Special components 2.3.1. Special suspension system for low ceilings The full benefits of the HANAULUX 2000 system can still be enjoyed even if the ceiling in your operating theatre is very low. Two special products are offered for low ceilings:... -
Page 8: Expandability
It is always possible to limit the rotation in the axle or the arms in a HANAULUX 2000 system should this be required. Please contact your Heraeus Med service agent for further information. -
Page 9: The Hanaulux Benefits
HANAULUX 2000 3.0 The HANAULUX Benefits 3.1 Brilliant cool light The heart of the HANAULUX 2000 lighting A specially developed double Fresnel lens 1, system is the HANAUCHROME optical system. creates a homogenous lightfield and completes Each HANAULUX 2000 lightheads has a different... -
Page 10: In-Depth Illumination
Abb. 3.3 3.4 Easy manoeuvrability, true positioning Even if the HANAULUX 2000 system is equipped with several SATELLIT lights and a HANAUPORT Lite arm, all can be easily moved without damage or interference. Three special... -
Page 11: Operating Your Hanaulux 2000 System
® Operating Instructions 56351039/C HANAULUX 2000 4.0 Operating your HANAULUX 2000 luminaire system 4.1 Mounting and removing the sterilisable handle All HANAULUX 2000 models have a sterilisable handle which can be removed and sterilised. To mount the handle 1, push it up onto the handle pillar until the ball bearing 2 snaps into place, as shown. -
Page 12: Positioning The Lights
® Operating Instructions 56351039/C HANAULUX 2000 4.2.2. Positioning the lights The extension arm at position 1 is specially shaped to allow the light to be positioned directly under the central axle, as is required for some disciplines. In order to achieve best possible mobility please position this arm in relation to the second light in a M position, as shown in fig. - Page 13 ® Operating Instructions 56351039/C HANAULUX 2000 4.3 Focussing the lights 4.3.1 Avoiding light spill When focusing or adjusting the fieldsize of your lights please keep the fieldsize to the minimum. The fieldsize should be just sufficiently large to illuminate the incision and surrounding tissues. If the field is too big, light spill around the operating area could dazzle and tire the eyes.
-
Page 14: Dimming The Light
56351039/C HANAULUX 2000 4.3.3 Working area and focus range Your HANAULUX 2000 lights have a special optical system (see chapter 3.1) which has the unique feature of providing a column of light which approximately 50 cm long. In practise this... - Page 15 ® Operating Instructions 56351039/C HANAULUX 2000 4.5 Operating the 2007 iXl D and 2007 iXL AF 4.5.1 Operating the 2007 iXL AF light The HANAULUX 2007 iXL AF is equipped with The autofocus system is now set. The fieldsize an autofocus system which automatically will remain the same during the entire operation.
-
Page 16: Important Information About Halogen Bulbs
5.0 Important information about halogen bulbs 5.1 Changing a bulb The shape and structure of the filament of the halogen bulbs used for the HANAULUX 2000 DUO lighting systems are specially designed for the HANAUCHROME optical system (see chapter 3.1). - Page 17 ® Operating Instructions 56351039/C HANAULUX 2000 The bulb generates considerable Never touch a bulb with bare heat which is emitted through the hands as the life of the bulb could top of the lighthead. The covers be considerably shortened. will therefore be quite warm to the touch.
-
Page 18: Adjustments
® Operating Instructions 56351039/C HANAULUX 2000 6.0 Adjustments The brakes are always adjusted during the commissioning phase and before official 6.1 Adjusting the brakes handover. The brakes should always be adjusted so that the manoeuvrability of the light is as light as possible but the light still maintain it’s position. -
Page 19: Adjusting The Spring-Arms
® Operating Instructions 56351039/C HANAULUX 2000 6.2 Adjusting the spring-arms 5. Place the spring-arm covers on the pring-arm. Should the lighthead drift downwards or jump The holes for the screw 3 and the hole in the upwards then the spring balance in the cover nose must line up. - Page 20 Operating Instructions 56351039/C HANAULUX® 2000 Adjustment of Acrobat Adjustment of Acrobat 2000 spring arm 2000 straight spring arm 6.4.1 6.3.1 Adjustment of spring arm: Adjustment of spring arm: upper stop upper stop Use the 5 mm Allen key provided (Fig. 1). Locate the setting.
-
Page 21: Cleaning/Desinfecting And Sterilising
7.4 Cleaning HANAUVISION 7.2 Cleaning the lenses The HANAULUX 2000 lenses are made of tough, high quality acrylic. As all plastics are subject to For details regarding the special care and cleanig aging processes the lenses should be visually of your HANAUVISION camera system please inspected from time to time. -
Page 22: Maintenance And Repair
(Part. no.) 2006/7 iXL 56052959 56050730 2007 iXL AF 56052969 56050732 All HANAULUX 2000 products are to be 2004/2005 iXL 56052961 56052962 inspected by the operator every six months with attention to the following points: 2002 i to 2005 i... -
Page 23: Troubleshooting Your Hanaulux 2000 System
® Operating Instructions 56351039/C HANAULUX 2000 9.0 Troubleshooting your HANAULUX 2000 system Fault Possible cause Corrective measure Reference Suspension System/Manoeuvrability Brakes are too tight Readjust brakes Chapter 6.1 Light is heavy, difficult to move Light is too light, Brakes are too loose Readjust brakes or replace Chapter 6.1... - Page 24 ® Operating Instructions 56351039/C HANAULUX 2000 Fault Possible Cause Corrective Measure Reference Lenses Lenses cracked, Wong cleaning agent - Replace lenses Chapter 8.0 used - Check cleaning agent splitting - Voltage too high - Replace lenses Lenses have - Wrong bulbs used - Check voltage Chapter 5.0 melted, bubbled...
-
Page 25: Technical Data
