  • Page 9 THE CS100 /CS100i ® ® ABBREVIATED OPERATOR’S GUIDE DATASCOPE IS NOW MAQUET CARDIOVASCULAR...
  • Page 10 CS100 BEZEL AND KEYPAD This guide is a reference for personnel trained in using the MAQUET CS100. Complete instructions for operation are provided in the MAQUET Operating Instructions: CS100 Manual (PN: 0070-00-0529-01). Do not use this guide until after thoroughly reading the Operating Instructions. Caution: Federal law...
  • Page 11 Abbreviated Operator’s Guide CS100 ® /CS100i ® QUICK REFERENCE – INITIAL SET-UP 1. Establish power and verify the MAINS ON/OFF and the IABP ON/OFF switches are 2. Open the Helium cylinder and verify the helium pressure. 3. Establish ECG and Pressure connection from the patient.
  • Page 12 | 2 | CS100 ® /CS100i ® Abbreviated Operator’s Guide OPERATING MODES AUTO Operation Mode All aspects of pump Operation are automated. Most appropriate trigger source is automatically selected. Inflation and deflation timing is automatically set. Lead I, II, III, or External ECG source is automatically selected.
  • Page 13 Abbreviated Operator’s Guide CS100 ® /CS100i ® TRIGGER SOURCE Trigger is the signal the CS100 uses to identify the beginning of the cardiac cycle. The Trigger Source keys are only active in the SEMI AUTO and Manual Operation Modes. Regardless of the Operation Mode, the active trigger source is indicated by a flashing diamond in the upper right corner of the screen.
  • Page 14 | 4 | CS100 ® /CS100i ® Abbreviated Operator’s Guide Pacer A This trigger mode is only available in the SEMI AUTO and Manual Operation modes. The R-wave of the ECG is the trigger event. Atrial pacer spikes are enhanced and rejected.
  • Page 15 Abbreviated Operator’s Guide CS100 ® /CS100i ® TIMING Timing refers to the positioning of inflation and deflation points on the arterial waveform. In the STANDBY mode an inflation marker appears as a highlighted interval on the Arterial Pressure Waveform. To supplement the marker, a horizontal bar is drawn beneath the Arterial Pressure Waveform.
  • Page 16 | 6 | CS100 ® /CS100i ® Abbreviated Operator’s Guide CLINICAL TROUBLESHOOTING - CLINICAL CONSIDERATIONS DURING OPERATION ECG: There are several methods to correct conditions that alter or hamper the acquisition of a reliable ECG. Reposition or replace ECG electrodes and check that the patient cable is properly connected.
  • Page 17 Abbreviated Operator’s Guide CS100 ® /CS100i ® Ventricular Standstill or Prolonged Cardiac Arrest: If possible, use during CPR. This facilitates Arterial Pressure trigger synchronization of the assist to the rate and rhythm of chest compressions. Operation mode, the (R-wave) or...
  • Page 18 Abbreviated Operator’s Guide CS100 ® /CS100i ® SYSTEM ALARMS MESSAGES AND ADVISORIES Help screens are provided to guide the user through set-up procedures and for consultation regarding alarm message descriptions and alarm configurations. Help screens are context sensitive and available based on the information displayed on the screen.
  • Page 19 | 10 | CS100 ® /CS100i ® Abbreviated Operator’s Guide MESSAGE [SEMI AUTO OR PROBABLE CAUSE MANUAL OPERATION MODE] No Trigger Valid trigger, as defined in Specification sec- tion, does not exist or is lost in ECG or Pacer Trigger mode.
  • Page 20 Abbreviated Operator’s Guide CS100 ® /CS100i ® 11 | CATHETER ALARMS The CS100 continually monitors specific parameters within the closed patient pneumatic system. If a change is detected or a specific parameter is violated, IABP Assist is suspended and a continuous tone will sound.
  • Page 21 | 12 | CS100 ® /CS100i ® Abbreviated Operator’s Guide ALERTS Alert messages are displayed in the ADVISORIES section of the screen. IAB pumping is not suspended with Alert conditions. A double beep tone signals the operator that corrective action is required.
  • Page 22 Abbreviated Operator’s Guide CS100 ® /CS100i ® 13 | STATUS/PROMPTS Status/Prompt messages are displayed in the ADVISORIES section of the display. Status/Prompt messages do not sound any tones (with the exception of Unplug Disk Outlet & Plug Disk Outlet) and are advisory in nature.
  • Page 23 | 14 | CS100 ® /CS100i ® Abbreviated Operator’s Guide MENU GUIDE The CS100 uses menus to provide rapid access to infrequently used functions. The menu guide, below, is also located on the top of the CS100 console. MENU NAVIGATION The first step in the menu navigation is to open the desired menu by pressing the associated key.
  • Page 24 | 16 | CS100 ® /CS100i ® Abbreviated Operator’s Guide SAFETY DISK LEAK TEST This optional test measures the pneumatic leak rate(s) of the Safety Disk. The test requires multiple interactions with the operator. Specifically during the course of the test, the operator is requested to plug and unplug the outlet of the safety disk.
  • Page 25 Prior to using the system in any other position except vertical, consult with Technical Service. NOTE: For information on outfitting an aircraft for IABP transport contact your local MAQUET sales representative. See “Accessories” on page 10-9 of the CS100 Operator’s Manual for information on the Transport Docking Station.
  • Page 26 | 18 | CS100 ® /CS100i ® Abbreviated Operator’s Guide BATTERY OPERATION During portable Operation, the CS100 is powered by a rechargeable battery. Prior to portable Operation the battery should be fully charged. A fully charged battery is indicated by a continuously illuminated battery charging LED. This LED is located on the front panel.
  • Page 27 Abbreviated Operator’s Guide CS100 ® /CS100i ® 19 | SWITCHING FROM AC TO BATTERY OPERATION 1. The system automatically switches to battery power if AC power is removed (intentionally or due to power loss). 2. If necessary, charge the battery as described in accordance with previous instructions.
  • Page 28 | 20 | CS100 ® /CS100i ® Abbreviated Operator’s Guide REMOVING PUMP CONSOLE FROM THE CART The console can be removed from the cart with or without the battery pack attached. When removing the pump console or the monitor from the cart or returning them to the cart, ensure that the wheels of the cart are in the locked position.
  • Page 29 Abbreviated Operator’s Guide CS100 ® /CS100i ® 21 | To attach the monitor to the pump console: Detach the monitor from the cart handle by pressing the button on the rear of the monitor (fig. 5). Attach the monitor to the top of the pump console. Make sure the monitor is securely attached before moving the system.
