IMPORTANT
Read this entire installation manual to
ensure proper installation.
Wall anchors used must have a minimum
pull-out rating of 1,000 lbs.
File these instructions with the owner or
maintenance department.
Installation
Instructions
MG-WR
Terreon® Waste
Receptacle - MG-Series
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . . . 2
MG-WR Components . . . . . . . . . . . . . . . . . . . . . 2
MG-WR Layout Options . . . . . . . . . . . . . . . . . . . 3
MG-WR Installation . . . . . . . . . . . . . . . . . . . . .4-5
Cleaning and Maintenance . . . . . . . . . . . . . . . . . .6
P.O. Box 309, Menomonee Falls, WI 53052-0309
TEL. 1-800-BRADLEY
http://www.bradleycorp.com
FAX 262-251-5817
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bradley Terreon MG Series
Summary of Contents for Bradley Terreon MG Series
- Page 1 Wall anchors used must have a minimum pull-out rating of 1,000 lbs. File these instructions with the owner or maintenance department. P.O. Box 309, Menomonee Falls, WI 53052-0309 215-1442; EN 02-800 TEL. 1-800-BRADLEY FAX 262-251-5817 Page 1 of 6 http://www.bradleycorp.com...
- Page 2 1. This warranty is limited to replacing or repairing, at our option, transportation charges prepaid by the purchaser, any Bradley unit or part thereof which our inspection shall show to have been defective within the limitations of this warranty.
- Page 3 (483mm) BTWN - waste receptacle mounted between two lavatory systems 19" (483mm) AL - waste receptacle mounted on left side of alcove 19" (483mm) AR - waste receptacle mounted on right side of alcove Bradley Corporation • 215-1442; EN 02-800...
- Page 4 (SUPPLIED BY INSTALLER) BACK WALL 14" (356mm) CENTERLINE OF RECEPTACLE 7" TWO 1/4" ANCHORS (178mm) 5.85" (SUPPLIED BY (149mm) INSTALLER) 3.5" REF. COVER (89mm) 2" (51mm) 31.62" 25" REF. 29.12" (803mm) (635mm) (740mm) WASTE FLOOR FLOOR Bradley Corporation • 215-1442; EN 02-800...
- Page 5 1/16" to 1/8" of the threads exposed. 3. Using the two key holes on the back of the receptacle, hang the waste receptacle onto the fasteners (see Figure 5). Figure 5 Bradley Corporation • 215-1442; EN 02-800...
- Page 6 ** It is emphasized that all products should be used in strict accordance with package instructions. • Repair kit: A repair kit is available from Bradley to repair/patch Terreon®. Contact your Bradley representative to order a repair kit and be sure to specify color when ordering.
