Juniper Day One+ ACX7100-32C Manual page 2

The ACX7100-32C router is a 1-U, fixed-configuration router that provides a throughput of 4.8 Tbps while maintaining
a power-efficient footprint. It has 32 QSFP28 ports that operate at 100-Gbps and four QSFP56-DD ports that operate
at 400-Gbps.
We ship the ACX7100-32C router with redundant power supplies. You can order it with front-to-back airflow (airflow
out or AO), and with AC or DC power supplies.
Install the ACX7100-32C
IN THIS SECTION
What's in the Box? | 2
What Else Do I Need? | 2
Install the ACX7100-32C in a Rack | 3
What's in the Box?
ACX7100-32C router with six preinstalled fan modules and two preinstalled AC power supplies
Two AC power cords appropriate for your geographical location
An RJ-45 to DB-9 serial port adapter
A breakout cable to simultaneously connect to a console and to a time of day (TOD) device
Two power cord retainers
A four-post rack mounting kit that contains:
Two mounting rails for mounting the router flush with the front posts of a rack
Twelve flat head Phillips screws for attaching the front mounting rails to the router
Two rear mounting blades
What Else Do I Need?
Someone to help you secure the router to the rack
A number 2 Phillips (+) screwdriver
2
