Day One+
SRX380
IN THIS GUIDE
Step 1: Begin | 1
Step 2: Up and Running | 6
Step 3: Keep Going | 9
Step 1: Begin
IN THIS SECTION
Meet the SRX380 | 1
Install the SRX380 | 2
Power On | 4
Meet the SRX380
®
The Juniper Networks
SRX380 Services Gateway is a high-performance, all-in-one secure SD-WAN gateway. It provides
your network with superior and reliable WAN connectivity while consolidating security, routing, and switching for distributed
enterprise offices. With sixteen 1-Gigabit Ethernet PoE+ ports and four 10-Gigabit Ethernet ports, the SRX380 provides
greater port density than other models in the SRX300 line of devices, all in a 1-U form factor.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Day One Plus SRX380 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Juniper Day One Plus SRX380

  • Page 1 Power On | 4 Meet the SRX380 ® The Juniper Networks SRX380 Services Gateway is a high-performance, all-in-one secure SD-WAN gateway. It provides your network with superior and reliable WAN connectivity while consolidating security, routing, and switching for distributed enterprise offices. With sixteen 1-Gigabit Ethernet PoE+ ports and four 10-Gigabit Ethernet ports, the SRX380 provides...
  • Page 2 Install the SRX380 IN THIS SECTION What’s in the Box? | 2 What Else Do I Need? | 2 Install the SRX380 in a Rack | 3 What’s in the Box? SRX380 Services Gateway Power cord appropriate for your geographic location RJ-45 cable DB-9 adapter USB console cable...
  • Page 3 Someone to help you screw the SRX380 into the rack Eight rack mount screws A number two Phillips (+) screwdriver Install the SRX380 in a Rack Before you begin the installation, review General Safety Guidelines and Warnings. Here’s how to install the SRX380 in a rack: 1.
  • Page 4 6. While you’re holding the SRX380 in place, have a second person insert and tighten the rack mount screws to secure the mounting brackets to the rack rails. Make sure they tighten the screws in the two bottom holes first and then tighten the screws in the two top holes.
  • Page 5 1. Wrap and fasten one end of the electrostatic discharge (ESD) grounding strap around your bare wrist, and connect the other end to a site ESD point. 2. Attach a grounding cable to earth ground and then attach it to the SRX380’s grounding points. 3.
  • Page 6: Step 2: Up And Running

    Juniper Sky™ Enterprise, Juniper Networks-hosted public cloud-based Software as a Service (SaaS) solution. NOTE: You’ll need to have a Juniper Sky Enterprise subscription service before you can use it to configure the SRX380. For more information, check out the Juniper Sky Enterprise Getting Started Guide.
  • Page 7: Plug And Play

    1. Connect the WAN network to port 0/0. 2. Connect the LAN network to any of the ports from 0/1 through 0/18. 3. Check to see if the SRX380 is connected to the Internet. Go to http://www.juniper.net. If the page doesn’t load, check the Internet connection.
  • Page 8 Customize the Basic Configuration To customize basic settings using the J-Web Setup wizard, have these values handy: Hostname Root authentication password IP address for the NTP server IP address for the DNS server IP address for the management interface 1. In the J-Web application, select Configure > Setup Wizard. The Setup wizard opens on your screen. 2.
  • Page 9 Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners.
