- Page 1 NB203QR Operation Manual CO2 incubator + Roller Model : NB-203QR...
-
Page 2: Table Of Contents
Table of Contents CONTENTS PAGE SAFETY AND GENERAL PRECAUTION TRANSPORTATION, STORAGE, AND LOCATION OF INSTALLATION PREREQUISITE AND CONFIGURATION FEATURES AND SPECIFICATIONS OF THE UNIT CONTROL PANEL OPERATION SAFETY SWITCH ROLLER OPERATION HOW TO DETACH THE ROLLER TROUBLESHOOTING... -
Page 3: Safety And General Precaution
1. SAFETY AND GENERAL PRECAUTION 1.1 General information on precaution Precaution is to prevent the possible accident or danger during operation. ⚫ So, you must keep it. Precaution is divided into caution and warning. And, each of them has following meanings. ⚫... - Page 4 1.3 Precaution for ground connection Please ground before use the product, if you don't ground, you could get an electric shock when malfunction or an electric leakage occurs. At the place where you can't ground, * Please buy the equipment to prevent any electrical leakage. * An electric shock, an electric leakage and a fire can be occurred without an electric leakage breaker.
-
Page 5: Transportation, Storage, And Location Of Installation
When you don't use the product or clean it, please pull out the power plug. (It is to prevent an eclectic leakage.) Open and close the door softly and please use a door knob. (A heavy shock can damage the product and breakdown the operating part. Also your hands can be stuck between the door and body.) Do not detach the built-in lamp and electrical devices. - Page 6 2.3 Location of installation and ambient conditions Do not put flammable substances near the product. (It may cause a fire.) When you install the product, you are required to keep the distance at least 30cm from the wall. To completely separate the unit from the power supply, power plug must be disconnected.
-
Page 7: Prerequisite And Configuration
When you have received the instrument which is packed on pallet, inspect the box carefully for any damages that may have caused any damages to product during shipping. Please report any damage to the carrier or to your local N-BIOTEK distributor immediately. LOCATION The incubator is designed to operate at temperature 5℃... - Page 8 3.2 Configuration Exterior Configuration of CO2 incubator. <Figure #1> Control panel Air jacket -6 side direct heating Ventilation fan Power switch Glass door heater -Prevent condensation Magnetic door seal Stainless steel shelve Glass door - Perforated to improve uniformity Inner door seal Door latch - Airtight to prevent CO leakage...
-
Page 9: Features And Specifications Of The Unit
4. FEATURES AND SPECIFICATIONS OF THE UNIT 4.1 Features 1. Excellent Uniformity of Temperature, CO 2. 6 Side Direct Heat for Temperature Uniformity and Fast Recovery 3. IR CO₂Sensor detects precise density of CO₂ 4. Outer Heated Door ensures no condensation on glass door. 5. -
Page 10: Control Panel
5. CONTROL PANEL 16 15 Alarm ON/OFF switch Safety Activation Indication Lamp: If Safety is activated, it will be ON. Heating Signal : To show status of heating activation at 3 parts. Glass door means the heater around glass door. Temperature display LED window CO₂... -
Page 11: Operation
6. OPERATION * Before Switch ON, insert water tray filling with distilled water. Make sure connection of gas supply. And Open CO2 gas cylinder or supply with the pressure of regulator set to 4.5Psi or 0.3 bar. * Please check connection of gas supply. And Open CO2 gas cylinder for supply with the pressure of regulator set to a certain level. - Page 12 ▶ When previous stage is cleared, connect the gas tube to regulator and incubator. At this point, Make sure that valves of all the part besides gas cylinder, Regulator are locked. (④ and ⑤ have the opposite lock direction each other. ④ is clockwise and ⑤ is counterclockwise) ▶...
- Page 13 Calibration for temperature and CO2 Please follow up below procedure for calibration in case of discrepancy between actual value (measured by reliable measurement device) in chamber and displayed value. Measure CO2 density and Temperature after incubator is stabilized in which takes about more than 2 hours (you might want to perform this stabilization process at night before home) Please note that low deviation range such as ±0.1 ~ 0.3% may not be corrected precisely by this calibration.
- Page 14 b. Second Click “CAL/SET” ☞ Outer door’s Temp calibration Channel 2 is purposed to remove water condensing on glass door caused by high temperature difference between chamber and outside. Recommend to use calibration at Channel 2 in case of water condensing on glass door. Note Except water condensing on glass door, calibration of channel 2 and 3 is not recommendable.
- Page 15 NOTE Channel 5 is to set heating control point. If it is set at 3, then the heating control works from 34’C against setting value i.e. 37’C. This is in order to minimize overshooting and faster reaching time to setting value. Therefore, user is kindly required not to change this value.
-
Page 16: Safety Switch
7. SAFETY SWITCH It is the safety device to prevent the heater from overheating when the temperature controller is malfunctioning. ■ Set the Safety S/W higher than setting point. ■The Safety S/W has wide deviation ■ Safety S/W is the safety device for preventing the heater to overheat when TEMP. -
Page 17: How To Detach The Roller
<TIME setting> ① Please STOP the product first. ② Press RPM/TIME button and get TIME MODE DISPLAY( t 00.00 ). ③ Press SET button then first 2 digits of DISPLAY TIMER will be flickering. ④ Set the desired time of hour by UP(∧), DOWN(∨) button. ⑤... -
Page 18: Troubleshooting
Replace main board Not proper engaged with axis Make sure to fix both axis and and shaft shaft in. Manufactured By : N-BIOTEK, Inc. 402-803 Techno-park, 655 Pyeongcheon-ro, Bucheon si Gyeonggi Province, Korea Tel : +82 321 2100 E-mail : export@n-biotek.com...
