- Page 1 WSD10DGII User Manual...
-
Page 2: General Warnings
WSD10DGII User Manual General warnings. • The following information must be read and understood before proceeding with the installation, commissioning and maintenance of the devices described in this document. • ATTENTION! Any omission or failure to follow these instructions scrupulously can cause danger. - Page 3 WSD10DGII User Manual • alarm value indiucated is the maximum value acquired sampling at 100Hz on three axis, for a maximum duration of 500msec. “Sentry” feature is also extended to potentiometric channel, that can detect rope extensions and contractions with a delay of few seconds and, in case of threshold trespassing sends immediately to gateway information regarding event and related alarm.
- Page 4 WSD10DGII User Manual This transition is practicable in field, during the sampling period, using the wireless network association command. When the association is done, the datalogger becomes a wireless datalogger and, besides sending new measures to the gateway, starts a download process towards...
-
Page 5: Device Enrolment
WSD10DGII User Manual WIRELESS DEVICES USER INTERFACE Flash count Command Description Shows the device STATUS. As answer the led perform a flash sequence as 1 flash STATUS reported in the STATUS table. If the device is performing the TEST (... - Page 6 WSD10DGII User Manual The device will give back the radio signal quality through led flashes: WIRELESS MODE STATUS Table FLASH COUNT – WIRELESS MODE STATUS/RADIO SIGNAL QUALITY 5 green flashes ACTIVE - Radio signal: Excellent 4 green flashes ACTIVE - Radio signal: Good...
- Page 7 WSD10DGII User Manual 9. Shutting off/Reactivating the device. (refer to Picture 4 – Wireless devices user If the device is shut off and left unused for a long time, you can issue the STANDBY command interface) . It corresponds to the command number 4 and must be issued twice to confirm the operation.
- Page 8 Picture 7 - Mechanical dimensions 12. Disclaimer. • Specifications are subject to change without notice and should not be interpreted as a commitment on the part of Capetti Elettronica S.r.l. • Capetti Elettronica S.r.l. assumes no responsibility for possibly errors that may appear in this document. In no case Capetti Elettronica S.r.l.
- Page 9 WSD10DGII User Manual 13. Reference standards. EN 61010 -1 For electromagnetic compatibility EN 61000 - 3 - 2 EN 61000 - 3 - 3 EN 300 220 -2 EN 301 489 - 03 EN 61000 - 6 -1 This symbol indicates that this product is compliant with the European Directive 2011/65/CE that restricts the use of substances in the manufacturing of electronic devices.
