- Page 1 WSD12-4D User Manual...
-
Page 2: General Warnings
WSD12-4D User Manual General warnings. • The following information must be read and understood before proceeding with the installation, commissioning and maintenance of the devices described in this document. • ATTENTION! Any omission or failure to follow these instructions scrupulously can cause danger. - Page 3 WSD12-4D User Manual • WineCapManager Execute software, create a new database, open it, and wait for datalogger acknowledgement and automatic connection. GREEN WineCapManager Once the connection is established, datalogger’s led flashes in , meantime on main page real time channels data...
- Page 4 WSD12-4D User Manual • Scale factor Modifies resolution and consequently the transducer’s dynamic range. The correct value to be inserted is the external linear transducer’s full scale, expressed in mm, divided per 10,000. Scale factor For example, if the full-scale value of a linear transducer is 25mm, the value to be inserted in the “...
- Page 5 WSD12-4D User Manual • Channel Calibration. If you need to add calibration values to a measurement channel, you can access the "Advanced sensor properties" screen and set the gain and offset values in the appropriate fields on the "Calibration" tab.
-
Page 6: Resetting Channels
WSD12-4D User Manual 3. Resetting channels. Once the device has been installed in the desired location, it is possible to proceed with resetting the channels previously configured for acquiring strain or proportional measurement values. Wireless device This procedure can be performed via WineCapManager or by using the wireless device user interface directly on the device (see user interface. - Page 7 WSD12-4D User Manual This transition is practicable in field, during the sampling period, using the wireless network association command. When the association is done, the datalogger becomes a wireless datalogger and, besides sending new measures to the gateway, starts a download process towards...
- Page 8 WSD12-4D User Manual The following COMMAND table describes the available commands: WIRELESS DEVICES USER INTERFACE Flash count Command Description Shows the device STATUS. As answer the led perform a flash sequence as 1 flash refer to STATUS reported in the STATUS table. If the device is performing the TEST ( TEST command ) this command stops it.
-
Page 9: Device Enrolment
WSD12-4D User Manual 6. Device enrolment. Not necessary if performed in factory before delivery. “WineCap System - User Manual R30” Enrol the device to the wireless network referring to the . In case the device is already enrolled but in Picture 10 –... - Page 10 WSD12-4D User Manual WineCapKey STATUS Through the is possible to ask for the status, bring it close to the datalogger for 1 flash ( ) and remove it. STAND-ALONE DEVICE - STATUS TABLE Table FLASH COUNT –STAND ALONE MODE STATUS...
- Page 11 WSD12-4D User Manual 9. Shutting off/Reactivating the device. (refer to Picture 10 – If the device is shut off and left unused for a long time, you can issue the STANDBY command . It corresponds to the command number 4 and must be issued twice to confirm the operation.
-
Page 12: Technical Information
WSD12-4D User Manual 11. Technical Information. Power supply 8.5Ah - 3.6V type “C” lithium internal battery ( BAT2 Up to 10 years (samples every 60 minutes and radio signal quality at least Battery life (*) sufficient) • Linear deformation • Proportional measure... -
Page 13: Mechanical Dimensions
Picture 14 - Mechanical dimensions 13. Disclaimer. • Specifications are subject to change without notice and should not be interpreted as a commitment on the part of Capetti Elettronica S.r.l. • Capetti Elettronica S.r.l. assumes no responsibility for possibly errors that may appear in this document. In no case Capetti Elettronica S.r.l. -
Page 14: Reference Standards
WSD12-4D User Manual 14. Reference standards. EN 61010 -1 For electromagnetic compatibility EN 61000 - 3 - 2 EN 61000 - 3 - 3 EN 300 220 -2 EN 301 489 - 03 EN 61000 - 6 -1 This symbol indicates that this product is compliant with the European Directive 2011/65/CE that restricts the use of substances in the manufacturing of electronic devices.
