UG-1554
Table 2. Link Options for P2 Header
Pin No.
Position
1, 2
Inserted
Not inserted
3, 4
Inserted
Not inserted
5, 6
Inserted
Not inserted
7, 8
Inserted
Not inserted
9, 10
Inserted
Not inserted
11, 12
Inserted
Not inserted
13, 14
Inserted
Not inserted
EVAL-AD5423SDZ
Function
Connects the FAULT signal from the
Disconnects the FAULT signal from the
Connects the RESET signal from the
Disconnects the RESET signal from the
Connects the LDAC signal from the
Disconnects the LDAC signal from the
Connects the SCLK signal from the
Disconnects the SCLK signal from the
Connects the SDO signal from the
Disconnects the SDO signal from the
Connects the SDI signal from the
Disconnects the SDI signal from the
Connects the SYNC signal from the
Disconnects the SYNC signal from the
Rev. 0 | Page 4 of 19
Evaluation Board User Guide
SDP-S
to the FAULT pin on the AD5423.
SDP-S
to the FAULT pin on the AD5423.
SDP-S
to the RESET pin on the AD5423.
SDP-S
to the RESET pin on the AD5423.
SDP-S
to the LDAC pin on the AD5423.
SDP-S
to the LDAC pin on the AD5423.
SDP-S
to the SCLK pin on the AD5423.
SDP-S
to the SCLK pin on the AD5423.
SDP-S
to the SDO pin on the AD5423.
SDP-S
to the SDO pin on the AD5423.
SDP-S
to the SDI pin on the AD5423.
SDP-S
to the SDI pin on the AD5423.
SDP-S
to the SYNC pin on the AD5423.
SDP-S
to the SYNC pin on the AD5423.
