EVAL-ADG5401FEBZ

GETTING STARTED

EVALUATION BOARD SETUP PROCEDURE

The EVAL-ADG5401FEBZ operates independently and does
not require any additional evaluation boards or software to
operate. An on-board ADP7142
the digital power supply for the LEDs and to manually control
the ADG5401F.
To supply the EVAL-ADG5401FEBZ with a dual power supply
of ±5 V to ±22 V or a single supply of +8 V to +44 V, connect
the EVAL-ADG5401FEBZ VSS pin and GND pin together on
J1. If the VDD pin voltage is greater than 40 V, remove the R6
resistor to protect the on-board
move the R10 resistor to the R11 pad (where the R11 resistor
can be populated, if required) to use an alternative digital
voltage supply connected to the EXT_VL pin on J1.
User Guide
LDO regulator is provided as
ADP7142 LDO regulator and
J1
VDD
GND
VSS
R6
ADP7142
LK2
R10 = LDO
R11 = EXT VL
J1
EXT_VL
LK1
R4
Figure 2. EVAL-ADG5401FEBZ Functional Block Diagram
To set up the EVAL-ADG5401FEBZ to perform a functionality
test, take the following steps:
1. Connect a power supply to the J1 connector. If a single supply
is required, connect the EVAL-ADG5401FEBZ VSS pin and
GND pin together on J1.
2. Use the LK1 link header to control the digital signals of the
switch channel on the
1.
2.
The green LED1 then illuminates to indicate that the switch is
operating normally.
V GND V
SS DD
ADG5401F
J2:S
S
HI POC
LO
J2:SFB
SFB DFB
HI
IN
LO
LED1
R2
Rev. A | Page 3 of 8
ADG5401F as follows:
To open the switch and present it as an open
circuit, place LK1 in Position LO.
To close the switch and present it with a resistance
of approximately 6 Ω, place LK1 in Position HI.
J3:D
D
J3:DFB
FF
UG-1755
